| System |
CPU: Multimedia SoC |
| Pan/Tilt/Zoom |
Pan range: 360 continuous rotation
Tilt range: 0 ~ 90 flip
36x optical zoom
Pan speed: 0.1 ~ 300 / sec
Tilt speed: 0.1 ~ 120 / sec
Number of presets: 128
Auto pan mode
Auto patrol mode
|
| Lens |
36x optical zoom
f=3.4 ~ 122.4 mm
F 1.6 (wide)
F 4.5 (tele)
Focus range: wide 10 mm,tele 800 mm to infinity
auto iris
auto focus
Removable IR-cut filter for day & night function
|
| Angle of View |
1.7 ~ 57.8 (horizontal)
|
| Shutter Time |
1 ~ 1/10,000 sec |
| Image sensor |
1/4" SONY EXview HAD CCD |
| Minimum Illumination |
0.01 Lux @ F1.6 ( typical )
0.001 Lux @ F1.6 ( B/W ) |
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 60/50 fps at 720x480 (SD8313E) / 720x576 (SD8323E)
MPEG-4: Up to 60/50 fps at 720x480 (SD8313E) /720x576 (SD8323E)
MJPEG: Up to 60/50 fps at 720x480 (SD8313E) /720x576 (SD8323E)
Up to 30/25 fps in WDR mode
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
EIS (Electronic Image Stabilizer)
WDR Pro |
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
External microphone input
Audio output
Supports two-way audio
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management |
Triple-window video motion detection
3 D/I & 2 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Audio detection |
| On-board Storage |
SD/SDHC card slot
Stores snapshots and video clips
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users |
10 clients on-line monitoring at the same time |
| Dimensions |
: 200mm x 270 mm
Cable length: 1330 mm
Cable diameter: 15 mm; Max Connector: 20 mm |
| Weight |
Net: 3400 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
|
| Power |
24V AC
Power consumption: Max. 60 W
802.3at compliant Power-over-Ethernet Plus
|
| Housing |
Weather-proof IP66-rated housing
|
| Approvals |
CEC-TickFCCLVDVCCI |
| Operating Environments |
Temperature: -40C ~ 55C (AC 24V), -10C ~ 55C (PoE Plus)
Humidity: 90% RH
|
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
24 months |
