Shuttle DS47 Slim PC Barebone
Celeron 847(1.10GHz), 2xDDR3-SODIMM, 2xSATA, 1xSD Card Reader, DVI, HDMI, 2xGigLAN, HD-Audio
NO O/S

No Longer Available

Part Number:

221524

(?) Brand:

Shuttle Web Site

Manuf No:

DS47

Shipping Weight:

2.5 KG (Includes product packaging)
Estimate Shipping

Date Added:

21/5/2013

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

DS47

DS47

Features

Full HD Digital Signage Solution

Shuttle’s DS47 is an ultra slim but energy efficient for Full HD digital signage platform, built-in RS232/RS422/RS485, USB 2.0&3.0 and dual Gigabit-LAN dedicated interfaces, you can easily connect a variety of peripherals. The DS47 is equipped with Intel® high-performance Celeron dual-core processor, provides HDMI, DVI-I output interface, support dual display function; the exclusive integration of low-power design and fan-less cooling, body thickness of less than 40mm, only use 65W external power supply to keep system long time operation, and compared with traditional PC can also be reduced by nearly 40% noise. Customers can have lower energy consumption and reliable silent system for their digital signage solution.

Application: Digital Signage, POS (Point-of-Sales), KIOSK, Education, Medical, Automation, Office computers, thin client and call center

Support Full HD video format

Shuttle DS47 is equipped with Intel high-performance Celeron 847 1.10 GHz dual-core processor, built-in Intel HD Graphics, memory support up to DDR3-1333 16GB capacity, can play a variety of Full-HD/ 1080 P high definition video format content.

Multiple I/O interfaces

Shuttle DS47 built-in RS232/RS422/RS485 dedicated interface, four USB 2.0 ports at the front panel, and two USB3.0 ports at the rear panel can easily connect to peripherals such as thermal printer, label printer and bar code scanner. It offers a wide range of vertical applications.

Fanless Design

The DS47 uses ideal cooling thermal module with cooled heat pipes that can transmit heat to the whole cooling module quickly and evenly. It can be achieved high cooling efficiency without cooling fans. Combined with precisely vent design, the waste heat inside the computer can be moved out quickly.

Dual display support

The DS47 provides HDMI and DVI-I dual display output interfaces, built-in Intel HD graphics, greatly upgrade digital signage display quality.

VESA Mount Capability

The compact body of the DS47 has multiple screw holes specially designed on the side of the body. This design not only complies with international VESA Mount Standards, but also allows users to choose the most appropriate back hanging configuration and placement under different environments. This space saving capability is well-suited for application of digital signage with limited space.

Dual Gigabit LAN high connectivity

The DS47 has built-in Realtek 8111G dual LAN, supports 10Mb/s, 100 Mb/s, 1000 Mb/s high-speed transfer capacity, and Wake On LAN function; built-in IEEE 802.11b/g/n wireless network card, the maximum transmission rate of up to 300 Mbps. It significantly enhances the digital signage system data transfer efficiency and save the operating time.

24/7 nonstop operation

Shuttle DS47 is officially approved for 24/7 permanent operation. Thanks to Shuttle’s low power consumption design and provide a stable operating environment, this PC runs highly reliable making it perfectly suitable for digital signage or other vertical applications.

Energy-saving

The exclusive integration low-power design and fan-less cooling, the DS47 consumes only 65W of power in full use and can keep stable for long-time operation; Compared with traditional PCs, a nearly 40% noise reduction during the operation, it is particularly suited for noise sensitive environment such as hospitals and libraries.

Specifications:

FORM FACTOR	200 x 165 x 39.5 mm
PROCESSOR	Intel Celeron 847 dual core CPU
CHIPSET	Intel NM70 Express chipset
MEMORY	2 x 204 pin DDR3 SODIMM slots,8GB per DIMM (Max 16GB) Dual Channel DDR3 1333 Mhz
VGA	DVI-I + HDMI dual display
AUDIO	Realtek ALC662 channel High Definition Audio
ETHERNET	Realtek 8111G X2 IEEE 802.3u 100Base-T specification revision 1.0 100Mb/s and 1Gb/s operation Support Wake-On-LAN function
STORAGE INTERFACE	3.0Gb/s bandwidth SATA II
ONBOARD CONNECTORS	(2) SATA connectors (1) SATA power connector (1) LVDS connector (1) LPC header (1) 4pin fan connector (1) 3pin fan connector (1) Clear COMS header
FRONT PANEL	(1) Power on button (1) Power LED (1) HDD LED (4) USB 2.0 ports (1) RS232/RS422/RS485 (1) RS232 (1) SD Card reader
BACK PANEL	(2) RJ45 Gigabit LAN port (1) DVI-I port (1) HDMI port (2) USB 3.0 ports (1) MIC in (1) Line out (1) External power on header (1) Clear CMOS (1) DC in (1) Kensinton lock (2) Wireless Antenna fixture
DRIVE BAYS	(1) 2.5" HDD / SSD bay
DIMENSIONS	190(L) x 165(W) x 43(H) mm
POWER	65W Power Adapter Input:100- 240V AC Output: 19V 4.47A DC
EXPANSION SLOT	(1) Full size Mini-PCIE socket (m-SATA support) (1) Half size Mini-PCIE socket for WLAN module
OS SUPPORT	Windows XP Windows 7 Windows 8 Linux
