Gigabyte GA-MA790FX-DQ6 Motherboard
AM2+, 790FX, HT 4000, 4x DDR2-1066, 4x PCI-Ex16 v2.0, 6x SATA-II, 2x eSATA, RAID, 2x GigLAN, 8Chl, Firewire, ATX


Large image is available
Product May Vary From Image

Our Price:Discontinued

Techbuy Part No:77430
Usually Ships: No Longer Available Details
Brand:Gigabyte Web Site
Manuf No:GA-MA790FX-DQ6
 GAMA790FXDQ6
Shipping Weight:2.5 KG How Much?
Date Added:25/10/2007
Rating: Not Rated
Currency:AUD Convert

Product Description

GA-MA790FX-DQ6 (rev. 1.0)
  1. Supports AMD AM2+ Phenom/ AM2 Athlon 64 series processors
  2. Dual Channel DDR2 1066* memory support for remarkable system performance
  3. Quad PCI-E 2.0 x16 graphics interfaces with ATI CrossFireX support for extreme gaming performance
  4. Integrated SATA 3Gb/s with RAID function and IEEE 1394a connection
  5. Integrated dual LAN with Teaming function to provide twice bandwidth of transmission speed
  6. High quality 8-ch ALC889A High Definition audio with DTS Connect support, featuring 106dB Signal to Noise Ratio and Full Rate Lossless Audio with Blu-ray/ HD DVD playback support.
  7. Ultra Durable 2 motherboard features High Quality CPU Power design with Ferrite core chokes, Low RDS (on) MOSFET and Solid Capacitors.
  8. Durable Capacitors that take advantage of Japanese manufactured SMD (Surface Mount Device) Solid Capacitors for enhanced system durability.
  9. Re-engineered Thermal Design featuring All Copper Silent-Pipe and Crazy Cool
  10. External SATA2 design makes you to enjoy your life
* Whether 1066 MHz memory speed is supported depends on the CPU being used, please refer "Memory Support List" for memory support information.
/images/P77430-I19.jpg
Overview

  Introduction
The GA-MA790FX-DQ6 is GIGABYTE's next generation, high performance platform based on the new AMD 790FX Chipset and support for the new AMD Phenom quad-core processors, with the latest AM2+ platform support, integrated DDR2 1066 memory controller, HyperTransport 3.0 technology links and 128-bit Floating Point Units. The GIGABYTE GA-MA790FX-DQ6 also features support for PCI Express 2.0 as well as ATI CrossFireX with dual x16, or four x8 connectivity for the ultimate gaming experience. In addition to setting new records for blistering performance, the GA-MA790FX-DQ6 is part of the GIGABYTE Ultra Durable 2 series of motherboards, featuring top quality electronic components which provide optimized power savings, ultra cooling and extended system durability.
    Ultra Durable 2 -Designed with Top Quality Highly Efficient Components

Ultra Durable 2

Ultra Cooling - Low RDS(on) MOSFET Design
Low RDS(on) MOSFETs specially designed to produce lower switching resistance for faster electric current charging and discharging.
Ultra Cooling

Low Power Loss - Ferrite Core Choke Design
Ferrite core chokes comprised of a compound of iron oxide and other metal elements whose properties hold energy much longer than common iron core at high frequency.
Low Power Loss






