All stock codes associated to this product
ST1000NC001, 2145434, 763649040980, 7636490039539
Constellation CS Hard Drive
CAPACITY
1TB
SECURITY OPTION
None
Model Number: ST1000NC001
Overview
Affordable, high-capacity, energy-efficient enterprise HDD.
Low-cost bulk storage designed for vast amounts of unstructured data in the cloud.
- Affordable storage for 247 cloud data center replicated environments
- Maximizes storage footprint with capacities up to 3TB for 114TB per square foot
- Energy-efficient at under 8 watts (random read operating power) which averages 29% less than competing hard drives
- Reliable enterprise rotational vibration tolerance and bad block management
- Seagate Instant Secure Erase for secure, easy and cost-effective drive disposal or repurposing
Affordable high-capacity storage for the cloud.
Seagate Constellation CS is the industrys first capacity-optimized hard drive thats perfect for cloud bulk storage.
Priced to fit your growing need for vast amounts of unstructured data storage with its 1, 2 and 3TB models, its the lowest $/GB enterprise-class hard drive on the market.
Energy-efficient, enterprise-class cloud storage.
With the Constellation CS and its low-power envelope, you can rest easier knowing your hard drives are running cool. Plus, with Seagate® PowerChoice™ technology, you can save even more.
Reduce storage costs over the long term.
Maximize ROI with Seagate Instant Secure Erase.
The Constellation CS with a Self-Encrypting Drive (SED) option and Seagate Instant Secure Erase reduces IT hard drive retirement costs. As required—and with a single keystroke—you can quickly and easily render the data on the drive completely unreadable and secure.
Features:
Capacity to grow on.
Constellation CS hard drives feature the highest capacities to meet the needs of scaleable burst performance in cloud infrastructures.
- 1, 2 and 3TB models
- 7200-RPM performance
- SATA 6Gb/s interface
Reliable, low-power and cost-effective storage.
Constellation CS hard drives feature consistent performance with low-power usage for the most economical means of storing exabytes of unstructured data in the cloud.
- Enterprise-ready RV tolerance for multi-drive systems
- Bad-block management (BBM)
- Lowest power usage in a 3.5-inch form factor
- 3-year limited warranty
Secure and easy drive disposal.
Lower Total Cost of Ownership (TCO) with Seagate Instant Secure Erase technology for drive retirement or disposal.
- Every day, thousands of terabytes of data leave data centers as old systems are retired
- Seagate's Instant Secure Erase feature renders all data on the hard drive unreadable in a matter of seconds versus hours
Specifications:
Capacity |
3TB |
2TB |
1TB |
|
|
Form Factor |
3.5" |
3.5" |
3.5" |
Interface Options |
SATA 6Gb/s |
SATA 6Gb/s |
SATA 6Gb/s |
Performance |
|
|
|
Spindle Speed (RPM) |
7200 |
7200 |
7200 |
Cache (MB) |
64 |
64 |
64 |
Transfer Rate, Max Ext (MB/s) |
600 |
600 |
600 |
Sustained Data Rate OD |
180MB/s |
180MB/s |
180MB/s |
Average Latency (ms) |
4.16 |
4.16 |
4.16 |
Reliability/Data Integrity |
|
|
|
Nonrecoverable Read Errors per Bits Read |
1in 1014 |
1in 1014 |
1in 1014 |
Annualized Failure Rate (AFR) |
1.065% |
1.065% |
1.065% |
Power Management |
|
|
|
Idle, Typical Operating (W) |
0.34 |
0.34 |
0.34 |
Environmental |
|
|
|
Temperature |
|
|
|
Operating |
5to60C |
5to60C |
5to60C |
Non-operating |
-40to70C |
-40to70C |
-40to70C |
Shock |
|
|
|
Operating: Gs (ms) |
70 / 40(2ms) |
70 / 40(2ms) |
70 / 40(2ms) |
Non-operating: Gs (ms) |
300(2ms) |
300(2ms) |
350(2ms) |
Acoustics (bels - sound power) |
|
|
|
Idle |
2.5 |
2.4 |
2.2 |
Operating |
2.5 |
2.4 |
2.2 |
Physical |
|
|
|
Height (in/mm) (maximum) |
1.028/26.10 |
1.028/26.10 |
0.7825/20.17 |
Width (in/mm) (maximum) |
4.010/101.85 |
4.010/101.85 |
4.010/101.85 |
Length (in/mm) (maximum) |
5.787/147.00 |
5.787/147.00 |
5.787/147.00 |
Weight (lb/g) |
1.38/626 |
1.18/535 |
0.88/400 |
ST1000NC001 |
1TB |
SATA 6Gb/s |
64MB |
7200RPM |
1.065% |
20.17mm |
101.85mm |
147.00mm |
60C |
625 |
7.79W |
