| Processor: |
Intel Core2 Quad, Core2 Extreme, Core2 Duo, Pentium EE, Pentium D, Pentium 4, Celeron D processors, Socket T (LGA775)
|
| Chipset: |
Intel 975X + Intel ICH7R |
| Front Side Bus: |
1066 / 800 / 533 MHz FSB |
| Memory: |
Dual channel DDR2 800 (OC) / 667 /533 x 4 DIMMs/ECC, Max 8GB |
| VGA on Die: |
N/A |
| Expansion Slots: |
2 x PCIe x16 slots ( dual graphics cards technology compatible ), 2 x PCIe x1 slots, 2 x PCI slots |
| IDE: |
1 x ATA 133, 1 x ATA 100
(To advance IDE transfer speed, you may install JMicron IDE-SATA RAID Drive. You can download the drive by clicking the "drive" icon at the left side.) |
| Serial ATA(SATA)/RAID: |
4 x SATAII + 1 x eSATA w / RAID 0, 1, 0+1, 5 |
| Audio: |
7.1 channel, Realtek ALC 882M (HDA) |
| LAN: |
Dual GbE LAN with Marvell 88E8056 |
| IEEE1394: |
2 x 1394a, TI TSB43AB22APDT ( one pin header and one rear port) |
| Back Panel I/O Ports: |
1 set 7.1 channel Audio jack (6 jacks)
1 x 1394a
1 x PS/2 keyboard
1 x PS/2 mouse
1 x parallel
1 x External SATA
4 x USB 2.0
2 x RJ45
1 x S/PDIF Coaxial out
1 x S/PDIF Fibre out |
| Internal I/O Connectors: |
2 x USB 2.0 headers support 4 ports
1 x Front audio header
1 x S/PDIF out header
1 x IrDA header
1 x CD-IN header
1 x AUX-IN header
1 x Front panel header
1 x Buzzer
1 x COM2
1 x IEEE 1394a
1 x speaker |
| BIOS Features: |
FWH 4MB, ACPI 2.0b, APM 1.2, PnP 1.0a, SMBIOS 2.3, USB 2.0 |
| Support CD: |
Drivers, DirectX, Adobe Reader, Super Utility, Norton Internet Security |
| Standards/Manageability: |
PCI 2.3, USB2.0, DMI 2.0 |
| Special Features: |
SuperRecovery, SuperBoot,SuperBIOS-Protect, SuperStep, Fox Live Update, Ratio Free, Fox Intelligent Stepping, Fox One |
| Form Factor: |
ATX (12 x 9.6) |
