Synology DS107+ Disk Station - 500MHz CPU
  • 1x 3.5" SATA HDD, Windows ADS, USB2.0, eSATA, GigLAN

IMG 1 of 1
No Longer Available
Part Number:
85625
(?) Brand:
Synology Web Site
Manuf No:
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
, DS107+(128MB), DS-107+ (128MB)


DS107+
Ultra-high-performance 1-bay SATA NAS Server with Windows ADS Authentication for Small Businesses and Corporations

DS107+ is designed with Windows ADS authentication, USB printer sharing, dynamic website hosting, and data backup. The ultra-high-performance file sharing capability makes DS107+ a great choice for business users who need faster performance.

Speedy & Flexible

DS107+ provides speedy data transmission and powerful computing capability, which is not only suitable for small business environments that demand on efficiency, but also a great choice for power users who massively access data on the server.

Work with Windows ADS

DS107+ is compatible with Windows ADS domain. Windows domain users are able to access data shared from DS107+ when they pass the Active Directory authentication. This will greatly save your time on creating large amount of accounts for the domain users.

Security Enhancements

Encrypted FTP allows you to transmit data using "FTP over SSL" or "FTP over TLS" option. HTTPS support encrypts all HTTP connections with SSL transport mechanism. Encrypted Network Backup ensures Network Backup is done with encrypted data transmission. You wont be worried about critical data being exposed in danger.

Share Files between Windows and Mac

DS107+ is designed for Windows users and Mac users to share files seamlessly. Windows users can access DS107+ via Samba and FTP, and Mac users via Samba, FTP, and AFP. Unicode support allows sharing files smoothly in different languages.

Even more, File Station is a great way for you to remotely access and manage files stored on DS107+. Simply use a web browser to connect to DS107+, and youll have total control over the files. With File Station, moving files among shared folders will now be only seconds away!

Network Video Recording

When connecting IP cameras to the network and recording the videos to the DS107+, Surveillance Station provides you an economical network video recording solution. On Surveillance Station , you can watch the camera-monitored area on a real-time basis, and also view and manage the recorded video clips. Feel free to choose either the continuous or motion-detection recording mode that best fits your need.

Build Up Dynamic Website

Web Station runs Apache web server that allows you to publish website with only few steps. With pre-installed PHP+MySQL, you are free to install popular blog or bulletin board programs on DS107+. No advanced IT knowledge is required to build up your community.

Total Backup Solutions

Data backup is so important but people tend to ignore it, DS107+ makes data backup so complete and automatic that backup always be done without your attention. You can always find the backup alternatives that fit your needs.

Network Backup is designed for you to back up data from DS107+ to another Synology product that also supports Network Backup function or rsync-compatible server.

Local Backup allows you to back up data from DS107+ to external hard drive attached to DS107+ via the USB port.

Desktop Backup simplifies desktop backup with Data Replicator 3. PC users will enjoy the easy-to-use backup tool to back up important data automatically.

Cool and Quiet

Ventilation

DS107+ has a brand new enclosure design. The elegant white cover, good ventilation airflow, and quiet fan operation, bring DS107+ to a new level of Synology Disk Station series.

Other Features

  • Photo Station 3
  • Expand external hard drive via USB port or eSATA port
  • Audio Station
  • Download Station
  • Multimedia Service
  • iTunes Server
  • USB Printer Sharing

Protect our Earth

Protect the earth

Synology products are designed with the concept of energy savings in mind. Compared with PC server products, Synology products consume relatively far less power than their PC counterparts, and are hibernated when not in used. It not only saves your money, but also saves The Earth.

All Synology products are produced with RoHS compliant parts and packed with recyclable packing materials. Synology recognizes its responsibility as a global citizen and is continually working to reduce the environmental impact of the products we create.


