| CPU |
Intel Socket 1155 for Intel 2nd Generation Core i7 Processor/Core i5 Processor/Core i3 Processor/
Support Intel 32nm CPU
Supports Intel Turbo Boost Technology 2.0
* The Intel Turbo Boost Technology 2.0 support depends on the CPU types.
* Refer to www.asus.com for Intel CPU support list.
|
| Chipset |
Intel H61(B3) Express Chipset |
| Memory |
2 x DIMM, Max. 16 GB, DDR3 1333/1066 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
Supports Intel Extreme Memory Profile (XMP)
* According to Intel SPEC, the Max. 16GB memory capacity can be supported with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available on the market.
* Please refer to www.asus.com or user manual for Memory QVL.
* When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
|
| Expansion Slots |
1 x PCIe 2.0 x16
2 x PCIe 2.0 x1
3 x PCI
|
| Storage |
Intel H61(B3) Express Chipset
4 xSATA 3.0 Gb/s ports |
| LAN |
Realtek 8111E Gigabit LAN
|
| Audio |
ALC887 8-Channel High Definition Audio CODEC
* Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
| USB |
Intel H61(B3) Express Chipset:
- 10 x USB 3.0/2.0 ports (6 ports at mid-board, 4 ports at the back panel)
|
| ASUS Unique Features |
- ASUS Anti-Surge Protection
- ASUS EPU
- ASUS TurboV
- ASUS Fan Xpert
- ASUS EFI BIOS
- ASUS AI Suite II
- ASUS AI charger
- ASUS CrashFree BIOS 3
- ASUS MyLogo 2
- ASUS EZ Flash 2
|
| Overclocking Features |
Precision Tweaker
- vCore: adjustable CPU voltage at 0.01V increment
vCCIO: adjustable I/O voltage at 0.005V increment
- vDRAM Bus: 190-step DRAM voltage control
- vPCH: 190-step chipset voltage control
SFS (Stepless Frequency Selection)
- BCLK/PEG frequency tuning from 80MHz up to 300MHz at 1MHz increment.
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
|
| Special Features |
100% All High-quality Conductive Polymer Capacitors |
| Back Panel I/O Ports |
1 x Parallel port
1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x LAN(RJ45) port(s)
4 x USB 2.0/1.1
1 x COM port
3 x Audio jacks |
| Internal I/O Connectors |
3 x USB 2.0/1.1 connector(s) support additional 6 USB 2.0/1.1 ports
4 x SATA 3.0Gb/s
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x S/PDIF Out connector
1 x 24-pin ATX Power connector
1 x 4-pin ATX Power connector
1 x Speaker Connector
1 x Front panel audio connector
1 x System Panel connector
|
| BIOS |
32 Mb Flash ROM , EFI BIOS, PnP, DMI v2.0, WfM2.0, SMBIOS v2.6, ACPI v2 0a, Multi-language BIOS
|
| Manageability |
WOL by PME,WOR by PME,PXE |
| Accessories |
User's manual
1 x I/O Shield
2 x SATA 3.0Gb/s cables
1 x Support DVD |
| Support Disc |
Drivers
Anti-virus software (OEM version)
ASUS Update
ASUS Utilities
|
| Form Factor |
ATX Form Factor
12 inch x 8 inch ( 30.5 cm x 20.3 cm ) |
