 Full 19" viewable widescreen with 1680X1050 resolution
High resolution panel with 36% more clarity than a regular 19" wide monitor.
Fast ClearMotiv II video response
Video response as fast as 2ms enables digital HD broadcast-quality video.
6000:1 dynamic contrast ratio (typ)
Provides for darker black levels and better overall front-of-screen performance.
Stylish slim-bezel design
The thin bezel lets you see more without taking up valuable desktop real estate.
OptiSync digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and analog (VGA) signals for ultimate compatibility and configuration flexibility.
SRS WOW HD sound and high quality stereo speakers
Windows Vista certified
PC and Mac compatible
MPR II and ENERGY STAR qualified
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
Wide Color TFT Active Matrix LCD |
| |
|
Display Area |
|
19 inch |
| |
|
True Resolution |
|
1680x1050 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 6000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 horizontal, 160 vertical (CR 10) |
| |
|
Response Time |
|
2ms (G to G) |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating (3H) |
|
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Digital |
|
DVI-D (TMDS, 100 ohms, with HDCP) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~75Hz |
| |
|
Sync |
|
Separate Sync / Composite Sync / SOG |
|
| Compatibility |
|
PC |
|
VGA up to 1680 X 1050 non-interlaced |
| |
|
Mac |
|
Power Mac, up to 1680 X 1050 non-interlaced |
|
| Connector |
|
Analog |
|
15 pin mini D-sub X 1 |
| |
|
Digital |
|
DVI-D X 1 |
| |
|
Audio |
|
3.5 mm Audio line-out |
| |
|
Power |
|
Built-in power Adapter, 3-Pin plug |
|
| Audio |
|
Speakers |
|
3W X 2 |
|
| Power |
|
Voltage |
|
100-240VAC; 50/60 Hz (Switch) |
| |
|
Consumption |
|
44W (Typ) / 49W (max) |
|
| Controls |
|
Basic |
|
[1], [2], Power, Down, Up |
| |
|
OSD |
|
Auto Image Adjust, Contrast/Brightness, Input Select (D-Sub, DVI-D), Audio Adjust (Volume, mute), Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R,G,B]), Information, Manual Image Adjust (Horizontal Size, H/V. Position, Fine Tune, Sharpness, Dynamic Contrast, Response time), Setup Menu (Language, Resolution Notice, OSD Position, OSD Timeout, OSD Background), Memory Recall |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0C - 35C (32F - 95F)
10-90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
447mm(W) x 399mm(H) x 174.9mm(D) |
|
| Weight |
|
Net |
|
3.9 Kgs |
|
| Regulations |
|
|
|
CB, MPR II, WEEE, RoHS, UL, cUL, FCC-B, TUV-S, NOM, Energy Star, EPEAT, TUV/ERGO (covers ISO13406-2), CE, GOSTR+Hygienic ,SASO, ENERGY, Ukraine, CCC, BSMI, PSB, C-TICK, MIC, VCCI |
|
| Power Management |
|
|
|
Meets RoHS and Energy Star standards |
* VESA wall mount sold separately. |
|
