BIPAC5200G RC | Billion BIPAC 5200G RC ADSL2/2+ Modem/Wireless Router - 802.11b/g

All stock codes associated to this product

BIPAC5200GRC, BIPAC5200G RC

Express Internet Access
This router complies with worldwide ADSL standards. It supports downstream rates of up to 12/24 Mbps with ADSL2/2+, 8 Mbps with ADSL, and upstream rates of up to 1 Mbps. With this technology, users enjoy not only high-speed ADSL service but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much more quickly and easily than ever. In particular, by doubling the upstream data rate, the Annex M standard included in the BiPAC 5200G RCA model supports the latest ADSL2/2+ for higher upload speeds.

Wireless Mobility
With an integrated 802.11g Wireless Access Point, the router offers quick and easy access and mobility to the users of wired networks, wireless networks, and broadband connections (ADSL). In addition to supporting the 54 Mbps 802.11g data rate, it is also backward compatible with existing 802.11b equipment. The Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol (WEP) features enhance the level of data protection and access control via a Wireless LAN.

SOHO Firewall Security
Along with the built-in NAT natural firewall feature, the router's advanced anti-hacker pattern-filtering protection feature automatically detects and blocks Denial of Service (DoS) attacks. In addition to the NAT technology, the BiPAC 5200G RC supports Packet Filtering for high-level security control.

Easy Network Management
The Web-based User Interface makes the BiPAC 5200G RC extremely easy for users to install and manage the network. The router supports DHCP client andserver, enabling system administrators to easily fit this security router into existing network environment and manage the IP assignment without re-configuring other stations. Furthermore, future firmware upgrade can be downloaded via the user-friendly Web-based Interface

ADSL Compliance
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available for BiPAC 5200G RCA model only)
Compliant with ADSL2+ Standard
- G.dmt.bis plus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available for BiPAC 5200G RCA model only)

Network Protocols and Features
NAT, static routing and RIP-1/2
NAT supports PAT and multimedia applications
Multi-to-multi NAT
Transparent Bridging
Dynamic Domain Name System (DDNS)
SNTP
DNS relay

Firewall & Virtual Private Network (VPN)
Built-in NAT Firewall
Prevents DoS attacks including Land Attack, Ping of Death,etc.
Anti probe function
Packet filtering
Password protection for system management
VPN pass-through

Wireless LAN
Compliant with IEEE 802.11g and 802.11b standards
2.4 GHz - 2.484 GHz frequency range
Up to 54 Mbps wireless operation rate
64/128-bit WEP supported for encryption
Wireless Security with WPA-PSK/ WPA2-PSK support

ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
OAM F4/F5
ATM QoS: UBR, CBR, VBR-rt, VBR-nrt

Management
Web-based configuration
Firmware upgrades and configuration data upload and download via HTTP/FTP
SNMP v2 MIB supported
Supports DHCP server/client/relay

Operating Environment
Operating temperature: 0 - 40C
Storage temperature: -20 - 70C
Humidity: 20 - 95% non-condensing

Hardware Specifications
Physical Interface
WLAN: fixed Antenna
LINE: ADSL port
LAN: 4-port 10/100M auto-crossover (MDI/MDI-X) switch
Factory default reset button
Power jack
Power switch
Physical Specifications
Dimensions: 7.09" x 4.72" x 1.57 (180mm x 120mm x 40mm)
Power Requirements
Input: 12V AC, 1A

Models & Standards Supported
BiPAC 5200G RCA: Supports Annex A and Annex M
BiPAC 5200G RCU: Supports U-R2 and Annex B
Annex A and Annex M: ADSL over POTS
Annex B and Annex U-R2: ADSL over ISDN
