PJD5112 | View Sonic PJD-5112 DLP Portable Projector - SVGA, 2700 Lumens

Digitally clear, dynamic presentations
The PJD5112 is a DLP powerhouse that delivers sharp and bright images for virtually any environment. Its 3D ready with support for up to 120Hz frame rates. BrilliantColor technology produces more vibrant colors, while the high brightness and contrast ratio make this projector shine in the classroom or meeting room. The extensive input options, including two RGB inputs and one RGB output, and integrated 2-watt stereo speakers deliver a truly dynamic multimedia experience. This projector even features closed captioning for the hearing impaired. The PJD5112 is ideal for use at home or in amy small corporate settings.

Bright in virtually any setting with lumens
Packs 2700 ANSI lumens in just 2.66kg(5.86 lb), and with a high 2800:1 contrast ratio (typ), your presentations are guaranteed to be vibrant even in the brightest office environment.

BrilliantColor technology
Latest BrilliantColorTM Technology delivers stunning all-digital clarity with life-like colour, sharp graphics and outstanding video. The sophisticated 6-segment colour wheel enriches the yellow colour performance that is key to accurate and vivid color reproduction.

Closed captioning
Integrated closed captioning decoder for the hearing impaired.

DLP Technology
Stunning all digital clarity delivers lifelike color, sharp graphics, and outstanding video.

Eco-mode extends lamp life
Extend the life of your lamp up to 5000 hours** and reduce noise output.

Off-to-Go feature
The direct off feature allows the busy presenter to simply unplug the projector and go without waiting for the usual cool down phase. This feature also protects lamp life from sudden power blackout.

Model Number: PJD5112

Download datasheet PDF Acrobat Reader required.

LCD		Type		0.55" Digital Micromirror Device(DLP)
		Resolution		800x600, 1600x1200 compressed
		Lens		1.2 Manual optical zoom / Manual optical focus
Display		Size		30 - 300 inch (measured diagonally)
		Throw Distance		1.2 - 10.0m
		Lamp		180watt (RLC-050) / 3500 hour rating
		Brightness		2700 Lumens
		Contrast Ratio		2800:1
		Keystone Correction		Vertical digital keystone correction:+/- 40 degrees
		Aspect Ratio		4:3 (native) & 16:9
Audio		Speakers		2W x 1
Input Signal		Video		NTSC M(3.58MHz), 4.43MHz, PAL(B, D, G, H, I, M, N, 60), SD 480i and 576i(24fps, 25fps and 30fps), ED 480p and 576p(24fps, 25fps and 30fps), HD 720p, 1080i (24fps, 25pfs and 30fps)
		Sync		H/V separated
		Frequency		Fh: 31-100KHz; Fv: 50-120Hz
Compatibility		PC		VGA to UXGA
		Mac		Up to 1152x864 (may require Mac Adapter)
Connector		RGB Input		2 15-pin mini D-sub
		RGB Output		1 15-pin mini D-sub
		Composite Video		1 RCA jack
		S-Video		1 4-pin mini-DIN
		Audio		Input: 2 x 3.5mm mini jack; Output: 1 x 3.5mm mini jack
		Control		1 RS-232 (8 Pin Mini-Din)
Power		Voltage		90~240VAC(Auto Switching), 50 / 60Hz(universal)
		Consumption		235W (Typical) / <1W (Stand-by m
Controls		Basic		POWER, Keystone/ Arrow keys, Left/ BLANK, MENU/ EXIT, Right/ Panel key lock, AUTO, MODE/ ENTER, SOURCE
		OSD		Picture: Brightness, contrast, color setting, keystone, aspect ratio, image, white intensity, gamma, 3D sync, 3D sync invert. Computer Image: Frequency, tracking, H position, V position. Video Image: Saturation, sharpnes, tint. Setting: Menu position, projection, signal type, lamp hour, lamp hour reset, filter mode, filter hours, filter hours reset, power saving, auto source, ECO mode, high altitude, OSD timeout. Advance: Blank screen, password word, screen capture, start up screen, text shot, digital zoom, DCR, close captions, brilliant color,
Operating Conditions		Temperature Humidity		0C - 40C (32F - 104F) 10%-80% (non-condensing)
Dimensions		Physical		280mm (W) x 114mm (H) x 218mm (D)
Weight		Net		2.7 kgs
Regulations				CB, ROHS, WEEE, UL / cUL, FCC-B, ICES-003, NOM, PSB, C-tick, EK, CE, TUV / GOST-R, Hygienic, UKrSEPRO, CCC
