Gigabyte GA-P55-USB3 Motherboard
  • LGA1156, P55, 4xDDR3-2200, 2xPCI-Ex16 v2.0, 8xSATA-II, 1xATA-133, RAID, 1xGigLAN, 8Chl-HD, USB3.0, ATX

IMG 1 of 2
No Longer Available
Part Number:
134078
(?) Brand:
Gigabyte Web Site
Manuf No:
GA-P55-USB3
GAP55USB3
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
GAP55USB3, GA-P55-USB3
GA-P55-USB3 (rev. 1.0)
Intel  P55 Chipset
  1. Leading quality standard of Ultra Durable 3 technology with 2oz copper PCB design
  2. Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  3. 3X USB power delivery for greater compatibility and extra power for USB devices
  4. Support Intel Core i7/ Core i5 processors with LGA 1156 socket
  5. New Dynamic Energy Saver 2 technology enables best energy efficiency
  6. Innovative Smart 6 technology for smarter PC management
  7. Support ATI CrossFireX for ultimate graphics performance
  8. Features high speed Gigabit Ethernet connection
  9. XHD technology accelerating hard drive performance with ease
  10. AutoGreen technology Greening your PC via Bluetooth cellphone
  11. Patented GIGABYTE DualBIOS technology delivering highest level failure protection
  12. Home theater quality 8-channel High Definition Audio
  13. Compatible with Windows 7 to deliver the best operation experience
  14. Meet European Union EuP(Energy-using Products) requirement

  Overview

  USB 3.0 Support
The GIGABYTE USB3.0 series motherboards support the latest generation SuperSpeed USB 3.0 technology made possible through an onboard NEC uPD720200 host controller. With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users of long term use of their legacy USB 2.0 devices. The onboard NEC SuperSpeed USB 3.0 technology also provides new power management features that include increased maximum bus power and device current draw to better accommodate power-hungry devices.

  3x USB Power Boost
GIGABYTE USB3.0 series motherboards feature a 3x USB power boost, delivering greater compatibility and extra power for USB devices. GIGABYTEs unique USB power design is also able to efficiently regulate output over the full voltage range, which greatly enhances USB device compatibility. In addition, dedicated lower resistance fuses ensure lower voltage drops, and provide more stable and plentiful power delivery.

    Ultra Durable 3

Ultra Durable 3
GIGABYTE Ultra Durable 3 design, featuring 2 ounces of copper for both the Power and Ground layers which dramatically lowers system temperature by delivering a more efficient spreading of heat from critical areas of the motherboard such as the CPU power zone throughout the entire PCB. GIGABYTE's Ultra Durable 3 also lowers the PCB impedance by 50%, which helps to reduce electrical waste and further lowers component temperatures. A 2oz Copper layer design also provides improved signal quality and lower EMI (Electromagnetic Interference), providing better system stability and allowing for greater margins for overclocking...more
    Benefits of 2 oz Copper PCB



Cooler than traditional motherboards
Enhanced durability
Improved energy efficiency
Greater margins for overclocking... more
    Smart 6- A Smarter way for PC system Management
GIGABYTE Smart 6 is designed with user-friendliness in mind, and offers a combination of 6 innovative software utilities that provide easier and smarter PC system management. Smart 6 allows you to speed up system performance, reduce boot-up time, manage a secure platform and recover previous system settings easily with a click of the mouse button.


Smart QuickBoot
No more waiting for PC Boot up

 Smart DualBIOS
Smart personal reminder
Smart QuickBoost
One-click Overclocking		 Smart Recorder
Your PC's Watch Dog
Smart Recovery
Reverse time for you		 Smart TimeLock
Time Controller for PC
    Qualified for Windows  7
The motherboard qualified for WHQL (Windows Hardware Quality Labs) certification of Windows 7 from Microsoft , setting the standard for future Windows 7 certified motherboards... more
  Dynamic Energy Saver 2
GIGABYTE Dynamic Energy Saver 2 incorporates a host of intelligent features that use a proprietary hardware and software design to considerably enhance PC system energy efficiency, Reduce power consumption and deliver optimized auto-phase-switching for the CPU, Memory, Chipset, VGA, HDD, and fans with a simple click of button.
    Intel  Core i7/ Core i5 LGA 1156 Processors



