| Lens |
f=3.45 mm
F 2.4
Board lens
Fixed
|
| Field of View |
47.4 (horizontal)
30.6 (vertical)
54.7 (diagonal)
|
| Shutter Time |
1/15 ~ 1/25,000 sec |
| Image sensor |
1/4" CMOS in 1280x800 Resolution |
| Minimum Illumination |
3.0 Lux @ F2.4 ( typical )
|
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 30 fps at 1280x800
MPEG-4: Up to 30 fps at 1280x800
MJPEG: Up to 30 fps at 1280x800
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure control
AGCAWBAES
Supports privacy masks
BLC (Backlight compensation)
|
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
Built-in microphone
Built-in speaker
Supports two-way audio
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, FTP
Local recording of MP4 files
Tamper Detection
PIR (Passive Infrared Sensor) for human detection
White-light illuminators for low light condition when event triggered
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
|
| Users |
10 clients on-line monitoring at the same time |
| Weight |
Net: 200 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
Privacy button on
|
| Power |
5V DC
Power consumption: Max. 4.3 W
802.3af Power-over-Ethernet (Class 2)
|
| Approvals |
CEC-TickFCCLVDVCCI |
| Operating Environments |
Temperature: 0 ~ 40 C (32 ~ 104 F )
Humidity: 90%
|
| Viewing System Requirements |
OS: Microsoft Windows 7 / Vista / XP / 2000
Browser: Mozilla Firefox
Browser: Internet Explorer 7.x or above
VLC:10.5 or above
QuickTime:6.5 or above
Cell phone: 3GPP player
Real Player 10.5 or above |
| Installation, Management, and Maintenance |
Installation Wizard 2
32-CH Central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
24 Months |
| Dimensions |
Depth: 32mm
Width: 79mm
Height: 80mm
|
