Technical Specifications
|
| General |
 |
| Feature |
Description |
| Engine |
Mono Laser |
| Paper size |
LTR, LGL, A4, B5, A5, B6, A6, EXE |
| Input / output max width |
Min Input of ADF: 148(W)x100(L)mm Max Input of ADF: 216(W)x356(L)mm Max Input of Glass Bed: No Flatbed Min Output of cut sheet feeder/cassette: 70(W)x116(L)mm Max Output of cut sheet feeder/cassette: 216(W)x406(L)mm |
| ADF (Automatic Document Feeder) |
Up to 20 sheets |
| Standard paper tray capacity |
Up to 250 sheets |
| Optional paper tray capacity |
No |
| Standard memory capacity |
16MB (RAM) |
| Optional memory |
No |
| Memory security |
No |
| LCD size |
1 line of 16 characters |
| On-screen programming |
Yes |
| Station ID |
Yes (20digits / 20characters) |
|
| Fax |
 |
| Feature |
Description |
| Fax modem speed |
33,600bps (Fax) |
| Transmission speed |
Approx 2 seconds (Brother1,MMR) |
| Quick scan |
Approx 3.5 sec/page@A4 |
| ITU-T Group compatibility |
Super G3 |
| Data compressions code |
MH / MR / MMR |
| Dual Access |
Yes |
| Memory transmission |
Up to 500 pages (ITU-T) |
| Out of paper reception |
Up to 500 pages (ITU-T Test Chart) |
| Super fine |
Yes (Send & Receive) |
| Grey scale |
64 levels |
| Contrast |
Auto/Light/Dark |
| One touch dials |
20 (10 x 2) locations |
| Speed dials |
200 Locations |
| Broadcasting |
Up to 270 locations |
| Group dials |
Up to 8 Groups |
| Navigator keys |
Yes |
| Telstra FaxStream Duet compatibility |
Yes |
| Automatic FAX/TEL switch |
Yes |
| Automatic redial |
Yes |
| ECM |
Yes |
| Delayed timer |
Up to 50 |
| Polling type |
Yes (Secure Polling) |
| Batch transmission |
Yes |
| Automatic reduction |
Yes |
| Fax forwarding |
Yes |
| Fax retrieval |
Yes |
| Chain dialling |
Yes |
| Enhance remote activation |
Yes |
| Remote access |
Yes |
| Speaker/ring volume adjustment |
3 steps OFF |
|
| Copier |
 |
| Feature |
Description |
| Copier speed |
Up to 14cpm |
| Digital copier multi stack |
Up to 99 copies |
| Digital copier multi sort |
Yes |
| Digital copier enlargement/ reduction ratio |
50%-200% in 1% increments |
| 2-in-1 / 4-in-1 |
Yes |
| 1-in 3 x 3 |
No |
|
| Telephone |
 |
| Feature |
Description |
| Handset |
Detachable |
| Telephone index |
Yes (with ? key) |
| Full Duplex Digital Speaker Phone |
No |
|
| Digital Answering Machine |
 |
| Feature |
Description |
| Digital answering machine |
No |
| Recording time |
No |
|
| List / Report |
 |
| Feature |
Description |
| Journal report |
Up to 200 |
| Transmission verification report |
Yes |
| Cover page list |
Yes (Super) |
| Help list |
Yes |
| Quick dial list |
Yes |
|
| Interface |
 |
| Feature |
Description |
| External TAD interface |
Socket Only |
| PC interface |
USB 2.0 @ Full-Speed |
|
| Weight and Measures |
 |
| Feature |
Description |
| Dimension sizes |
374(W) x 374(D) x 262(H)mm |
| Dimension weight |
7.25 kg without consumables |
| Power consumption |
Peak:1032W or less Stand by: 80W or less Sleep: 10W or less |
|
* Subject to change without prior notice. |