Longer Life - All-Solid Capacitor Design
Solid capacitors contain a solid organic polymer, while electrolytic capacitors use a common liquid electrolyte, hence, the terms solid capacitor versus electrolytic capacitors.
Longer Life
  AMD Live Ready
AMD Live Ready Requirement compliant.
  Windows Vista Premium Logo Certified
Windows Vista Premium promises to deliver a streamlined computing experience designed to fundamentally change how users view, find and organize their digital information. With GIGABYTE AM2+/ AM2 solutions enabling support for Vista Premium, GIGABYTE offers a fresh and unique desktop experience that will be more informative, intuitive and completely new.
  AMD Phenom processors
The leading-edge performance and unparallel technology of AMD AM2+ Phenom processors have built its strength on the well-known AMD64 framework which consisted next generation of HyperTransport 3.0 Technology, and integrated DDR2 1066 memory controller, and 128-bit Floating Point Units. The AMD Phenom processors are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments to offer significant performance boosts and provides an overall more energy efficient platform.
  AMD 790FX Chipset
The AMD 790FX Chipset is the system logic of the latest AM2+ (HyperTransport 3.0) platform from AMD that enables its next generation Phenom processors with the leading CrossFireX solution. The AMD 790FX Chipset, with optimized next generation of PCI-E 2.0 graphics capabilities, providing outstanding quality and performance for every PC users. Confidently manage and back-up precious digital files, surf the Internet faster, and play the latest games with technology designed today and ready for tomorrow.
  Dual Channel DDR2 1066* MHz
Experience the advanced technology of DDR2 1066* memory, featuring faster speeds and higher data bandwidth, which delivers superior performance for the most demanding applications.
* Whether 1066 MHz memory speed is supported depends on the CPU being used, please refer Memory Support List for memory support information.
  PCI-E 2.0 Graphics Interface
PCI-E 2.0 doubles the bus standard's bandwidth from 2.5 Gbit/s to 5 Gbit/s, meaning a x32 connector can transfer data at up to 16 GB/s in each direction. PCI-E 2.0 also features improvements to the point-to-point data transfer protocol and its software architecture.
  ATI CrossFireX support
With support for latest ATI CrossFireX technology, GIGABYTE pushes the envelope once again by delivering highly optimized performance and flexibility demanded by power users and extreme gaming enthusiasts. Designed to provide unmatched multi-GPU support with Quad PCI-E connectivity, the GA-MA790FX-DQ6 allows users to take advantage of the ultra smooth 3D rendering, blazing-fast frame rates and enhanced visual quality possible with a dual graphics card solution.
  SATA 3Gb/s storage interface
The SATA specification doubles bus bandwidth from 1.5Gb/s to 3Gb/s. Native Command Queuing is a new specification that enables out-of-order execution of commands for efficient retrieval of data. Hot Plug support allows users to insert and remove hard disk drives without shutting off power to the system.
  IEEE1394 motherboard
This motherboard comes with IEEE1394 FireWire interface from Texas Instruments (TI). With the transfer speed up to 400Mb/s, the new generation IEEE1394 interface further enhances PC connectivity with consumer electronics audio/video (A/V) appliances, and storage peripherals.
    ALC889A with DTS Connect Enables a Superior Audio Experience



Excellent Audio Performance
High-performance DAC (Digital-Analog Converter) with 106 dB Signal-to-Noise ratio playback quality, designed especially for Windows Vista Premium PCs.



Blu-ray/HD DVD Full Rate Audio Support
The ALC889A enables high quality Full Rate Lossless Audio for content protected media and support for both Blu-ray and HD DVD formats for an exhilarating home theater entertainment experience.

