Powerline 500M / Homeplug AV Wall Plug Gigabit Ethernet Adapter
Enables high-speed Internet applications throughout your home Simply plug the adapter into any wall power socket, using your homes existing electrical wiring to create or extend a network. Compliant with the IEEE1901 & HomePlug AV standards, which support high speeds of up to 500Mbps, the BiPAC 2075 enables seamless high-definition media streaming, intense online gaming, and jitter-free VoIP calling throughout your home. Another unique feature is supporting superior and noise-immune data transmission over electrical wire. Even at the moment your family turns on or off any other electronic device, you wont experience any interruption to latency-sensitive applications such as multimedia or video being shared with your family in another room.
Key Features
- Provides physical layer data rate of up to 500Mbps over existing in-home power lines
- Supports Gigabit / Fast Ethernet wired connection
- IEEE1901 and HomePlug AV Compliant
- European Union’s Energy-using Products (EuP) Directive compliant
- Utilizes power line technology that takes advantage of the unused bandwidth of the electrical wiring in your home
- Smart power saving technology for improved power efficiency
- Utilizes Quality of Service control
- Supports Triple Play applications such as IPTV, VoIP and high-speed Internet access
- Ideal for residential users
Benefits
Using existing wiring to create in-home network
The BiPAC 2075 transmits bandwidth intensive data easily and securely over the existing electrical wiring without installation effort. It is also ideal for homes or small offices where concrete walls, successive floors in multi-storied buildings could inhibit a wireless signal. Just one touch of the Sync button to install the bridge utility and your high-speed network is ready. Its as easy as simply plugging in your networking devices and using the electrical wiring in your home.
Smooth HD streaming and prioritization
With increased speeds of up to 500Mbps and utilizing QoS technology, BiPAC 2075 is ideal for streaming HD video, intense online gaming, and VoIP calling. Quality of Service (QoS) control guarantees the transmission quality by automatically prioritizing data. The BiPAC 2075 automatically recognizes the bandwidth needs of voice and video applications. QoS prioritizes the data to guarantee optimal transmission quality. TV and video images are received and displayed with absolute smoothness. QoS also guarantees the clear, instant reproduction of voice data, even when other applications are running on the network at the same time.
Reduce energy consumption
With the Smart Power Saving feature, the BiPAC 2075 can automatically detect its Ethernet connection. When the Ethernet-based device is powered down or disconnected, the BiPAC 2075 adapter will automatically fall into sleep mode, which reduces power consumption significantly. In full operation mode, the adapter can reduce its power consumption and save money on your electricity bill. Create a Green home and enjoy energy efficiency!
Specifications
Protocols
TDMA, CSMA/CA
Standards
Ethernet specifications: IEEE 802.3, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ab Auto MDI/MDIX
IEEE1901 and HomePlug AV compliant
European Unions Energy-using Products (EuP) Directive
European Code of Conduct (CoC) on Energy Efficiency
Transmission Speed
500Mbps max.
Modulation
Supports OFDM
4096/1024/256/64/16/8 QAM, QPSK, BPSK and ROBO
Frequency Range
2MHz ~ 70MHz
Security
128-bit AES Link Encryption with key management for secure power line communications
Encryption: NMK (Network Membership Key) used to authenticate/access
Rotating NEK (Network Encryption Key)
Quality of Service Control
Enhancements: contention-free access, four-level priority based contention access, and multi segment bursting
ToS, CoS and IP Port Number Packet Classifiers
Supports IGMP managed multicast sessions
IGMP snooping with multicast to multiple unicast support in CSMA
QoS classification for quasi-error-free delivery - VLAN priority field, ToS Field
Enhanced IPv4/IGMPv1-3 snooping support
Supports IPv6 and MLDv1-2 snooping
Supported Operating Systems
Windows 98 / 98SE / Me / 2000 / XP / Vista / 7
Device Port
Ethernet RJ-45
Other 10/100/1000 Base-T Ethernet devices
Power Supply Specifications
Input: 100~240V AC, 50~60Hz
Protection: OCP, OVP, SCP
Smart Power Saving (* depends on input power voltage)
Up to 80% power reduction in standby mode
Power consumption < 1W in standby mode
Hardware Specifications
Physical Interface
AC power plug
RJ-45 Giga Ethernet
Sync button
Reset button
LED display:
POWER
PLC
ETH
Physical Specifications
Dimensions (W, D, H): 3.63 x 2.41 x 1.73 (93mm x 62mm x 44mm)
Operating Environment
Operating temperature: 0 ~ 40 C
Storage temperature: -20 ~ 70 C
Humidity: 20 ~ 95% non-condensing
Available Product Package
BiPAC P108
Powerline 500M / Homeplug AV Gigabit Ethernet Starter Kit
includes 2 x BiPAC 2075
