All stock codes associated to this product
GUIP20401, GUIP204-01
4-Port USB Sharing Hub
GUIP204
Description
IOGEAR's 4-portUSB Sharing Hub over Network enables any USB external hard drive, USB flash drive, USB memory card reader, USB webcam, USB speaker, or USB multi-function printer (MFP) to be shared on a network among different users. With the versatility afforded by the 4-portUSB Sharing Hub over Network, users can now enjoy their favorite multimedia content stored on their computer from anywhere in their home or office. A user can attach a standard USB webcam to the 4-portUSBSharing Hub over Networkas a simple and low cost security monitoring solution for the home/small office use.
Because the unit includes multi-function printer sharing, any user can print, scan, or fax from any computer in their home. The 4-portUSBSharing Hub over Networkalso supports a USB 2.0 hub extension, which can support 4 USB devices over your home or office IP network. It complies with USB 2.0 specifications, and provides users with an auto-sensing 10/100Base-T port. The print server will even automatically identify your printer make/model upon connection.
When connecting IOGEAR's 4-portUSBSharing Hub over Networkto a wireless router, users can access their multimedia content and USB devices wirelessly.It is a one-stop-shop for multi-functional network peripheral sharingwith anumber of applicationsthat are practically endless.
Note: For Windows 7, please download the latest driver from here.
Features
- Share up to 4 USB devices through your home or office network
- Wirelessly* access USB devices without the USB cable clutter
- A simple way for multiple users to share USB devices
- Works with all wired and wireless routers; supported protocols: LPR/LPD, DHCP, UPnP, WSD
- Supports USB 2.0 and USB 1.1 devices
- Supports Windows Vista Rally Technologies to simplify the setup and maintenance of network-connected devices
*Requires connection to a wireless router
**Supports USB 1.1 webcam
Warranty: 3-YEAR
Function Diagram
Requirements
Requirements
Computer:
- CPU of 1.7GHz and above
- Minimum 512MB RAM
- Windows 2000/XP/Vista
- Available Ethernet port in home/office network
Support Devices:
- Printer or Multi-function printer with USB connection*
- External USB hard drive
- USB speaker*
- USB webcam*
- USB flash drive
- USB memory card reader
- USB printer
- USB scanner
Printer:
- Multi-function printer with USB connection
* Some USB devices require a direct connection for optimum performance
Package Content
- 1 x 4-Port USBSharing Hub over Network
- 1 x Quick Start Guide
- 1 x Installation CD
- 1 x Warranty / Registration card
- 1 x Power Adapter
- 1 x Ethernet Cable
Specifications
| Function |
GUIP204 |
| Operating System Support |
Windows 2000/XP/Vista |
| Network Protocol |
TCP/IP |
| Network Interface |
10/100Mbps RJ45 |
| Printer Connection |
USB 2.0 / backward compatible with USB 1.1 |
| Standards |
IEEE 802.3 10Base-T; IEEE 802.3u 100Base-T; USB 2.0 |
| Management |
Web Interface, Windows Utility |
| Dimensions |
GUIP204 |
| POP Information |
| 10'' Peg Hook |
3 |
| 6'' Peg Hook |
2 |
| Unit Dimensions |
| Width |
5 in. |
| Height |
1 in. |
| Depth |
2.95 in. |
| Inner Pack |
| Width |
9.41 in. |
| Height |
6.81 in. |
| Depth |
8.23 in. |
| Inner Pack Qty. |
3 |
| Unit Package Dimensions |
| Width |
6.34 in. |
| Height |
6.5 in |
| Depth |
3.03 in |
| Master Carton |
| Width |
28.54 in. |
| Height |
10.24 in. |
| Depth |
8.66 in. |
| Master Carton Qty. |
12 |
| Weight |
| Master Carton Wt. |
16.38 lbs |
| Unit Pack Wt. |
1.21 lb |
| Unit Wt. |
0.2 lb |