7.1+2 Channel High Definition Output
The ALC889A provides support for 7.1 sound playback, plus 2 channels of independent stereo output (multiple streaming) through the front panel stereo outputs.
  Dual Gigabit LAN with Teaming
The dual Gigabit LAN with Teaming function allows the 2 single network connections to act as one for twice the bandwidth, further to improve overall throughput with lower CPU utilization and also provide new generation connectivity for the broadband era. It is able to prevent network downtime by transferring the workload from a failed port to a working port.
  Quad-Core Optimized
GIGABYTE has implemented optimized Quad-Core system bus routing on latest AMD AM2+ platform and a Quad-Double phase power design to ensure the highest levels of performance and stability from multi-core processors, including the next generation AMD Phenom processors, providing the highest levels of performance for multi-tasking applications.
  Quad BIOS
Quad BIOS is a feature unique to GIGABYTE that includes DualBIOS and Xpress BIOS Rescue Technology. This combination delivers a safety assurance mechanism that sports a total of 4 copies of BIOS distributed between the Flash ROM, hard-disk and driver CD. This feature helps to reduce the affects of virus attacks or firmware damage and provides multi-layer BIOS protection that assures greater PC platform stability.How does Quad BIOS work?
  Quad Cooling
This revolutionary cooling design combines Crazy Cool and Silent-Pipe technology that includes heat sinks covering MOSFET modules, the north bridge and the south bridge. Additionally, the Crazy Cool enhances heat dissipation of the rear side of CPU and north bridge of the motherboard. Quad Cooling allows users to enjoy longer component lifetime through lower temperatures and absolute silence combined with the ultimate thermal performance on chipsets, CPU power components and the PCB.
  Quad CrossFire Ready
Supports ATI CrossFireX Technology, true dual PCI-E 2.0 x16 or four PCI-E 2.0 x8 connectivity for up to 2 or 4 latest ATI CrossFireX VGA cards, providing flawlessly smooth 3D video rendering and screaming frame rates.
  Quad Double Phase
An exclusive feature found only on GIGABYTE motherboards, this unique design incorporates Virtual 8 Power Phases to deliver steadier power and immediate current to the CPU and memory during heavy system workloads or overclocking. Additionally, the Quad-Double Phase power design helps decrease the working temperatures, enhancing system stability and increasing component lifespan.
  Quad e-SATA2
Four sets of external SATA ports based on the Serial ATA 3Gb/s storage specification allow effortless sharing and transfer of entertainment content and digital media on external devices. Designed for external SATA devices, Quad eSATA 2 delivers enhanced scalability and double the bus bandwidth for high-speed data retrieval and saving On-The-Go.
  Silent-Pipe
The revolutionary Silent-Pipe Technology compliant GIGABYTE motherboards featuring 0dB soundless heat-pipe thermal cooling solution, convergence with GIGABYTE Crazy Cool Technology, enhances heat dissipation efficiency from the critical Chipsets and CPU power components.
  Speed
The Speed compliant motherboards of GIGABYTE S-series provide intelligent over-clocking and over-voltage software settings through both hardware and software design.
  Smart
The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!.
  Safe
Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!.

