All stock codes associated to this product
VISIONHT321B, VISION HT 321B, SYSASRI3302N
Vision HT Series
Vision HT 321B
- IntelMobile Ivy Bridge Processor
- Mobile IntelHM77 Express chipset
- Multi VGA Output options : HDMI, DVI-I and D-Sub by the bundled DVI to D-Sub adapter
- HDMI audio pass through (Dolby TrueHD & DTS-HD Master Audio)
- Supports Blu-ray disc S3D content via HDMI 1.4a
- 7.1 CH HD Audio with THX TruStudio
- 4 x USB3.0, 4-in-1 Card reader (SD3.0/MMC/MS/MS PRO)
- 2T2R 802.11 a/b/g/n (5GHz/2.4GHz Dual-Band access)
- Bluetooth 4.0/3.0 HS class II
- Supports ASRock XFast RAM, XFast LAN, XFast USB, Dehumidifier, UEFI System Browser, OMG, Internet Flash
- Supports IntelSmart Connect, IntelRapid Start
- Free Bundle : CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX Multimedia Suite
Product Introduction
Play
Fantastic gaming experience you've always wanted!
Leisure
Hear the perfect audio quality.
Work
Redefine your office. Do your daily tasks more efficiently.
Entertainment
Experience the absolutely realistic Blu-ray 3D display.
Features
IntelMobile Ivy Bridge Processor
The worlds first 22nm 3-D transistors from Intelthat ensure lower power consumption, amazing multitasking performance and stunning visuals.
Intel® HD Graphics Built-in Visuals
Intel® HD Graphics is built into the processor and delivers superior mainstream gaming and 3D experiences – without the need for a discrete graphics card.
Stunning 3D Visuals
Enjoy 3D games/movies/photos in stunning HD quality. Become the scene stealer in your favorite games with amazing stereoscopic 3D gaming image quality that puts you in the heart of it all. Feeling like you are a part of the action has never been more exciting or more comfortable.
Bitstream
With HDMI 1.4a, it supports Bitstream / audio pass through (Dolby TrueHD and DTS HD Master audio)
BD Combo
Designed with BD Combo, Vision HT HTPC Series allow you to enjoy the dazzling audio and visual experience with Blu-ray discs.
RAID
RAID 0 mode offers even faster data transfer speed, RAID 1 mode can duplicate the documents to avoid working disruption. With RAID support, users are assured to enjoy a speedy and safe working environment.
THX TruStudio™
Vision HT HTPC Series use sophisticated audio processing technology to deliver a 7.1 CH surround sound with THX TruStudio™, so you can be sure to hear the best sound quality.
Bluetooth 4.0
Bluetooth v4.0 standard features Smart Ready technology that adds a whole new class of functionality into the mobile devices including Apple's most recent iPhone 4S. BT 4.0 also includes Low Energy Technology and ensures extraordinary low power consumption for PCs.
2T2R WiFi 802.11 a/b/g/n (Dual Band)
Double your wireless performance and bandwidth with simultaneous 2.4GHz and 5GHz bands speed up to 300Mbps concurrently. Optimized 2T2R WiFi 802.11 a/b/g/n connectivity standards offer maximum broadband network.
mSATA
mSATA connector can be used to connect a Solid-State Drive (SSD) for an internal storage device. Coupled with SSD and HDD, users are able to take advantage of Intel® Smart Response Technology and enjoy SSD caching performance from ASRock HTPC solution.
XFast 555
ASRock unique XFast 555 Technology (XFast RAM, XFast LAN, and XFast USB) features 5X performance boost in terms of system’s overall performance, LAN speed and USB transfer speed.
ASRock OMG (Online Management Guard)
Fast, Easy and Free – ASRock OMG technology allows you to establish an internet curfew or restrict internet access at specified times. Administrators are able to schedule the starting and ending hours of internet access granted to other users. Normally, ISPs (Internet Service Provider) will charge for internet curfew service. The service controls “all” the PCs connected at home through network remotely but all the PCs in that network will be restricted to access the internet at pre-setup times. However, ASRock OMG is a free tool for controlling internet access of each single PC. Parents can easily control internet access through BIOS setup to protect their kids from using Internet at inappropriate time, and meanwhile, enjoy their own internet space.