Hardware

  • CPU Clock Rate: 500 MHz
  • RAM Size: 64MB or 128MB
  • Internal HDD: 3.5 SATA(II) X1
  • External HDD Interface: USB 2.0 port X3, eSATA port X1
  • Size: 160mm X 218mm X 63mm
  • Weight: 0.81kg
  • LAN: Gigabit X1
  • Fan: X1(50mmX50mm)
  • Power Recovery
  • AC Input Power Voltage: 100V to 240V
  • Power Frequency: 50Hz to 60Hz, Single Phase
  • Max Capacity (Internal HDD): 1 TB (See All Supported HDD)
  • Max Supported IP Camera: 64MB RAM: 2; 128MB RAM: 5 (See All Supported IP Cameras)
  • Operating Temperature: 5C to 35C (40F to 95F)
  • Storage Temperature: -10C to 70C (15F to 155F)
  • Relative Humidity: 5% to 95%RH
  • Maximum Operating Altitude: 10,000 feet

Power Consumption(1)

  • 19W(Access);
    8.6W(Hibernation)

Certification

  • FCC Class B, CE Class B, BSMI Class B, VCCI Class B

Networking Protocols

  • CIFS
  • AFP (3.1)
  • FTP

Windows ADS Domain Integration

  • ADS Support
  • Domain users login via Samba/AFP/FTP
  • Synology Data Replicator 3 for Domain Users

Security

  • "FTP over SSL (explicit)" or "FTP over TLS (explicit)"
  • Encrypted Network Backup
  • HTTPS Connection
  • FTP Auto-Block

File System

  • EXT3
  • FAT (External Disk Only)
  • NTFS (External Disk Read Only)

File Sharing

  • Max User Accounts: 128
  • Max Groups: 64
  • Max Shared Folder: 100
  • Max Concurrent Connections: 32

Utilities

  • Synology Assistant
  • Synology Data Replicator 3
  • Synology Download Redirector
  • Add printer wizard

Applications

  • Surveillance StationNew!
  • Photo Station 3New!
  • File Station
  • Audio Station
  • Web Station
  • PHP/MySQL
  • Download Station
  • iTunes Server

UPnP Multimedia Service Support

  • Sony PS3, Microsoft Xbox360 (See All Supported DMA)
  • Audio Format: AAC, M4A, MP3, Ogg Vorbis, WAV, WMA, WMA VBR, WMA PRO, WMA Lossless
  • Video Format: ASF, AVI, DAT, DivX, MP4, MPEG1, MPEG2, MPEG4, VOB, WMV, XviD
  • Image Format: BMP, JPG (jpe, jpeg), GIF, ICO, PNG, PSD, TIF (tiff), UFO
  • Playlist Format: WPL, M3U

iTunes Server Support

  • Audio Format: MP3, M4A(4), M4P(4)
  • Playlist Format: M3U, WPL

Audio Station Support

  • Audio Format: AAC, M4A, MP3, Ogg Vorbis, WMA, WMA VBR
  • Playlist Format: M3U, WPL
  • Internet Radio: SHOUTcast, Radioio

Photo Station 3 Support

  • Video Format: ASF, AVI, MPEG1, MPEG4, WMV, XviD, DivX, DAT(2), MP4(2), MPEG2(2), RM(2), RMVB(2), VOB(2)
  • Image Format: BMP, JPG (jpe, jpeg), GIF

Management

  • AJAX-based Management UI
  • Download Station Bandwidth control
  • Download Station Port Range Setup
  • Editable HTTP Error Page
  • Email Alert Message
  • Email Notification for New User
  • External HDD Hibernation (eSATA, USB)
  • Scheduled Power Off
  • Firmware Upgrade
  • FTP passive port range
  • Hide-able Shared Folder
  • Internal HDD Hibernation
  • Port range for BitTorrent
  • Removable Default Shared Folder
  • Ez-Internet
  • PPPoE
  • UPS Management (Over USB 2.0)
  • User Quota
  • Web-based Download Station

Backup Solutions

  • Network Backup
  • Local Backup
  • Desktop Backup (using Synology Data Replicator 3)
  • USB Copy

3rd-Party Backup Support

  • Acronis True Image
  • Symantec Backup Exec
  • EMC Retrospect
  • LaCie SilverKeeper (Details)

Supported Clients

  • Windows 2000 onward
  • Mac OS X 10.3 onward

Printer Support(3)

  • Max Printer #: 1
  • Supported Protocols: LPR, CIFS, AppleTalk

Languages

  • English, German, French, Italian, Spanish, Danish, Norwegian, Swedish, Dutch, Russian, Japanese, Korean, Traditional Chinese, Simplified Chinese.

Environment

  • RoHS Compliant

___
(1) Measured with 1 Seagate 750GB ST3750640NS hard drive. The figures could vary on different environments.
(2) User can click and download the file, but not play it in Photo Station as compressed Flash video.
(3) For Mac users, DS107+ supports PostScript USB printers only.
(4) The music can be streamed, but may not be indexed on the iTunes.
