All stock codes associated to this product
SRSA3B, 23SRSA3B
15-Degrees Upward Design
15-degrees upward design creates a more natural listening exprience.
Digital Amplifier
Digital amplifier converst analog signal to short wave in which the pulse width changes in time (PWM = Pulse Width Modulation). Short waves turn FET (Field Effect Transistor) on/off and it integrates the signal and drives speakers.
Compared to analog amplifier, it has a higher efficiency, generates lesser heat and has low consumption of electricity. As it consumes less electricity, it does not require metallic plates to radiate heat, making it an environmental product.
Specifications
General
Speaker System - Full Range Bass Reflex
Speaker System (Satellite) - Magnetically-Shielded
Power Output - 2.5 W + 2.5 W (10 % T.H.D., 1 kHz, 3.2ohms)
Speaker (Diameter) - 46mm
Speaker Impedance - 3.2ohms
Amplifier Impedance - 8 kohms (at 1 kHz)
Input - Connecting cord with stereo mini plug (approx. 1 m) × 1
Power Source - DC 5.2V (supplied AC power adaptor)
Dimensions (W x H x D) - Approx. 85 × 172 × 119 mm
Weight - Approx. 330g (Left), Approx. 310g (Right)
Supplied Accessories - AC power adaptor x 1, Operating Instructions x 1
