Features |
|
Eight 1-inch, front-access, HDD trays |
Flexibility and Compatibility |
Complies with Intel DP Xeon/ DP AMD Opteron sever boards |
|
Ultra320 SCSI backplane (4 x HDDs per backplane, option) |
|
Support 1 x front access USB port |
Validated Thermal Solutions |
Two 80 mm, rear-mounted fans for optimal heat dissipation(option) |
|
Optimized HDD interspaces maximize inlet air ow |
System Monitoring |
Buzzer alarm for fan failure and overheat warning |
|
Reset switch to disable audible warning |
Application References |
Media/Streaming Server |
|
Mobile Internet Service System |
|
Corporate files servers, DB/File Server |
|
Data retention and archives |
|
Video-on-Demand |
|
Security and surveillance systems |
Specification |
M/B form factor |
Extended ATX (12" 13") |
CPU Type |
DP Xeon/DP Opteron Processors |
Dimension (DxWxH) |
mm: 660 422 132 |
|
inch: 26" 16.9" 5.2" |
Drive Bays |
External: 5.25": 2 , 3.5": 1 |
|
HDD Trays:8 |
Backplane |
8 Ports SCSI(option) |
PSU |
Form Factor:Single or Redundant |
Switches/ Controls |
Power ON/OFF, HDD/LAN Activity, Fan Failure and Overheat Warning |
Indicators |
Power ON/OFF, Alarm Reset, System Reset |
Slot Openings |
7 |
Cooling Fan |
Standard: 4 x 80 mm (T=32) middle fans |
|
Optional: 2 x 80 mm (T=25) rear fans |
Construction Material |
SGCC |
Sheet Metal Thickness |
1.2 mm |
|
