System |
CPU: Multimedia SoC |
Pan/Tilt/Zoom |
Pan range: 360 continuous rotation Tilt range: 0 ~ 90 flip 18x optical zoom Pan speed: 0.1 ~ 300 / sec Tilt speed: 0.1 ~ 120 / sec Number of presets: 128 Auto pan mode Auto patrol mode
|
Lens |
18x optical zoom f=4.1 ~ 73.8 mm F 1.4 (wide) F 3.0 (tele) Focus range: wide 10 mm,tele 800 mm to infinity auto iris auto focus Removable IR-cut filter for day & night function
|
Angle of View |
2.8 ~ 48 (horizontal)
|
Shutter Time |
1 ~ 1/10,000 sec |
Image sensor |
1/4" SONY EXview HAD CCD |
Minimum Illumination |
0.7 Lux @ F1.4, 50IRE ( typical )
|
Video |
Compression: H.264, MPEG-4 & MJPEG Streaming: Simultaneous multiple streams H.264 streaming over UDP, TCP, HTTP or HTTPS H.264/MPEG-4 multicast streaming MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MJPEG streaming over HTTP or HTTPS Supports activity adaptive streaming for dynamic frame rate control Supports 3GPP mobile surveillance Frame rates: H.264: Up to 60/50 fps at 720x480 (SD8311E) / 720x576 (SD8321E) MPEG-4: Up to 60/50 fps at 720x480 (SD8311E) /720x576 (SD8321E) MJPEG: Up to 60/50 fps at 720x480 (SD8311E) /720x576 (SD8321E) Up to 30/25 fps in WDR mode
|
Image Settings |
Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure AGCAWBAES Automatic, manual or scheduled day/night mode Supports privacy masks BLC (Backlight compensation) WDR Pro |
Audio |
Compression GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law Interface: External microphone input Audio output Supports two-way audio Supports audio mute
|
Networking |
10/100 Mbps Ethernet, RJ-45 ONVIF support Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
Alarm and Event Management |
Triple-window video motion detection 3 D/I & 2 D/O for external sensor and alarm Event notification using HTTP, SMTP, or FTP Local recording of MP4 files Audio detection |
On-board Storage |
SD/SDHC card slot Stores snapshots and video clips
|
Security |
Multi-level user access with password protection IP address filtering HTTPS encrypted data transmission 802.1X port-based authentication for network protection
|
Users |
10 clients on-line monitoring at the same time |
Dimensions |
: 200mm x 270 mm Cable length: 1330 mm Cable diameter: 15 mm; Max Connector: 20 mm |
Weight |
Net: 3400 g |
LED Indicator |
System power and status indicator System activity and network link indicator
|
Power |
24V AC Power consumption: Max. 60 W 802.3at compliant Power-over-Ethernet Plus
|
Housing |
Weather-proof IP66-rated housing
|
Approvals |
CEC-TickFCCLVDVCCI |
Operating Environments |
Temperature: -40C ~ 55C (AC 24V), -10C ~ 55C (PoE Plus) Humidity: 90% RH
|
Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7 Browser: Mozilla Firefox, Internet Explorer 6.x or above Cell phone: 3GPP player Real Player: 10.5 or above Quick Time: 6.5 or above |
Installation, Management, and Maintenance |
Installation Wizard 2 32-CH central management software Supports firmware upgrade
|
Applications |
SDK available for application development and system integration |
Warranty |
24 months |
