Accelerate
Perform tasks on a PC faster with ATI Stream technology, speed up demanding everyday applications and get more done in less time.
Unleash the massive parallel processing power of your GPU to help you do more with your PC than ever before.
With multimedia softwares that support ATI Stream, users can enjoy fast video encoding and transcoding so video playback, editing and transferring content to portable media players is quick and easy.
DirectCompute presents even more opportunities for you to take advantage of your ATI Radeon HD 5400 Series GPU for tasks other than just rendering
- DirectCompute, helps improve PC performance by taking on some or all of a DirectX 11-enabled applications processing load, freeing up the computers mainprocessor to take on additional tasks.
- DirectX 11-enabled applications are designed for fast performance on your PC running Windows 7. In addition, programs designed for Windows 7 can convert a digital media file to a different size or format can perform a faster conversion (i.e. transcode) under Windows 7 than under previous versions of WIndows.
- Windows 7 with built-in drag and drop transcoding is a great example how ATI Radeon HD 5400 Series GPUs provide an exceptional experience for the upcoming operating system.
- High performance anisotropic filtering and 24x custom filter anti-aliasing (CFAA) smooth jagged edges and create true-to-life graphics, for everything from grass to facial features.
Dominate
With DirectX 11 support you can play the latest HD games with unrivalled visual quality, astonishing realism and ultra-fast frame rates.
Get unrivalled visual quality and intense gaming performance and for today and tomorrow with support for Microsoft DirectX 11
- ATI Radeon HD 5400 Series graphics accelerators and software drivers are the first to offer full support for Microsoft DirectX 11.
- Get striking 3D visual effects and dynamic interactivity with DirectX 11 support, including features like HDR Texture Compression, DirectCompute and Tessellation.
- DirectX 11 brings new levels of visual realism to gaming on the PC and youll get top-notch performance for these titles with ATI Radeon HD 5400 Series GPUs.
ATI Radeon HD 5400 Series GPUs are designed to deliver all the benefits of Microsoft Windows 7
Engineered to take advantage of all the graphical features within the new Windows 7 operating system, ATI Radeon HD 5400 Series GPUs deliver a visually compelling experience and a fast, responsive PC.
Up to 2.8 GB Memory Support with Hyper Memory**Enjoy the big memory frame buffer with Hyper Memory Technology.
Hyper Memory Support Matrix Under Windows Vista and Windows 7.
| |
1 GB system memory
|
2 GB system memory
|
3 GB system memory
|
4 GB system memory
|
|
64 MB
graphics memory
|
HyperMemory
= 320 MB
|
HyperMemory
= 832 MB
|
HyperMemory
= 1280 MB
|
HyperMemory
= 1792 MB
|
|
128 MB
graphics memory
|
HyperMemory
= 384 MB
|
HyperMemory
= 896 MB
|
HyperMemory
= 1344 MB
|
HyperMemory
= 1856 MB
|
|
256 MB
graphics memory
|
HyperMemory
= 512 MB
|
HyperMemory
= 1024 MB
|
HyperMemory
= 1536 MB
|
HyperMemory
= 2048 MB
|
|
512 MB
graphics memory
|
HyperMemory
= 768 MB
|
HyperMemory
= 1280 MB
|
HyperMemory
= 1792 MB
|
HyperMemory
= 2304 MB
|
|
1024 MB
graphics memory
|
HyperMemory
= 1280 MB
|
HyperMemory
= 1792 MB
|
HyperMemory
= 2304 MB
|
HyperMemory
= 2816 MB
|
|
2048 MB
graphics memory
|
HyperMemory
= 2304 MB
|
HyperMemory
= 2816 MB
|
HyperMemory
= 3328 MB
|
HyperMemory
= 3840 MB
|
**SKU 11166-06 supports Hyper Memory
Low Power Consumption, Passive Cooling, Noise Free
Sapphire HD5450 Series consumes less 20 Watt power. The passive cooling design is noise free.
Low Profile Bracket Bundled
Sapphire HD5450 Series is bundled with low profile bracket, offering the flexibility to install the card in low profile form factor chassis.
Remark: Please check the board dimension before installing the card in low profile chassis.
Exclusive Software Bundle
A Plug-in For Higher Quality Video and Audio In Video
Conference/Chat.
- Supports MSN, Yahoo Messenger and Skype
- Supports Windows Vista and Windows 7
- Supports ATi Stream
Sapphire HD 5450 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard
- 400 Watt or greater power supply recommended (500 Watt for ATI CrossFireX technology in dual mode)
- Certified power supplies are recommended. Refer to https://ati.amd.com/certifiedPSU for a list of Certified products
- Minimum 1GB of system memory
- Installation software requires CD-ROM drive
- DVD playback requires DVD drive
- Blu-ray playback requires Blu-ray drive
- For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required.
Microsoft DirectX 11 Support
ATI Stream technology**
40nm Process Technology
PCI Express® 2.1 support
Microsoft Windows 7® Support
Enhanced Anisotropic Filtering
Accelerated Video Transcoding**
HDMI 1.3
Dolby® TrueHD and DTSHD Master AudioTM Support
ATI PowerPlay ™ Technology***
ATI Avivo™ Technology Enhanced Unified Video Decoder 2 (UVD 2)***
Supports OpenGL 3.2 ****
ATI CrossFireX™ multi-GPU technology
I/O Output: DL-DVI-I,HDMI,VGA
Core clock: 650MHz
Memory Clock: 800MHz Effective
1024MB / 64-bit DDR2 memory interface
PCI-E x16 (PCI-E 2.1) interface
Single slot passive heatsink
Software CrossFire
Board Dimension: 189mm(W) x 72.9mm(H) x 25(D)mm
11166-14-40R/11166-16-40R bundled with Arcsoft SIM HD IM*
*Arcsoft SIM HD IM is a software plug-in for instant messenger software such as MSN.
