All stock codes associated to this product
P8H61MLE, P8H61-M LE, MBDASUP8H01H
P8H61-M LE
REV 3.0 - New H61 B3 Revision
Get better graphics with iGPU Boost on H61 platform
Overview
LGA1155 socket for Intel® Second Generation Core™ i7/ Core™ i5/ Core™ i3 Processors
This motherboard supports the Intel® second generation Core™ i7 / Core™ i5 / Core™ i3 processors in LGA1155 package with memory and PCI Express controllers integrated to support 2-channel (2 DIMMs) DDR3 memory and 16 PCI Express 2.0 lanes. This provides great graphics performance. Intel® second generation Core™ i7 / Core™ i5 / Core™ i3 processors are among the most powerful and energy efficient CPUs in the world.
Dual-Channel DDR3 1333 / 1066 support
The motherboard supports DDR3 memory that features data transfer rates of 1333 / 1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet applications. The dual-channel DDR3 architecture enlarges the bandwidth of your system memory to boost system performance.
EPU
Tap into the world’s first real time PC power saving engine through a simple onboard switch or AI Suite II utility. Get total system power savings by automatically detecting current PC loadings and intelligently moderating power consumption. This also reduces fan noise and extends component longevity.
TurboV
[TurboV] Easy, Real-Time O.C. Tunings
Feel the adrenaline rush of real-time OC-now a reality with the ASUS TurboV. This easy OC tool allows you to overclock without exiting or rebooting the OS; and its user-friendly interface makes overclock with just a few clicks away. Moreover, the ASUS OC profiles in TurboV provides the best O.C. settings in different scenarios.
EFI BIOS (EZ Mode)
ASUS brand new EFI BIOS offers a user-friendly interface that goes beyond traditional keyboard BIOS input to enable more flexible and convenient mouse controls. You can easily navigate the new EFI BIOS with the same smoothness as their operating system. The exclusive EZ Mode displays frequently-accessed setup info, while the Advanced Mode is for experienced performance enthusiasts that demand far more intricate system settings.
Intel® H61(B3) Express Chipset
[Intel Chipset Inside] The Intel® H61(B3) Express Chipset is the latest single-chipset design to support the new 1155 socket Intel® Core™ i7 / Core™ i5 / Core™ i3 2nd generation processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability.
Anti-Surge Protection
[Anti-Surge Protection] Protect Your Device Anti-Surge Protection Design detects overvoltage conditions and prevents voltage surges from spreading in real time. It also actively cuts off the overvoltage supply to protect the system.
1. Real-time over voltage detection.
2. Active protection against potential damage to your motherboards and systems.
AI Suite II
[AI Suite II] With its fast user-friendly interface, ASUS AI Suite II consolidates all the exclusive ASUS features into one simple to use software package. It allows you to supervise overclocking, energy management, fan speed control, voltage and sensor readings. This all-in-one software offers diverse and ease to use functions, with no need to switch back and forth between different utilities.
GPU Boost
[GPU Boost] GPU Boost overclocks the integrated GPU in real time for the best graphics performance. User-friendly UI facilitates flexible frequency and voltage adjustments. Its ability to deliver multiple overclocking profiles also provides rapid and stable system-level upgrades.
ErP ready
[ErP ready] The motherboard is European Union´s Energy-related Products (ErP) ready, and ErP requires products to meet certain energy efficiency requirements in regards to energy consumptions. This is in line with ASUS vision of creating environment-friendly and energy-efficient products through product design and innovation to reduce carbon footprint of the product and thus mitigate environmental impacts.
Specifications
| CPU |
Intel Socket 1155 for Intel 2nd Generation Core i7 Processor/Core i5 Processor/Core i3 Processor/
Support Intel 32nm CPU
Supports Intel Turbo Boost Technology 2.0
* The Intel Turbo Boost technology 2.0 support depends on the CPU types.
* Refer to www.asus.com for Intel CPU support list.
|
| Chipset |
Intel H61(B3) Express Chipset |
| Memory |
2 x DIMM, Max. 16 GB, DDR 1333/1066 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* According to Intel SPEC, the Max. 16GB memory capacity can be supported with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available on the market.
* Please refer to www.asus.com or user manual for Memory QVL.
