All stock codes associated to this product
ENP800MC5130, ENP800MC-5130
Specifications:
- Intel Dual-Core 1.8GHz CPU
- 4GB DDR3 RAM
- 2 x Gigabit LAN ports
- 8 x 3.5 SATAII/SATAIII hard disk drives
- 5 x USB ports (front: 1, rear: 4)
- 1 x eSATA port
- LCD panel
- Dimensions: 305 (H) x 175(W) x 245 (D) mm
- Weight: 5.95kg / 13.12lb (without HDD); 12.34kg / 27.21lb (with HDD)
- 250W AC power supply
- Input power voltage: 100V to 240V AC
- Power frequency: 47 - 63Hz
- System fan: 2 x SmartFan (8.0cm, 12V DC)
Protocols
CIFS/SMB, AFP, NFS, FTP, HTTP/HTTPS, iSCSI, SNMP, NDMP, NTP, ICAP
Client Operating System Support
Windows XP, Vista (32/64-bit), Windows 7 (32/64-bit), Windows Server 2003, Windows Server 2008 R2, Apple Mac OS X, Linux, Red Hat, SuSE
Server Virtualization
- VMware vSphere
- Citrix XenServer
- Windows Server 2008 Hyper-V
File System
- Internal: ZFS
- External: FAT32, NTFS
Networking
- IPv6 support
- Fixed or dynamic IP address
- Dual Gigabit Ethernet with Jumbo Frame
- Port trunking/NIC teaming/Link aggregation (IEEE 802.3ad)
- DHCP Client
- MPIO, MC/S support
Security
- HTTPS connection
- Encrypted remote replication (rsync over 128-bit SSH)
- CHAP authentication for iSCSI volumes
RAID and Volume Management
- RAID0/1/5/5+Hot spare/6/6+Hot spare/10/50/60
- Online and automatic RAID capacity expansion
- Deduplication
- Inline and block-level
- Compression
- Thin provisioning (iSCSI volumes only)
- SPC-3 Persistent Reservation (iSCSI volumes only)
- ICAP-based anti-virus support
Power Management
- Wake on LAN
- Network UPS with SNMP management
Access Right Management
- User account management
- Group management
- Folder management
- Folder and subfolder access control
- Folder quota
- Comprehensive access control action items
- All Controls, Read, Read and Run, Write, Modify, List
- Support Windows Active Directory Authentication
- Domain Users Login via CIFS/ SMB, AFP, FTP, and file explorer
System Management
- Web-based GUI
- HTTP/HTTPS connections
- Email alerts
- SNMP traps
- System status monitoring
- Exportable event logs
- System settings backup and restore
- LCD quick initialization
- System migration
- Time synchronization with the NTP server
Data Protection
- ZFS end-to-end data integrity
- Detects and automatically heals silent data corruption
- Snapshot
- Unlimited number
- For both shared folders and iSCSI volumes
- Scheduling at intervals as short as 10 minutes
- Automatic snapshot copy pruning based on user-configured policy
- Remote Replication
- Rsync with 128-bit SSH encryption
- Pool mirror
- Remote data mirroring
- Real-time or scheduled
- IPsec encryption
- ICAP-based anti-virus support
Browser Support
- Internet Explorer 7 &8
- Firefox 3
File Server
- Protocols: CIFS/SMB, AFP, NFS, FTP, HTTP/HTTPS
- Client operating system: Windows, Mac OS, Linux
- File/folder management by web browser
FTP Server
- Max. concurrent connection control
- Max. failed log-in attempt control
Backup Server
- Apple Time Machine support
- Windows Backup and Recovery support
- Bundled free licenses for FarStone TotalRecovery Pro 7
- 8 licenses per system
- Backup to external storage devices via USB or eSATA connection
- USB one-touch-copy (Import/Export)
- Remote replication
- Rsync with 128-bit SSH encryption
- 3rd-party backup software support