The Intel brand new computing architecture based on the innovation of micro-architecture transforms 3-chip solutions to a 2-chip platform. The next generation Intel  Core i7/ Core i5 processors with LGA1156 package integrate graphics and memory controller to support dual channel DDR3 memory. Supporting Intel Turbo Boost technology and Hyper-Threading Technology, Intel  Core i7/ Core i5 processors provide the overwhelming performance with optimized power efficiency.
  DDR3 2200+ Support
P55-USB3 support Intel Core i7/ Core i5 processors delivering native support for DDR3 memory up to 2200+MHz by the enhanced design of GIGABYTE, Intel Core i7/ Core i5 processors feature the memory controller integrated directly into the processor die, rather than as part of the Northbridge as in previous generations, allowing for faster memory performance.
* Please refer "Memory Support List" for memory support information
  XHD (eXtreme HardDrive)-Accelerating hard drive performance with ease
Accelerating system performance is made easy with the user friendly GIGABYTE eXtreme Hard Drive (X.H.D). GIGABYTE eXtreme Hard Drive (X.H.D) provides a quick and easy way to boost your hard drive performance simply by adding another hard drive.
  AutoGreen- Greening your PC via Bluetooth cellphone
AutoGreen technology can automatically save power for you simply by your bluetooth cell phone when you are away from your computer
  Multi-display support with ATI CrossFireX
P55-USB3 supporting ATI CrossFireX delivers the ultimate in graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution.
  Norton Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down. It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.
  EuP Lot 6 support
The EuP (as known as Energy Using Products Directive) is part of new European Union's environment regulations. EuP established is based on the concern of environmental issues regards electronic devices been gained popularity and how to improve energy efficiency for better and greener life. GIGABYTE presents standard motherboards to help you effectively improving system performance and saving more energy.



  Specifications
CPU
  1. Support for an Intel  Core i7 series processor/Intel  Core i5 series processor in the LGA1156 package (Go to GIGABYTE's website for the latest CPU support list.)
  2. L3 cache varies with CPU
Chipset
  1. Intel  P55 Express Chipset
Memory
  1. 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (Note 1)
  2. Dual channel memory architecture
  3. Support for DDR3 2200/1333/1066/800 MHz memory modules
  4. Support for non-ECC memory modules
  5. Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio
  1. Realtek ALC888 codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel
  4. Support for S/PDIF In/Out
  5. Support for CD In
LAN
  1. 1 x RTL8111D chip (10/100/1000 Mbit)
Expansion Slots
  1. 1 x PCI Express x16 slot, running at x16 (PCIEX16) (Note 2) (The PCIEX16 slot conforms to PCI Express 2.0 standard.)
  2. 1 x PCI Express x16 slot, running at x4 (PCIEX4_X1) (Note 3)
  3. 2 x PCI Express x1 slots
  4. 3 x PCI slots
Multi-Graphics Technology
  1. Support for ATI CrossFireX technology (Note 4)
Storage Interface Chipset:
  1. 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
  2. Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
GIGABYTE SATA2 chip:
  1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
  2. 2 x SATA 3Gb/s connectors (GSATA2_6, GSATA2_7) supporting up to 2 SATA 3Gb/s devices
  3. Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8720 chip:
  1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB Chipset:
  1. Up to 14 USB 2.0/1.1 ports (Note 5) (10 on the back panel, 4 via the USB brackets connected to the internal USB headers)
NEC chip:
  1. Up to 2 USB 3.0 ports on the back panel
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x floppy disk drive connector
  4. 1 x IDE connector
  5. 8 x SATA 3Gb/s connectors w1 x CPU fan header
  6. 2 x system fan headers
  7. 1 x power fan header
  8. 1 x front panel header
  9. 1 x front panel audio header
  10. 1 x CD In connector
  11. 1 x S/PDIF In header
  12. 1 x S/PDIF Out header
  13. 2 x USB 2.0/1.1 headers
  14. 1 x serial port header
  15. 1 x parallel port header
  16. 1 x clearing CMOS jumper
Back Panel Connectors
  1. 1 x PS/2 keyboard or PS/2 mouse port
  2. 1 x coaxial S/PDIF Out connector
  3. 1 x optical S/PDIF Out connector
  4. 8 x USB 2.0/1.1 ports
  5. 2 x USB 3.0/2.0 ports
  6. 1 x RJ-45 port
  7. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
  1. iTE IT8720 chip
H/W Monitoring
  1. System voltage detection
  2. CPU/System temperature detection
  3. CPU/System/Power fan speed detection
  4. CPU overheating warning
  5. CPU/System/Power fan fail warning
  6. CPU/System fan speed control
BIOS
  1. 2 x 16 Mbit flash
  2. Use of licensed AWARD BIOS
  3. Support for DualBIOS
  4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Q-Flash
  3. Support for Xpress BIOS Rescue
  4. Support for Download Center
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for EasyTune
  8. Support for Dynamic Energy Saver 2
  9. Support for Smart 6
  10. Support for Auto Green
  11. Support for eXtreme Hard Drive
  12. Support for Q-Share
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft  Windows 7/Vista/XP
Form Factor
  1. ATX Form Factor; 30.5cm x 24.4cm
Remark
  1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
  2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
Note (Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(Note 3) When the PCIEX1_2 slot is populated with an expansion card, the PCIEX4_X1 slot will operate at up to x1 mode.
(Note 4) The PCIEX16 slot operates at up to x4 mode when ATI CrossFireX is enabled.
(Note 5) Two share the same ports with USB 3.0.

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* All trademarks and logos are the properties of their respective holders.

* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
