NBG-318S

Wireless G HomePlug AV Router

3-in-1 Wireless HomePlug AV Router

- Throughput up to 200Mbps over Power Lines
- Configurable Powerline for Internet or Home Network Connections
- Advanced 128-bit AES Security Network Protection
- Super G Technology Offers the Optimal Wireless Range and Performance of Data Rate up to 108Mbps
- HomePlug AV Compliant



No New Wire Required for House-Wide Network
ZyXEL NBG-318S features both wireless and HomePlug AV connectivity. You can always connect to the Internet wirelessly, even on some spots that couldn't be reached by the wireless network. With existing power lines, reliable connection can be provided through wall plugs.

Now you can plan your home network, use the power lines as the network backbone, and then deploy the NBG-318S as the broadband extender to reach every corner in the house.


Data Transmission Rates of Up to 200Mbps
The NBG-318S is an extension solution for your house to be completely networked with existing power lines. Thanks to the advanced HomePlug AV technology, the NBG-318S is capable of transmitting data at up to 200Mbps. It allows you to share network resources and enjoy Internet access through secure high-speed data connection over the house power lines you already have.


High Speed and QoS for High Definition Video Streams
The inherited advanced QoS features make the NBG-318S ideal access tool for service providers to deliver "triple play" multimedia services such as high-quality digital video streams, high-speed Internet access and voice services.


Advanced 128-bit AES Security Protection
With the 128-bit Data Encryption Security (AES) feature, the NBG-318S provides secure network connection for Internet access and resource sharing. Just leave the sweats to the NBG-318S, sit back and enjoy the fast surfing experience as well as secure file transfer over the Internet.


High Speed Wireless Access
Taking advantage of ZyXEL's Wireless Super G Technology, users can achieve data rates of up to 108Mbps, which doubles the speed of the conventional 802.11g standard. With the astounding performance, users can handle the fast data transfer for streaming applications like video or audio broadcasting effortlessly.





System Specifications

  • MBM v2 with Automatic Traffic Classifier
  • Powerline as WAN or LAN port
  • PPPoE/DHCP/PPTP with MS CHAP v1/v2
  • Logging
  • Web configurator
  • Many to one NAT
  • SIP ALG
  • DOS/DDOS SPI Firewall
  • Port Triggering
  • DDNS
  • WPA/WPA2 support
  • 802.11e/WMM

Hardware Specifications

  • 3-port 10/100Mbps Ethernet port with MDI/MDIX as LAN
  • 1-port 10/100Mbps Ethernet port with MDI/MDIX as WAN
  • One Power Input: 100-240 VAC, 50 ~ 60 Hz
  • LED Display on Top-Case
    • Power
    • Powerline Link and Activity
    • Ethernet LAN Link and Activity
    • Ethernet WAN Link and Activity
    • Wireless LAN Link and Activity
    • Security Status

Physical Specification

  • Dimensions:162 (W) x 117.35 (D) x 39.4 (H)mm
  • Weight: 185g

Environmental Specification

  • Operating Temperature: 0C ~ 40C
  • Storage Temperature: -30C ~60C
  • Operating Humidity: 20% to 90% RH
  • Storage Humidity: 20% to 90% RH

Certification

  • Safety: CSA international
  • EMI: CE, FCC part 15B
  • HomePlug Certification: HomePlugAV
  • Wi-Fi





homeplug_200mbps 2_4ghz_802_11g_108 : Wireless Super G based on IEEE 802.11g Technology HomePlug AV 200Mbps : HomePlug AV series with data rate of up to 200Mbps WPA 2 : Wi-Fi Protected Access (WPA or WPA2) QoS Media Streaming : Quality of Service (QoS) for Media Streaming Optimization homeplug_av

No additional files, specification sheets, guides or documentation found for product.

Warranty: 24 months*

Full manufacturers warranty details are available at the manufacturers (ZyXEL) web site.
