Thermalright HR-01 X Passive Heat Sink - for Intel Socket 603, Socket 604, Socket 771

No Longer Available

Part Number:

88728

(?) Brand:

Thermalright

Manuf No:

HR-01X
HR01X

Shipping Weight:

1.5 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

HR-01X, HR01X

Origin

We have received many distraught emails from users across the globe complaining that their stock cooler would not allow them to overclock their servers. Another issues brought up was the noise they have to tolerate from the high RPM fans in order to keep the CPU at mediocre operation level. To solve these problems we upgraded the original HR-01 with 6 heat pipes, and with its proprietary thru holes you can pair it up with any low RPM 120mm fan and add the ability and flexibility to OVERCLOCK! At the same time enjoying the quietness the HR-01X brings while you work effortlessly and quietly.

Features

120mm design for low-noise fan operation (120mm Fan optional)

Proprietary through holes on fins for efficient ventilation

Six heatpipes for well spread heat around aluminum fins

Soldered fins to copper base (nickel plated) to make effective contact

Light weight and easy installation

Adjustable positioning on CPU for best angle on installation

Technical Spec


Dimension : L110 x W60 x H159.5(mm) Heat sink only Weight : 600g (Heatsink Only)

Motherboard Compatibilities

Intel Xeon : 5000 Series,7000 Series. (Socket 603,Socket 604,Socket 771)

Support Duo Core, Quad Core Processors

No additional files, specification sheets, guides or documentation found for product.

Warranty: 12-month Manufacturer

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
