Netcomm NP285 Turbo Homeplug Ethernet Over Power

Netcomm NB285 Turbo Charged Ethernet Over Power Adaptor

• Share a broadband Internet connection to any room with a power point ? at turbo speeds

• Establish or extend an Ethernet LAN using power wires

• Connect any Ethernet device

• Plug into wall or power board

• Connect a gaming console to the Internet for on-line gaming

• Maximum data carrier rate 85Mbps

• Range up to 200 metres



Utilising existing cable structure on your premise - Saving you from running new data cables, all its require is two flyleads - one for each adaptor.



Examples of Application for NP285



PROTOCOL/STANDARDS
HomePlug 1.0 specification, IEEE 802.3 10/100 Ethernet (10 Mbps) and IEEE 802.3u Fast Ethernet Compliant (100 Mbps)
Integrated Physical Layer (PHY) and Media Access Controller (MAC)
10/100 Mbps AutoMDI/MDIx support
85 Mbps HomePlug 1.0 compatible

MODULATION SUPPORT
OFDM 256/64/16, DQPSK, DBPSK and ROBO Modulation Scheme QUALITY OF SERVICE
Forward Error Correction (FEC) support
Channel Adaptation ensures that signal integrity is maintained even under harsh noise environment
CSMA/CA with prioritisation and Automatic Repeat Request (ARQ) for reliable delivery of Ethernet packets via Packet Encapsulation
Four Level prioritised random access method
Segment bursting and contention-free access ensures high throughput while maintaining low latency response and jitter performance

FREQUENCY BAND
4.3MHz ~ 20.9MHz

SECURITY SUPPORT
56-bit DES Encryption with key management for secure powerline communications (use Windows platform to enable encryption)

PLATFORM SUPPORT
Windows 98SE, ME, 2000 or XP
OS Independent with TCP/IP protocol installed

POWER SUPPLY
Switch Mode 90v ~ 240v

LED INDICATORS
1 x Power LED
1 x Powerline Activity Status LED
1 x Ethernet Link/Activity Status LED

EXTERNAL CONNECTORS
1 x Electrical Power plugs
1 x RJ45 for 10/100 Ethernet (AutoMDI/MDI-X)
