 Full 22" viewable widescreen with 1680x1050 resolution
Fast ClearMotiv II video response
Video response as fast as 2ms enables digital HD broadcast-quality video.
4000:1 dynamic contrast ratio (typ)
Provides for darker black levels and better overall front-of-screen performance.
Stylish slim-bezel design
The thin bezel lets you see more without taking up valuable desktop real estate. The high neck and fl oating head design accentuate the visual experience.
OptiSync digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and analog (VGA) signals for ultimate compatibility and confi guration fl exibility.
Amplified Impulse
Advanced amplified impulse technology accelerates grayscale transitions for superior video and gaming.
OnView controls for superior screen adjustability
Screen adjustments are precisely made via an easy-to-use on-screen menu.
4:3Pull down
Both wide and 4:3 signals are popular for this moment, and the screen also need to provide suitable display area to enjoy. After the display ratio adjustment, perfect images will be played in front of all audiences.
Windows Vista approved
PC and Mac compatible
TCO '03 and ENERGY STAR qualified
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
22" Wide Color TFT Active Matrix LCD |
| |
|
Display Area |
|
22 inch |
| |
|
True Resolution |
|
1680x1050 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 4000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 horizontal, 160 vertical (CR>10) |
| |
|
Response Time |
|
2ms |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating(3H) |
|
| Input Signal |
|
Analog |
|
RGB Analog(75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Digital |
|
DVI-D (with HDCP) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~75Hz |
| |
|
Sync |
|
H/V separated (TTL), composite, sync-on-green |
|
| Compatibility |
|
PC |
|
VGA up to 1680 X 1050 non-interlaced |
| |
|
Mac |
|
Power Mac, up to 1680 X 1050 non-interlaced |
|
| Connector |
|
Analog |
|
15 pin mini D-sub X 1 |
| |
|
Digital |
|
DVI-D |
| |
|
Power |
|
3-pin AC plug (CEE22) |
|
| Power |
|
Voltage |
|
100-240VAC; 50/60Hz (Switch) |
| |
|
Consumption |
|
38W (typ) |
|
| Controls |
|
Basic |
|
Power, 1, down, up, 2 |
| |
|
OSD |
|
Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch color adjust (sRGB, 9300K, 7500K, 6500Kdefault, 5400K, user color-RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number), manual image adjust (H. size, H. position, V. position, fine tune, sharpness, dynamic contrast, aspect ratio, response time), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0C - 40C (32F - 104F)
10% - 90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
509mm(W) x 431mm(H) x 225mm(D) |
|
| Weight |
|
Net |
|
5.0 Kgs |
|
| Regulations |
|
|
|
UL, cUL, FCC-B, CB, CE, ENERGY STAR, NOM, NEMKO/GS (covers TUV/GS), NEMKO ERGO (covers TUV/ERGO, ISO 13406-2 & MPR II), TCO'03, GOST-R +20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, Argentina-S, Green Mark, RoHS, EPEAT-Silver |
|
| Power Management |
|
|
|
Meet VESA ( 100mm X 100mm ) Standards |
* VESA wall mount sold separately. |
|
