MSI K9N2GM-FIH Motherboard
AM2+, GeForce 8200, HT 5200, 4x DDR2-800, PCI-Ex16 v2.0, 6x SATA-II, RAID, GigLAN, 8Chl, Firewire, VGA, HDMI, mATX

No Longer Available

Part Number:

85790

(?) Brand:

MSI Web Site

Manuf No:

K9N2GM-FIH
K9N2GMFIH

Shipping Weight:

2 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

K9N2GMFIH, K9N2GM-FIH, MSI2009

K9N2GM-FIH

K9N2GM-FIH
[Onboard GbE LAN, IEEE1394, HDMI]

MSI Reminds you :
Because of the limitations of chipset, this MB does not support Win98/ME.

Features

Key components status hardware monitor.
Monitor the Dual Core CPU each unit status.
Optimize System status define.
Auto speed up with system loading change.

The MSI Live Update online is designed to automatically download and update the BIOS and driver when theres a new version online. It helps reduce the risk of getting the wrong file and minimize the trouble of searching the files from MSI website.

Live Update 3 is a single utility software that automatically checks BIOS, driver and utility updates and installs for you , which can save your time for searching and lower the risk while updating.

AMD Cool'n'Quiet technology that based on famous PowerNow technology just brings fresh air to hot-fighting desktop platform. Cool'n'Quiet technology can automatically adjust processor ratio to throttle CPU speed with four modes.

Specifications

CPU

Support socket AM2 for AMD Athlon 64/Athlon 64X2 CPU. (Optional)
Support socket AM2+ for AMD Phenom CPU. (Optional)
Please refer to CPU Support for compatible CPU; the above description is for reference only.

FSB

HyperTransport 3.0 supporting speed up to 2600MHz
- AM2 CPU supports HyperTransport 1.0/2.0 (Optional)
- AM2+ CPU supports HyperTransport 3.0 (Optional)

Chipset

NVIDIA GeForce 8200 (MCP78S) Series single chipset

Main Memory

Supports Dual DDR2 667/800
-4 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 8GB.

Slots

1 PCI Express x16 slot (PCI Express Bus SPEC V2.0 compliant)
1 PCI Express x1 slot
2 PCI slots, support 3.3V/ 5V PCI bus Interface.

On-Board IDE

One IDE port by NVIDIA GeForce 8200 Series
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices

On-Board SATA

6 SATA II (1~6) ports by NVIDIA GeForce 8200 Series
- Supports storage and data transfers at up to 3Gb/s

RAID Function

- SATA II 1~6 support RAID 0, 1, 0+1, 5 or JBODmode by NVIDIA GeForce 8200 Series

MSI Reminds You...
The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.

Audio

Chipset integrated by Realtek ALC888
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

Realtek PCI-E GbLAN controller 8211BL
- Integrated Fast Ethernet MAC and PHY in single chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
- Compliance with PCI-Express Bus specification v1.0a

IEEE1394

Chipset integrated by JMicron JMB381
- Transfer rate is up to 400Mbps

Internal I/O Connectors

- ATX 24-pin power connector
- ATX 4-pin 12V CPU power connector
- CPU / System x1 FAN connectors
- CD-in connector
- Front panel audio connector
- Front panel connector
- Chassis intrusion switch connector
-1 x Serialport connector
-2 x USB 2.0 connector support additional4 ports
- 1 x Floppy disk drive connector
-6 x Serial ATA II connectors
- 1 x ATA133IDE connector
- Clear CMOS jumper
- 1 x SPDIF-out header
- 1 x IEEE1394 connector support additional 1 port (optional)
- 1 x TPM module header (optional)

MSI Reminds You...
The floppy disk cable will be optional.

Back Panel I/O Ports

- 1 x HDMI port
- 1 x PS/2 keyboard
- 1 x PS/2 mouse
- 1 x IEEE1394 Port
- 1 x 6 in 1 audio jack

K9N2GM-FIH

- 4 x USB 2.0 ports
- 1 x RJ45 LAN jack
- 1 x Graphics Card port

Dimension

24.4cm(L) x 24.4cm(W) M-ATX Form Factor

Mounting

8 mounting holes.

MSI Reminds You...
The accessories will probably be different according to the different selling areas of product models. For details of accessories, please refer to the descriptions on the product package.