* When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
|
| Expansion Slots |
1 x PCIe 2.0 x16
2 x PCIe 2.0 x1
1 x PCI
|
| VGA |
Dual independent displays support: DVI and D-Sub
Supports Single-link DVI with max. resolution up to 1920x1200 @60Hz
Supports D-Sub with max. resolution up to 2048x1536 @75Hz
Supports Microsoft DirectX 10.1
Intel Quick Sync Video Technology Support |
| Storage |
Intel H61(B3) Express Chipset
4 xSATA 3.0 Gb/s ports |
| LAN |
Realtek 8111E Gigabit LAN controller
|
| Audio |
Realtek ALC887 8-Channel High Definition Audio CODEC
* Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
| USB |
Intel H61(B3) Express Chipset:
- 10 x USB 2.0/1.1 ports (4 ports at the mid-board, 6 ports at the back panel)
|
| ASUS Unique Features |
ESD
GPU Boost
ASUS Anti-Surge Protection
ASUS EPU
ASUS TurboV
ASUS Fan Xpert
ASUS EFI BIOS
ASUS AI Suite II
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2
|
| Back Panel I/O Ports |
1 x PS/2 Keyboard/Mouse Combo port
1 x DVI
1 x D-Sub
1 x LAN(RJ45) port(s)
6 x USB 2.0/1.1
3 x Audio jacks |
| Internal I/O Connectors |
2 x USB 2.0/1.1 connector(s) support additional 4 USB 2.0/1.1 ports
4 x SATA 3.0Gb/s
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x LPT connector
1 x S/PDIF Out connector
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
1 x Front panel audio connector
1 x COM connector
1 x System Panel connector
|
| BIOS |
32 Mb Flash ROM EFI BIOS, PnP, DMI v2.0, WfM 2.0, ACPI v2.0a, SM BIOS v2.6, Multi-language BIOS
|
| Accessories |
User's manual
1 x I/O Shield
2 x SATA 3.0Gb/s
1 x Support DVD |
| Form Factor |
uATX Form Factor
9.6 inch x 8.0 inch ( 24.4 cm x 20.3 cm )
|
LGA1155 socket for Intel Second Generation Core i7/ Core i5/ Core i3 Processors
This motherboard supports the Intel second generation Core i7 / Core i5 / Core i3 processors in LGA1155 package with memory and PCI Express controllers integrated to support 2-channel (2 DIMMs) DDR3 memory and 16 PCI Express 2.0 lanes. This provides great graphics performance. Intel second generation Core i7 / Core i5 / Core i3 processors are among the most powerful and energy efficient CPUs in the world.
Intel H61(B3) Express Chipset
The Intel H61(B3) Express Chipset is the latest single-chipset design to support the new 1155 socket Intel Core i7 / Core i5 / Core i3 2nd generation processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability.
Dual-Channel DDR3 1333 / 1066 support
The motherboard supports DDR3 memory that features data transfer rates of 1333 / 1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet applications. The dual-channel DDR3 architecture enlarges the bandwidth of your system memory to boost system performance.
Anti-Surge Protection
Protect Your Device Anti-Surge Protection Design detects overvoltage conditions and prevents voltage surges from spreading in real time. It also actively cuts off the overvoltage supply to protect the system.
1. Real-time over voltage detection.
2. Active protection against potential damage to your motherboards and systems.
EFI BIOS (EZ Mode)
ASUS brand new EFI BIOS offers a user-friendly interface that goes beyond traditional keyboard BIOS input to enable more flexible and convenient mouse controls. You can easily navigate the new EFI BIOS with the same smoothness as their operating system. The exclusive EZ Mode displays frequently-accessed setup info, while the Advanced Mode is for experienced performance enthusiasts that demand far more intricate system settings.
ErP ready
The motherboard is European Unions Energy-related Products (ErP) ready, and ErP requires products to meet certain energy efficiency requirements in regards to energy consumptions. This is in line with ASUS vision of creating environment-friendly and energy-efficient products through product design and innovation to reduce carbon footprint of the product and thus mitigate environmental impacts.
The product (electrical , electronic equipment, Mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
- All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
- PCB color and bundled software versions are subject to change without notice.
- Brand and product names mentioned are trademarks of their respective companies.
