Intel SRCSASRB RAID Controller - 8xSAS/SATA (via 2-Port Mini-SAS Internal SFF-8087), 256MB Cache, Low Profile - PCI-Ex4, (Cable Included)
RAID 0,1,5,6,10,50,60

No Longer Available

Part Number:

89958

(?) Brand:

Intel Web Site

Manuf No:

SRCSASRB

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Finance Images & Video

All stock codes associated to this product

SRCSASRB, 1065188, 735858196437

Exceptional data protection with RAID-On-Chip and serial attached SCSI technology for mainstream applications.

The Intel RAID Controller SRCSASRB is one in a family of Intel first-generation RAID solutions to use RAID-On-Chip (ROC) technology.

The SRCSASRB is also highly flexible. An important feature is the high-performance multiplexer (MUX) which allows configuring of eight ports for internal or external use, or both. Solutions can be built for up to 240 disks, using high-performance SAS disks or high-capacity SATA drivesor a combination of each.

Features and benefits

Exceptional data protection	Supports data redundancy using SAS or SATA hard disk drives through mirroring, parity, and double parity (RAID levels 1, 5, and 6) plus striping capability for spans (RAID levels 10, 50, and 60).
Excellent performance	ROC technology directly connected to 256 MB embedded 667 MHz cache enhances the performance of mainstream applications.
Outstanding availability	Delivers proactive drive monitoring and automatic error correction. An optional battery backup maintains data without the need for an uninterruptible power supply.
Increased IT productivity	Includes a suite of tools that are common across multiple Intel RAID solutions, for easy installation and advanced management.
SAS/SATA flexibility	Features eight internal 3 GB/s Serial Attached SCSI (SAS) ports on two SFF8087 mini connectors, and is designed for high-performance SAS disks, low-cost/high-capacity SATA drives, or a combination of both.

Product specifications

RAID levels and spans	RAID levels 0, 1, 5 and 6 RAID spans 10, 50, 60
Fault tolerant features	Online capacity expansion Hot spare support Enclosure management S.M.A.R.T. support
Intel RAID software	Intel RAID BIOS Console Intel RAID Web Console 2 Intel RAID Flash Utilities
I/O processor	LSI Logic* 1078 SAS ROC at 500 MHz, and dual- independent DMA controllers
Drive type	SAS or SATA 3Gb/s
Maximum drives	Up to 32 devices supported
Connectors	Two SAS SFF8087 Mini-SAS 4i internal connectors
Cache memory	Embedded 256 MB ECC DDR2, 40b wide
PCI interface	PCI Express* x4
BBU support	AXXRSBBU4
Form factor	Low profile, extended half-length (7.75" x 2.525")
Data transfer rates	Up to 3 GB/s per port
Operating temperature	Minimum ambient: 0C; Maximum ambient: 50C (10C to 40C w/ optional BBU)
Operating voltage	+3.3V
Battery backup unit	Intel Smart Battery AXXRSBBU4

Specification Sheets / Installation guides / Associated files

SRCSASRB Datasheet

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Intel) web site.
