| LCD |
Type |
19" Wide Color a-Si TFT Active Matrix |
| Display Area |
|
| Optimum Resolution |
1440900 |
| Brightness |
300 cd/m(Typ) |
| Contrast Ratio |
800:1(Typ) / 2000:1(Dynamic Contras Ratio) |
| Viewing Angle |
160 (H), 160 (V)(CR?10) |
| Response Time |
5ms |
| Pixel Pitch |
0.2835mm (H)0.2835mm (V) |
| Panel Surface |
Anti-Glare, Hard coating(3H) |
| Light Source |
|
| INPUT |
Analog |
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| Digital |
DVI-D (TMDS, 100 ohms) |
| Sync |
Separate Sync / Composite Sync / SOG |
| Frequency |
Fh:24-82kHz, Fv:50-75Hz |
| COMPATIBILITY |
PC |
VGA up to 1440900 Non Interlaced |
| Mac |
Power Mac(up to 1400900 ) |
| CONNECTOR |
Analog |
15 pin mini D-sub1 |
| Digital |
DVI-D |
| Audio-in |
- |
| USB |
- |
| Power |
Built-in power Adapter, 3-Pin plug |
| AUDIO |
Speaker |
- |
| POWER |
Voltage |
AC 100-240V (Universal); 50/60Hz(Switch) |
| Consumption |
32W(Typ.) / 36W(Max) |
| ERGONOMICS |
Tilt |
Down 5, Up 20 |
| Swivel |
|
| Rotation |
|
| Height Adjust |
|
| CONTROLS |
Basic |
[1], [2], Power, Down[?], Up[?] |
| OnView / OSD |
Auto Image Adjust, Contrast/Brightness, Color Adjust(sRGB, 9300K, 6500K, 5400K, User Color [R, G, B]), Information, Manual Image Adjust(Horizontal Size, H/V Position, Fine Tune, Sharpness), Setup Menu(Language Select, Resolution Notice, OSD Position, OSD Time Out, OSD, Background), Memory Recall |
| OPERATING CONDITIONS |
Temperature |
0C - 40C(32F - 104F) |
| Humidity |
10 - 90%(Non condensed) |
| DIMENSIONS (WxHxD) |
Physical (w/ stand) |
440.0 mm(W)383.3 mm (H)195 mm(D), 17.3"(W) x 15.2" (H) x 7.7"(D) |
| Physical (w/o stand) |
|
| Physical (packaging) |
|
| WEIGHT |
Net (w/ stand) |
4.0 Kg(8.8 lbs) |
| Net (w/o stand) |
|
| Gross (packaging) |
|
| REGULATIONS |
|
UL, CUL, FCC-B(ICES), CB, CE, TCO'03, ICES-003B, TUV/GS, TUV ERGO(covers ISO13406-2 & MPRII), TUV-S, VCCI, GOST-R, HYGIENIC(20 copies), ENERGY, Energy Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS, NOM |
| WALL MOUNT (VESA) |
|
Meet VESA (100mm100mm) Standards |
| POWER MANAGEMENT |
|
|
| SECURITY |
|
|
| PACKAGE CONTENTS |
|
|
| FEATURE |
|
2000:1 Dynamic Contras Ratio
ClearMotiv II technolog
OptiSync Technology
sRGB Color Management
OSD/Power Lock Function
16:10 wide screen |
|
