IOGEAR GCE500U USB/VGA KVM Console Extender - With Surge Protection - 1xHDB-15-Female, 1xSPHD-17-Female, 2xUSB-A-Female, 1xRJ45-Female - Black

No Longer Available

Part Number:

164789

(?) Brand:

IOGEAR Web Site

Manuf No:

GCE500U-01
GCE500U01

Shipping Weight:

2 KG (Includes product packaging)
Estimate Shipping

Date Added:

16/2/2011

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

GCE500U01, GCE500U-01

USB VGA KVM Console Extender

GCE500U

Description

The IOGEAR USB VGA KVM Console Extender allows access to a PC with USB or USB KVM switch from a remote USB VGA console (VGA monitor, USB keyboard, and USB mouse) via CAT5e/6 cable up to500 feet away.

This unit is perfect for moving the console away from the computer or the KVM switch. Your console can be moved out of the server room to a location that may be more comfortable and quieter. It is also useful for security and monitoring purposes; you can place the unit in a secure area at the same time that you put the console in the most convenient location for user access and monitoring.

An USB VGA KVM Console Extender is a cost effective solution because it uses inexpensive UTP (CAT5e/6) cabling to extend the distance, versus expensive and bulky coaxial cabling. It is easy to install and operate thanks to its Auto Signal Compensation (ASC) technology, which senses the distance and adjusts the signal levels accordingly so there is no need to do any DIP switch setting. It also provides a built-in Application-Specific Integrated Circuit (ASIC) for greater reliability and compatibility

Features

Extend your KVM console (VGA monitor, USB keyboard & mouse) connection up to 500 ft. via CAT5e cables
Auto Signal Compensation (ASC) helps make installation easy, with no need to configure DIP switches
Built-in Application-Specific Integrated Circuit (ASIC) for greater reliability and compatibility
Dual Console Operation - Control your system from either the local or remote console
Built-in 8KV ESD protection and 2KV surge protection
Maximum video resolution up to:
1920 x 1200 @ 60Hz (100 ft. - 30m)
1600 x 1200 @ 60HZ (330 ft. - 100m)
1280 x 1024 @ 60Hz (500 ft. - 150m)
USB over-current detection and prevention
Easy To Operate - Push button selection between local and remote console
Local monitor supports DDC; DDC2; DDC2B
Rack Mountable (rack mount kit included)
Plug-N-Play - No need for any software driver installation

Warranty: 3-YEAR

Function Diagram

Requirements

A Solid CAT5e/6Cable

Console:

VGA, SVGA, SXGA, UXGA, WUXGA or multi-sync monitor
USB keyboard and mouse

Computer:

VGA, SVGA, SXGA, UXGA, WUXGA or multi-sync video output
An available USB port

Package Content

1 x GCE500U Local Unit
1 x GCE500U Remote Unit
2 x Rack Mount Kit
1 xUSB KVM Cable
2x Grounding Wire
2 x Power Adapter
1 x Installation Guide
1 x Warranty Card

Specifications

Function	GCE500U
Console Connectors
Monitor	1 x HDB-15 Female
Keyboard	1 x USB Type A Female
Mouse	1 x USB Type A Female
CPU Connectors
Keyboard, Mouse, and Monitor	1 x SPHD-17 Female (Green)
Unit to Unit Connectors	1 x RJ45 Female
Power Connections	1 x DC Jack
Function Keys	1 x Operating Mode Pushbutton
LEDs
Local	1 x Local; 1 x Remote
Remote	1 x Remote; 1 x Link
Emulation
Keyboard	USB
Mouse	USB
Power Consumption	Local: DC5.3V, 2.31W; Remote: DC5.3V, 2.84W
Power
Voltage	DC5.3V
Amps	0.94A
Video Resolution	Up to 1920x1200@60Hz
Cable Distance	Up to 495ft (150m)
Environment
Operation Temperature	0~50C
Storage Temperature	-20~60C
Humidity	0~80% RH; Non-condensing
Housing
Case	Metal

Dimensions	GCE500U
Unit Dimensions
Width	5in.
Height	1in.
Depth	3.375in.
Unit Package Dimensions
Width	11.25in.
Height	7in.
Depth	4in.
Master Carton
Width	12in.
Height	15.25in.
Depth	12.5in.
Master Carton Qty.	6
Weight
Master Carton Wt.	21.06lb
Unit Pack Wt.	3.28lb
Unit Wt. w/accessories	2.74lb
Unit Wt.	1.41lb
