IMG 1 of 1
No Longer Available

Part Number:
85744
(?) Brand:
Manuf No:
HDD-WD1601ABYS
HDDWD1601ABYS
Shipping Weight:
1.5 KG (Includes product packaging)
Estimate Shipping
All stock codes associated to this product
WD1601ABYS, HDDWD1601ABYS, HDD-WD1601ABYS
WD RE2 hard drives are the world's most reliable server-class SATA drives in the market. With 1.2 million hours MTBF, 5-year limited warranty, 3 Gb/s SATA technology, and best-in-class vibration tolerance, WD RE2 drives offer the best combination of superior reliability, high capacity, and optimum performance for enterprise applications.

Key Features
Superior reliability - Designed and manufactured to server-class standards to provide best-in-class enterprise reliability in high duty cycle environments. With 1.2 million hours MTBF, these drives have the highest available reliability rating on a high-capacity drive.

High capacity - Up to 750 GB of storage packed with server-class features and low cost-per-gigabyte value.

Fast - With a next-generation SATA interface, 3 Gb/s data transfer rate, native command queuing (NCQ), and 16 MB cache, these drives deliver optimum performance.

Low power - Active Power Save delivers best-in-class seek mode power consumption through an advanced WD firmware which conserves power in active seek modes without degrading performance.

RAID-specific, time-limited error recovery (TLER) - A feature pioneered by WD, significantly reduces drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.

Rotary Acceleration Feed Forward (RAFF) - Provides best-in-class vibration tolerance by optimizing operation and performance when the drives are used in vibration-prone, multidrive systems such as rack-mounted servers or network storage.

Perpendicular Magnetic Recording (PMR) - WD RE2 drives employ PMR technology to achieve even greater areal density.

5-year limited warranty

Ideal For

Servers, SAN/NAS, scientific computing, life sciences, video surveillance, enterprise backup, document/image management, audio/video media applications, and other demanding write-intensive applications.

Performance Specifications
Rotational Speed 7,200 RPM (nominal)
Buffer Size 16 MB
Average Latency 4.20 ms (nominal)
Start/Stop Cycles 50,000 minimum
Seek Times
Read Seek Time 8.9 ms
Write Seek Time 8.9 ms (average)
Track-To-Track Seek Time 2.0 ms (average)
Full Stroke Seek 21.0 ms (average)
Transfer Rates
Buffer To Host (Serial ATA) 3 Gb/s (Max)
Transfer Rate (Buffer To Disk) 85 MB/s (Sustained)
Physical Specifications
Formatted Capacity 160,041 MB
Capacity 160 GB
Interface SATA 3 Gb/s
User Sectors Per Drive 312,581,808
Physical Dimensions
English
Height 1.028 Inches (Max)
Length 5.787 Inches (Max)
Width 4.00 Inches (+/- 0.010 inch)
Weight 1.61 Pounds
Metric
Height 25.4 mm (Max)
Length 147 mm (Max)
Width 101.6 mm
Weight 0.73 kg
Environmental Specifications
Shock
Operating Shock (Read) 65G, 2 ms
Non-operating Shock 250G, 2 ms
Acoustics
Idle Mode 28 dBA (average)
Seek Mode 0 33 dBA (average)
Seek Mode 3 29 dBA (average)
Temperature (English)
Operating 41 F to 131 F
Non-operating -40 F to 149 F
Temperature (Metric)
Operating 5 C to 55 C
Non-operating -40 C to 65 C
Humidity
Operating 5-95% RH non-condensing
Non-operating 5-95% RH non-condensing
Altitude (English)
Operating -1,000 feet to 10,000 feet
Non-operating -1,000 feet to 40,000 feet
Altitude (Metric)
Operating -305M to 3,050M
Non-operating -305M to 12,200M
Vibration
Operating
Linear 20-300 Hz, .75G (0 to peak)
Random 10-300 Hz, 0.004 g / Hz
Non-operating
Low Frequency 5-20 Hz, 0.195 inches (double amplitude)
High Frequency 20-500 Hz, 4.0G (0 to peak)
Electrical Specifications
Current Requirements
12 VDC
Read/Write 450 mA
Idle 430 mA
Standby 20 mA
Sleep 20 mA
5 VDC
Read/Write 800 mA
Idle 730 mA
Standby 270 mA
Sleep 250 mA
Power Dissipation
Read/Write 9.50 Watts
Idle 8.75 Watts
Standby 1.60 Watts
Sleep 1.50 Watts
