Intel Pentium G3460 Dual Core CPU (3.50GHz, 350GHz-1.1GHz GPU) - LGA1150, 5.0 GT/s DMI, 3MB Cache, 22nm, 53W

IMG 1 of 1
No Longer Available
Part Number:
402647
(?) Brand:
Intel Web Site
Manuf No:
BX80646G3460
Shipping Weight:
0.5 KG (Includes product packaging)
Estimate Shipping
Date Added:
1/12/2015
Details Files Images & Video
All stock codes associated to this product
BX80646G3460

Intel® Pentium® Processor G3460
(3M Cache, 3.50 GHz)

Specifications

Essentials
Status Launched
Launch Date Q3'14
Processor Number G3460
Intel® Smart Cache 3 MB
DMI2 5 GT/s
Instruction Set 64-bit
Instruction Set Extensions SSE4.1/4.2
Embedded Options Available
No
Lithography 22 nm
Scalability 1S Only
Thermal Solution Specification PCG 2013C
Conflict Free Yes
Performance
# of Cores 2
# of Threads 2
Processor Base Frequency 3.5 GHz
TDP 53 W
Memory Specifications
Max Memory Size (dependent on memory type) 32 GB
Memory Types DDR3-1333/1600, DDR3L-1333/1600 @ 1.5V
Max # of Memory Channels 2
Max Memory Bandwidth 25.6 GB/s
ECC Memory Supported ‡
Yes
Graphics Specifications
Processor Graphics ‡ Intel® HD Graphics
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 1.1 GHz
Graphics Video Max Memory 1.7 GB
Graphics Output eDP/DP/HDMI/DVI/VGA
Max Resolution (HDMI 1.4)‡ 1920x1080@60Hz
Max Resolution (DP)‡ 2560x1600@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ 2560x1600@60Hz
Max Resolution (VGA)‡ 1920x1200@60Hz
DirectX* Support 11.1
OpenGL* Support 4.0
Intel® Quick Sync Video
Yes
Intel® Wireless Display
Yes
# of Displays Supported ‡ 3
Expansion Options
PCI Express Revision Up to 3.0
PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes 16
Package Specifications
Max CPU Configuration  1
TCASE 72°C
Package Size 37.5mm x 37.5mm
Graphics and IMC Lithography 22 nm
Sockets Supported FCLGA1150
Low Halogen Options Available See MDDS
Intel® Data Protection Technology
Intel® AES New Instructions
No
Secure Key Yes
Intel® Platform Protection Technology
Trusted Execution Technology ‡
No
Execute Disable Bit ‡ Yes


No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Intel) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
