More Capabilities beyond Plug-and-play Connectivity
The GS108PE ProSafe Plus Gigabit Switch provides your network with reliable, high-speed connectivity. This switch is equipped with 8 10/100/1000 ports, 4 of which are Power over Ethernet (PoE) compliant. It also features a built-in mechanism to prevent loops and broadcast storms, and can prioritize Voice/Video traffic to ensure smooth delivery of time-sensitive data.
NETGEAR's new ProSafe Plus Switches are designed to meet the growing need for easy to use visibility and limited configuration capabilities. To provide more insight into the network behavior, ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally, if there are connectivity issues, these switches offer a cable diagnostic test capability that can identify and even locate problems in the cables.
ProSafe Plus Switches also offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. As a means of improving security or managing collision domains, they also offer VLAN technology.
Delivering great value to the end user, ProSafe Plus Switches offering these monitoring and configuration capabilities at a slight cost premium over un anaged switches.
The GS108PE ProSafe Plus Gigabit Switch provides your network with reliable, high-speed connectivity. This switch is equipped with 8 10/100/1000 ports, 4 of which are Power over Ethernet (PoE) compliant. It also features a built-in mechanism to prevent loops and broadcast storms, and can prioritize Voice/Video traffic to ensure smooth delivery of time-sensitive data.
Additionally, furthering NETGEAR's support of the environment, ProSafe Plus Switches have power-saving Green Ethernet technology. The GS108PE switch comes in a sturdy metal case with a fan-less design for silent operation.
NETGEAR Green
- Up to 60% lower power consumption than the non-Green version
- Auto power-down and cable-length detection for energy savings
- Packaging manufactured with at least 80% recycled materials
Status LEDs
- System: Power, PoE maximum power
- Per Port: Link, activity, speed, PoE active, PoE fault
Power Supply
- Total power consumption: 51.1W maximum
- 802.3af power consumption: 45W maximum (Ports 1-4)
- 48V DC, 1.25A power output; plug is localized to country of sale
Physical Specifications
- Dimensions (H x W x D): 27 x 235 x 103 mm. (1.1 x 9.3 x 4.1 in)
- Weight: 0.716 kg (1.7 lb)
- Network Ports
- Eight (8) auto speed-sensing 10/100/1000 RJ-45 ports
Network Protocol and Standards
- IEEE 802.3i 10BASE-T
- I EEE 802.3u 100BASE-TX
- I EEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.3x flow control
- IEEE 802.3af DTE Power via MDI
Electromagnetic Emissions
- CE mark, commercial
- EN 55022 (CISPR 22) Class A
- FCC Part 15 Class A
- VCCI Class A
- C-Tick
Environmental Specifications
- Operating temperature: 32 to 122 F (0 to 50 C)
- Storage temperature: -4 to 158 F (-20 to 70 C)
- Operating humidity: 90% maximum relative. humidity, non-condensing
- Storage humidity: 95% maximum relative. humidity, non-condensing
- Operating altitude: 10,000 ft (3,000 m) maximum
- Storage altitude: 10,000 ft (3,000 m) maximum
Safety
Performance Specifications
- Forwarding mode: Store-and-forward
- Queue Buffer Memory: 192 KB
- Bandwidth: 16 Gbps (non-blocking)
- Forwarding rate:
- 10 Mbps port: 14,880 packets/sec,
- 100 Mbps port: 148,800 packets/sec,
- 1000 Mbps port: 1,488,000 packets/sec
- Latency: 1000 Mbps to 1000 Mbps: 2.7 is max
- MAC address database: 4K
System Requirements
- Ethernet Category 5 cable
- Network card for each PC
- Microsoft Windows 7, Vista, or XP for running Configuration Utility
Warranty
- Switch: NETGEAR Lifetime Warranty
- Power Supply: NETGEAR 2-year Warranty
Package Contents
- ProSafe Plus 8-port 10/100/1000 Gigabit Switch with 4-port PoE (GS108PE)
- AC adapter
- Wall-mount kit
- Resource CD with configuration utility software
- Installation guide
Features
- Gigabit speed with QoS, VLAN and network monitoring
- Simple network set-up on top of plug-and-play connectivity
- Power-over-Ethernet (PoE) support
- Detects loops and prevents broadcast storm
- NETGEAR Green, power saving features
- VLAN support for traffic separation
- Quality of Service (QoS) prioritizes traffic
- Auto denial-of-service (DoS) prevention
- Network monitoring and bandwidth control
- Troubleshoot connection issues via cable test
- Power up to 4 wireless access points or other PoE-capable devices
- Loop detection
