HCP-1200
HIGH CURRENT PRO SERIES
Elite power meets unrivaled performance
Antec’s HCP-1200 unifies raw power with advanced PSU engineering to meet the demands of high performing PCs. A
full-featured, 80 PLUS® Gold-certified unit, HCP-1200 is capable of outputting 99 percent of its rated power on its eight
+12V rails, which contain high maximum loads to ensure graphics card compatibility. Exclusive to the High Current series,
HCP-1200 boasts High Current heavy-gauge 16 AWG wiring that reduces conducted resistance, increasing efficiency and
improving power delivery. In addition, a cool-running dual double-layer PCB and onboard DC-to-DC converters provide
substantial voltage stability. To experience kilowatt-class power in an unmatched design, pick up Antec’s HCP-1200.
80 mm Pulse Width Modulation (PWM) Fan
with double ball bearing design for quiet airflow
Advanced Hybrid Cable Management
strikes a perfect balance between performance and modularity
Eight +12V rails
ensure high-end CPU and Eight +12V rails ensure high-end CPU and
Continuous Power:
Trust Antec to label all of our power supply units in Continuous Power – the output level that PSU can maintain continuously, rather than the amount delivered at its short-lived peak.
Advanced Hybrid Cable Management:
The HCP series features a heavy-gauge 16 AWG High Current cable to reduce conducted resistance and a modular 8-pin connector for your system’s optimal use.
NVIDIA® SLI®-Ready certified, ATI CrossFireX™ certified:
Only PSUs that successfully pass vigorous testing can be NVIDIA™ SLI™-Ready certified, ensuring a quality user experience.
Features:
1200 watts of Continuous Power
80 PLUS Gold certified - up to 92% efficient
NVIDIA SLI-Ready certified, ATI CrossFire certified
High Current Hybrid Cable Management includes a 8-pin modular connector
Special heavy-gauge 16 AWG High Current cable at CPU reduces conducted resistance, increasing efficiency and improving power delivery
2 x 8-pin CPU connectors included for dual-CPU gaming and server applications
Gold-plated high-current terminals for optimal conductivity
Quiet 80 mm double ball bearing PWM cooling fan
Eight Fully-protected High Current +12V rails with high maximum loads assures graphics card compatibility
Up to 99% power available on +12V rails
DC-to-DC voltage regulator modules ensure stability
Highest quality Japanese brand capacitors ensure long-term reliability
Dual Double-layer PCB optimizes cooling efficiency and allows for heavy-duty components
ATX12V version 2.3 and EPS version 2.92 compliant
Full suite of industrial grade protection:
- Over current protection (OCP)
- Over voltage protection (OVP)
- Short circuit protection (SCP)
- Over power protection (OPP)
- Over thermal protection (OTP)
All cables braided and wrapped for better airflow and neatness
Universal Input - works on any 100V - 240V grid
Active PFC with PF: 0.99
MTBF: 100,000 hours
Meets 2010 EUP requirement: 5Vsb < 1W
AQ5 Antec Quality 5-year limited warranty on parts and labor
Safety: cUL, TUV, CE, CB, FCC, C-TICK, CCC, BSMI, Gost-R
Unit Dimension
- 86 mm (H) x 150 mm (W) x 180 mm (D)
- 3.4" (H) x 5.9" (W) x 7.1" (D)
Package Dimension
- 120 mm (H) x 290 mm (W) x 240 mm (D)
- 4.7" (H) x 11.4" (W) x 9.4" (D)
Weight: 6.5 lbs / 2.9 kg
