All stock codes associated to this product
ENP500MC5130, ENP500MC-5130
Specifications:
Intel Dual-Core 1.8GHz CPU
4GB DDR3 RAM
2 x Gigabit LAN ports
5 x 3.5” SATAII/SATAIII hard disk drives
5 x USB ports (front: 1, rear: 4)
1 x eSATA port
LCD panel
Dimensions: 220(H) x 175(W) x 245(D) mm
Sound Level:
Power Saving Mode: 35.7dB
Operating Mode: 35.9dB
Weight: 5.00kg / 11.02lb (without HDD); 9.00kg / 19.84lb (with HDD)
250W AC power supply
Input power voltage: 100V to 240V AC
Power frequency: 47 - 63Hz
System fan: 1 x SmartFan (9.2cm, 12V DC)
Protocols
CIFS/SMB, AFP, NFS, FTP, HTTP/HTTPS, iSCSI, SNMP, NDMP, NTP, ICAP
Client Operating System Support
Windows XP, Vista (32/64-bit), Windows 7 (32/64-bit), Windows Server 2003, Windows Server 2008 R2, Apple Mac OS X, Linux, Red Hat, SuSE
Server Virtualization
VMware vSphere
Citrix XenServer
Windows Server 2008 Hyper-V
File System
Internal: ZFS
External: FAT32, NTFS
Networking
IPv6 support
Fixed or dynamic IP address
Dual Gigabit Ethernet with Jumbo Frame
Port trunking/NIC teaming/Link aggregation (IEEE 802.3ad)
DHCP Client
MPIO, MC/S support
Security
HTTPS connection
Encrypted remote replication (rsync over 128-bit SSH)
CHAP authentication for iSCSI volumes
RAID and Volume Management
RAID0/1/5/5 + Hot spare/6/6+ Hot spare/10
Online and automatic RAID capacity expansion
Deduplication
Inline and block-level
Compression
Thin provisioning (iSCSI volumes only)
SPC-3 Persistent Reservation (iSCSI volumes only)
ICAP-based anti-virus support
Power Management
Wake on LAN
Network UPS with SNMP management
Access Right Management
User account management
Group management
Folder management
Folder and subfolder access control
Folder quota
Comprehensive access control action items
All Controls, Read, Read and Run, Write, Modify, List
Support Windows Active Directory Authentication
Domain Users Login via CIFS/ SMB, AFP, FTP, and file explorer
System Management
Web-based GUI
HTTP/HTTPS connections
Email alerts
SNMP traps
System status monitoring
Exportable event logs
System settings backup and restore
LCD quick initialization
System migration
Time synchronization with the NTP server
Data Protection
ZFS end-to-end data integrity
Detects and automatically heals silent data corruption
Snapshot
Unlimited number
For both shared folders and iSCSI volumes
Scheduling at intervals as short as 10 minutes
Automatic snapshot copy pruning based on user-configured policy
Remote Replication
Rsync with 128-bit SSH encryption
Pool mirror
Remote data mirroring
Real-time or scheduled
IPsec encryption
ICAP-based anti-virus support
Browser Support
Internet Explorer 7 &8
Firefox 3
File Server
Protocols: CIFS/SMB, AFP, NFS, FTP, HTTP/HTTPS
Client operating system: Windows, Mac OS, Linux
File/folder management by web browser
FTP Server
Max. concurrent connection control
Max. failed log-in attempt control
Backup Server
Apple Time Machine support
Windows Backup and Recovery support
Bundled free licenses for FarStone TotalRecovery Pro 7
5 licenses per system
Backup to external storage devices via USB or eSATA connection
USB one-touch-copy (Import/Export)
Remote replication
Rsync with 128-bit SSH encryption
3rd-party backup software support
