All stock codes associated to this product
WS-QV4.0TL/R5-AP, WSQV4.0TL/R5AP, WSQV4.0TL/R5I, WS-QV4.0TL/R5-I, WSQV40TL/R5I, 4981254589601
TeraStation Pro Quad WSS - WS-QVL/R5
4 TB WS-QV4.0TL/R5
Description
TeraStation Pro Quad WSS Storage Server provides high performance four hard drive RAID based network storage with the power of a Windows Server operating system. Powered by Microsoft Windows Storage Server 2008 R2 Workgroup Edition, TeraStation Pro Quad WSS provides seamless capability with Windows computers and servers. The TeraStation Pro Quad WSS incorporates the powerful Intel Atom Dual-Core Processor providing class-leading performance, enabling the ability to focus on concurrent tasks with minimal performance degradation: experience maximum network throughput while a replication job runs in the background or perform fast search indexing while an anti-virus scan is occurring. Additionally, TeraStation Pro Quad WSS supports full disk encryption and support for NTFS for very specific file-level security. Native Active Directory support provides integration with large Windows networks.
Overview
Features
- Intel® Atom™ 1.66 GHz Dual Core / 2 GB RAM
- Windows Storage Server 2008 R2 Workgroup Edition
- iSCSI Target and Initiator
- Front loading hot swap hard drives with lockable front panel
- Active Directory support
- Disk quota (soft quota) support prevents users/groups from consuming too much disk space
- Scheduled shut down eliminates unnecessary access and reduces energy costs
- DFS (Distributed File System),Namespace & Replication support
- Hot swap hard drive trays behind the front panel for easy drive access and replacement
- Improved CPU speed enables faster data transfer
- 10/100/1000 Gigabit Ethernet with Jumbo Frame
- Two Ethernet ports for port trunking and load balancing
- Works with VMware and Hyper-V (SAN storage for Virtual Machines)
- Supported RAID levels: 0, 1, 5, JBOD (Individual Disks)
- BitLocker AES-256 bit hard drive encryption
- Large silent fan cools hard drive efficiently
- Advanced ventilation design reduces internal heat
- LCD Display shows important TeraStation information and disk status
- Windows Server 2008 Server Manager Utility for easy deployment and configuration
- Internet Information Services (IIS) support
- 2 USB 3.0 ports and 2 USB 2.0 ports for external drive, printer and UPS connectivity
- 10 licenses of NovaBACKUP® Business Essentials v12 Included Back up 10 Windows PCs, Windows Servers, Exchange or MS SQL databases
- 3-Year Limited Warranty
Specifications
LAN Interface
| Standard Compliance |
IEEE802.3ab / IEEE802.3u / IEEE802.3 |
| Data Transfer Rates |
10 / 100 / 1000 Mbps |
| Connector Type |
RJ-45 |
| Number of Ports |
2 |
Internal Hard Drives
| Number of Drives |
4 |
| Drive Interface |
SATA 3 Gb/s |
| Supported RAID Levels |
0, 1, 5, JBOD (Individual Disks) |
USB Interface
| Standard Compliance |
USB 3.0 / USB 2.0 |
| Number of Ports |
2 USB 3.0 / 2 USB 2.0 |
| Data Transfer Rates |
Max: 5 Gbps (USB 3.0)
Max: 480 Mbps (USB 2.0) |
Protocol Support
| Networking |
TCP/IP |
| File Sharing |
CIFs/SMB, NFS, IIS, (FTP/FTPS, HTTP/HTTPS) |
| Directory Integration |
LDAP, Active Directory |
| Management |
Remote Desktop Connection (RDP), Terminal Services Client |
| Time Synchronization |
NTP |
Other
| Dimensions (WxHxD in.) |
6.7 x 8.5 x 9.1 |
| Weight (lbs) |
Average 17.6 |
| Operating Environment (Fahrenheit) |
41-95 |
| Setup Utility OS Support |
Windows Operating Systems |
| Client OS Support |
Windows 7 (32-bit/64-bit), Windows Vista (32-bit/64-bit), Windows XP, Windows 2000, Windows Server 2008, Windows Server 2003, Windows 2000 Server |
| Power Supply |
Internal, AC 100-240V 50/60 Hz |
