 OptiColor technology
Delivers 98% color saturation for richer, more precise colors. Enjoy more intense colors in your graphics, photos and documents
ClearMotiv II 2ms video response
Ultra-fast video response enables digital, HD broadcast-quality video.
2000:1 dynamic contrast ratio
Provides for darker black levels and better overall front-of-screen performance.
Pivot, height and wall-mount versatility
VESA wall-mount interface and detachable base for ergonomic flexibility with pivot,* height, tilt and 120o swivel adjustments.
PerfectSuite Plus control software
Professional-grade LCD control software featuring color calibration, asset management, theft deterrence, and auto screen rotation.*
Full 19" viewable screen with 1280X1024 resolution
Multiple analog / digital inputs and integrated USB hub expand your connectivity
Certified for Windows Vista
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
Color TFT Active Matrix LCD |
| |
|
Display Area |
|
19 inch |
| |
|
True Resolution |
|
1280x1024 |
| |
|
Contrast Ratio |
|
800:1 (typ), 2000:1 (DCR) |
| |
|
Brightness |
|
280 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 horizontal, 160 vertical @ contrast ratio 10:1 |
| |
|
Response Time |
|
2ms (G to G) |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating(3H) |
|
| Input Signal |
|
Analog |
|
RGB Analog(75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Digital |
|
DVI-D (HDCP) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~85Hz |
| |
|
Sync |
|
H/V separated (TTL), composite, sync-on-green |
|
| Compatibility |
|
PC |
|
VGA up to 1280x1024 non-interlaced |
| |
|
Mac |
|
Power Mac, up to 1280x1024 non-interlaced |
|
| Connector |
|
Analog |
|
15 pin mini D-sub X 1 |
| |
|
Digital |
|
DVI-D |
| |
|
USB |
|
V2.0, 1-up / 4-down |
| |
|
Power |
|
3-pin AC plug (CEE22) |
|
| Power |
|
Voltage |
|
100-240VAC; 50/60 Hz (Switch) |
| |
|
Consumption |
|
32W (typ) |
|
| Controls |
|
Basic |
|
Power, 2, up, down, 1 |
| |
|
OSD |
|
Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch color adjust (sRGB, 9300K, 7500K, 6500K default, 5000K, user color-RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number), manual image adjust (H. size, H. position, V. position, fine tune, sharpness, dynamic contrast, display mode, response time), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background, OSD pivot), memory recall |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0 C - 40 C (32F - 104F)
10-90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
412.2mm(W) x 390.7mm(H) x 278.5mm(D) |
|
| Weight |
|
Net |
|
5.6 Kgs |
|
| Regulations |
|
|
|
UL, cUL, FCC-B (ICES), CB, CE, TCO03, ICES-003B, ISO 13406-2, TUV/GS, TUV ERGO (covers ISO 13406-2 & MPR II), TUVS, NOM, GOST-R, HYGIENIC, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS, EPEAT-Silver |
|
| Power Management |
|
|
|
Meets TCO'03 and RoHS standards |
* VESA wall mount sold separately. |
|