Specifications
Processor
  1. Support for Socket AM2+/ AM2 processors: AMD PhenomFX processor/ AMD Phenom processor/ AMD Athlon 64 FX processor/AMD Athlon 64 X2 Dual-Core processor/AMD Athlon 64 processor/AMD Sempron processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
  1. 4000/2000 MT/s
Chipset
  1. North Bridge: AMD 790FX
  2. South Bridge: AMD SB600
Memory
  1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory (Note 1)
  2. Dual channel memory architecture
  3. Support for DDR2 1066(Note 2)/800/667 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio
  1. Realtek ALC889A codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel
  4. Support for DTS (dts NEO:PC)
  5. Support for S/PDIF In/Out
  6. Support for CD In
LAN
  1. Realtek 8111B chip (10/100/1000 Mbit)
Expansion Slots
  1. 2 x PCI Express x16 slots (PCIE_16_A, PCIE_16_B) supporting ATI CrossFireX technology (Note 3) (The PCI Express x16 slots conform to PCI Express 2.0 standard.)
  2. 2 x PCI Express x8 slots (PCIE_8_A, PCIE_8_B) supporting ATI CrossFireX technology
  3. 1 x PCI Express x1 slot
  4. 2 x PCI slots
Storage Interface South Bridge:
  1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
  2. 4 x SATA 3Gb/s connectors (SATAII0, SATAII1, SATAII2, SATAII3) supporting up to 4 SATA 3Gb/s devices
  3. Support for SATA RAID 0, RAID 1 and RAID 0+1
2 x GIGABYTE SATA2 chip:
  1. 2 x SATA 3Gb/s connectors (GSATAII_1, GSATAII_2) supporting up to 2 SATA 3Gb/s devices
  2. 2 x eSATA 3Gb/s ports on the back panel supporting up to 2 SATA 3Gb/s devices
  3. Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8718 chip:
  1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394a T.I. TSB43AB23 chip
  1. Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a bracket connected to the internal IEEE 1394a headers)
USB Integrated in the South Bridge
  1. Up to 10 USB 2.0/1.1 ports (6 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x 4-pin PCIe 12V power connector
  4. 1 x floppy disk drive connector
  5. 1 x IDE connector
  6. 6 x SATA 3Gb/s connectors
  7. 1 x CPU fan header
  8. 2 x system fan headers
  9. 1 x power fan header
  10. 1 x North Bridge fan header
  11. 1 x front panel header
  12. 1 x front panel audio header
  13. 1 x CD In connector
  14. 1 x S/PDIF In header
  15. 1 x S/PDIF Out header
  16. 2 x USB 2.0/1.1 headers
  17. 2 x IEEE 1394a headers
  18. 1 x parallel port header
  19. 1 x power LED header
  20. 1 x chassis intrusion header
Rear Panel I/O
  1. 1 x PS/2 keyboard port
  2. 1 x PS/2 mouse port
  3. 1 x serial port
  4. 1 x coaxial S/PDIF Out connector
  5. 1 x optical S/PDIF Out connector
  6. 6 x USB 2.0/1.1 ports
  7. 1 x IEEE 1394a ports
  8. 2 x RJ-45 port
  9. 2 x eSATA 3Gb/s ports
  10. 6 audio jacks (Line In / Line Out / MIC In/Surround Speaker Out (Rear Speaker Out) / Center / Subwoofer Speaker Out / Side Speaker Out)
I/O
  1. iTE IT8718 chip
H/W Monitoring System voltage detection
  1. CPU/System temperature detection
  2. CPU/System/Power fan speed detection
  3. CPU overheating warning
  4. CPU/System/Power fan fail warning
  5. CPUfan speed control
BIOS
  1. 2 x 4 Mbit flash
  2. Use of licensed AWARD BIOS
  3. Support for Dual BIOS
  4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Download Center
  3. Support for Q-Flash
  4. Support for EasyTune (Note 4)
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for Virtual Dual BIOS
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft Windows Vista/XP/2000
Form Factor
  1. ATX Form Factor; 30.5cm x 24.4cm
Overclocking Voltage adjustments in BIOS Setup (CPU/DDR2/Chipset/PCIE/FSB/HTT/HTR) allow you to:
  1. Increase CPU voltage (Note 5)
  2. Increase DDR2 voltage by 0.05V to 0.50V with 0.05V increment
  3. Increase Chipset voltage by 0.05V to 0.40V with 0.05V increment
  4. Increase PCI Express voltage by 0.05V to 0.45V with 0.05V increment
  5. Increase FSB voltage by 0.05V to 0.35V with 0.05V increment
  6. Increase HTT voltage by 0.05V to 0.40V with 0.05V increment
  7. Increase HTR voltage by 0.05V to 0.45V with 0.05V increment
Frequency adjustments in BIOS Setup (CPU/HT Link/PCIE/DDR2) allow you to:
  1. Adjust CPU host frequency from 200 MHz to 500 MHz with 1 MHz increment
  2. Adjust HT Link frequency
  3. Adjust PCI Express frequency from 100 MHz to 200 MHz with 1 MHz increment
  4. Adjust DDR2 frequency
Remark (Note 1) Due to Windows XP 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) Whether 1066 MHz memory speed is supported depends on the CPU being used.
(Note 3) If you are installing one or two PCI Express graphics card(s), be sure to install it/them in the PCIE_16_A or/and PCIE_16_B slot(s) for optimum performance. When four graphics cards are installed, the PCIE_16_A and PCIE_16_B slots will operate at up to x8 mode.
(Note 4) Available functions in Easytune may differ by motherboard model.
(Note 5) The adjustable CPU voltage range depends on the CPU being used.


* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.

* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.


Product Warranty


3-year Manufact.
