Product DetailsGo BackEmail to FriendPrint
Computer Systems -> BareBone - Servers -> ASUS

ASUS Barebone RackMount Server - 1U (RS120-E5/PA4)
Single Xeon 3xxx, 4xDDR2-800 ECC, 4xHS SATA-II HDD Bays, 2xGigLAN, VGA
1xPCI-Ex16, 1xPCI-Ex8
Cart
Quantity:
Add ASUS Barebone RackMount Server - 1U (RS120-E5/PA4)
Single Xeon 3xxx, 4xDDR2-800 ECC, 4xHS SATA-II HDD Bays, 2xGigLAN, VGA
1xPCI-Ex16, 1xPCI-Ex8 to your wishlist
Click here to write a review on ASUS Barebone RackMount Server - 1U (RS120-E5/PA4)
Single Xeon 3xxx, 4xDDR2-800 ECC, 4xHS SATA-II HDD Bays, 2xGigLAN, VGA
1xPCI-Ex16, 1xPCI-Ex8

Large image is available
Product May Vary From Image

Our Price:
$1,305.25
RRP:$1,490.00
You Save:$184.75

Techbuy Part No:87322
Usually Ships: 1-3 Days Details
Brand:ASUS Web Site
Manuf No:RS120-E5/PA4
 RS120E5/PA4
Shipping Weight:15 KG How Much?
Date Added:30/7/2008
Rating: Not Rated
Currency:AUD Convert

Product Description

Enjoy 45nm Micro Technology & Mass Storage Capacity

RS120-E5/PA4 is a high storage capacity 1U1P server platform based on Intel 3200 chipset and ready to support next generation 45nm Intel Xeon processor With optimized placement and thermal technology, its able to provide high performance computing with great reliability.

Powerful Technology Support Ready
Support latest 45nm Intel Xeon Processor and Intel 3200MCH to deliver better computing performance and energy-saving
1333MHz FSB provides wider bandwidth than ever
DDR2 800/667 Unbuffered ECC memory offers higher computing capability

Full-range of I/O Expansion Card Support
Provides one PCI-E x16 (x8 link) and one PCI-E x8 (x4 link) by default
Support one PCI-E x8 (x8 link) and one PCI-X 64bit/133MHz via an optional riser card

High Availability & Superb Storage Expandability
Four hot-swappable HDD bays offer mass storage capacity and high availability
Support RAID 0, 1, 10 for major Linux distributions and RAID 0, 1, 5, 10 for Windows OS



KEY SPECIFICATIONS

Processor Support

Quad-Core Intel Xeon processor 3300 series (45nm)
Dual-Core Intel Xeon processor 3100 series (45nm)
Dual-Core Intel Xeon 3000 series
Quad-Core Intel Xeon 3200 series (G0 stepping)

FSB

FSB 1333/1066/800

Core Logic

Intel 3200 MCH + Intel ICH7R

Memory

4-DIMM support up to 8GB DDR2 800/667 un-buffered, ECC

Storage

4 x Hot-Swap SATAII HDD Bays
1 x Slim-type Optical Device (Optional)

RAID Support

Max. 4 * SATA HDD with S/W RAID 0, 1, 5, 10 (Windows) or S/W RAID 0,1, 10 (Linux)

NIC

2 x Broadcom BCM5721 PCI-E GbE LAN

Onboard Gfx

XGI Z9s VGA Controller / 32MB

Expansion Slot

Default:
1 * PCI-E x 16 slot (x8 link) (Full-Height / Half-Length) +1 *PCI-E x 8 slot (x4 link) (Full-Height / Half-Length)
Configuration Option:
1 * PCI-E x8 slot (x8 link) (Full-Height / Half-Length)+ 1 * PCI-X 64-bit/133MHz slot (Full-Height / Half-Length)

Power Supply

315W Single Power Supply

Dimension

600mm x 444mm x 43.6mm (1U)

Net Weight

12Kg (CPU, Memory & HDD are not included)





Specifications
Processor / System Bus
1 * Socket LGA775
Quad-Core Intel Xeon processor 3300 series (45nm)
Dual-Core Intel Xeon processor 3100 series (45nm)
Dual-Core Intel Xeon 3000 series
Quad-Core Intel Xeon 3200 series (G0 stepping)
FSB 800/1066/1333
Core Logic
Intel 3200 MCH
Intel ICH7R
ASUS Features
Smart Fan III
ASWM2.0
Memory
Total Slots: 4 (2-channel)
Capacity: Maximum up to 8GB*
Memory Type: DDR2 533/667/800 Unbuffered , ECC
Memory Size: 512 MB, 1 GB, 2GB*
Expansion Slots
Total PCI/PCI-X/PCI-E Slots: 2

Slot Type:
Default:
1 * PCI-E x 16 slot (x8 link) (Full-Height / Half-Length)
1 * PCI-E x 8 slot (x4 link) (Full-Height / Half-Length)
Configuration Option:
1 * PCI-E x8 slot (x8 link) (Full-Height / Half-Length)
1 * PCI-X 64-bit/133MHz slot (Full-Height / Half-Length)

Additional Slot: 1* SO-DIMM socket
Storage
SATA Controller:
Intel ICH7R:
4 SATA2 300MB/s ports
Intel Matrix Storage (for Windows only)
(Support software RAID 0,1,10, 5)
LSI MegaRAID (Linux/Windows)
(Support software RAID 0, 1, 10)
HDD Bays
4 * Hot-swap SATA2 HDDs Bays
Networking
LAN: 2 * Broadcom BCM5721 PCI-E Gb LAN
Graphic
VGA: XGI Z9s/ 32MB DDRII VRAM
Auxiliary Storage
1 * Slim-type Optical Device Bay
Options: No Device / DVD-ROM / DVD-RW
On Board I/O
1 * External Serial Port
2 * RJ-45 ports
4 * USB 2.0 ports (Fornt * 2, Rear * 2)
1 * VGA port
1 * PS/2 keyboard port
1 * PS/2 mouse port
OS Support
Windows Server 2003 R2 Enterprise 32/64-bit
RedHat Enterprise Linux AS4.0 32/64-bit
SuSE Linux Enterprise Server 10 32/64-bit
(Subject to change without any notice)
Anti-virus Software
Optional CA eTrust 7.1 anti-virus software
Management Solution
Software: ASWM2.0
Out of Band Remote Management: ASMB3-SOL PLUS
Safety
US / Canada ( UL1950-CSA950)
Europe (CE, EN55022 compliance to EU Directive 89 / 366/ EEC)
Europe (TUV)
EMI
US (FCC, CFR47 Part 15) (Class A)
Europe (CE, EN55022 & EN55024)
Australia (C-TICK)
Taiwan (BSMI)
China (CCC)
Dimensions without Packing
600mm * 444mm * 43.6mm
Net Weight Kg (CPU, DRAM and HDD not included)
12Kg
Power Supply
315W Single Power Supply
Environment
Operation temperature: 10 ~ 35 / Non operation temperature: -40 ~ 70
Non operation humidity: 20% ~ 90% ( Non condensing)

- All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
- PCB color and bundled software versions are subject to change without notice.
- Brand and product names mentioned are trademarks of their respective companies.
- All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
- PCB color and bundled software versions are subject to change without notice.
- Brand and product names mentioned are trademarks of their respective companies.


Product Warranty


3-month RTB