Internet Flash
Internet Flash searches for available UEFI firmware updates from ASRock servers. System can auto-detect the latest UEFI from our servers and flash them within UEFI setup without entering Windows® OS.
Intel® Smart Response
Intel® Smart Response Technology accelerates the system response experience by putting frequently-used blocks of disk data on a solid-state drive (SSD), providing dramatically faster access to user data than the hard disk alone can provide. For users who are tempted to connect the SSD and HDD on ASRock HTPC, Intel® Smart Response Technology can make the SSD become the "Cache of the HDD" to boost up the HDD access speed. ASRock HTPC with Intel® Smart Response Technology are able to drive 4X faster performance boost than a HDD-only system.
Intel® Rapid Start
Intel® Rapid Start Technology gets your device up and running faster from even the deepest sleep, saving time and battery life. It quickly returns where you left off with a PC that goes from deep-sleep to full awake in a flash. The ultra-responsive capability gives your device the power to quickly resume to Windows® 7 OS within few seconds and ensures ultra-low power consumption when on standby. With Intel® Rapid Start Technology, users can jump right back into everything they were doing!
Intel® Smart Connect
Intel® Smart Connect Technology keeps content always up-to-date! It means that your email, favorite apps, and social networks are continually and automatically updated even when the system is asleep. Smart Connect will periodically wake up the PC while in a sleep state and check updates for things like email, Twitter, Facebook, etc. No more waiting for the latest world news or friends’ updates to be delivered—just enable this function and you’re up-to-date and ready to go.
Specifications:
Vision HT 321B |
CPU |
- Intel Core i5-3210M Mobile Ivy Bridge Processor - Supports 3rd Generation Intel Core i7 / i5 / i3 Mobile Ivy Bridge Processor Family - Supports Intel Turbo Boost 2.0 Technology - Supports Hyper-Threading Technology |
OS |
- Microsoft Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit compliant |
Chipset |
- Mobile Intel HM77 Express chipset - Supports Intel Rapid Start Technology and Smart Connect Technology
**Intel Rapid Start Technology and Smart Connect Technology are only supported under Windows 7 OS or later versions
|
Memory |
- 4GB DDR3-1600MHz (2x2GB) - Supports DDR3 1600/1333/1066 MHz, 2 x SO-DIMM slots, Max. up to 16GB*
*Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
|
VGA |
- Intel HD Graphics 4000 - Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video 2.0, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider.
*Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows Vista and Windows 7. ** Intel InTru 3D is only supported under Windows 7 and Windows 7 x64.
|
HDD |
- 750GB, Supports second 2.5" SATA HDD |
mSATA |
- Supports mSATA SSD |
ODD |
- BD Combo |
Front I/O |
- 2 x USB 3.0, 1 x MIC, 1 x Headphone, 4-in-1 Card reader (SD3.0/MMC/MS/MS PRO) |
Rear I/O |
- 1 x HDMI 1.4a, 1 x DVI-I, 4 x USB 2.0, 1 x S/PDIF, 1 x eSATA2, 2 x USB 3.0 |
LAN |
- Gigabit LAN |
Sound |
- 7.1 CH HD Audio with THX TruStudio |
WiFi |
- 2T2R 802.11 a/b/g/n (5GHz/2.4GHz Dual-Band access) |
Bluetooth |
- Bluetooth 4.0/3.0 HS class II |
Remote Controller |
- MCE Remote Controller |
Power Unit |
- 90W/19V Adapter |
Dimension |
- 200mm(W) x 70mm(H) x 200mm(L) |
Volume (liters) |
- 2.8L |
Certifications |
- CE / FCC / CB / BSMI / WHQL - ErP/EuP Ready |
