| CPU |
| |
AMD AM2+ processors: Phenom FX / Phenom / Athlon / Sempron AMD AM2 processors: Athlon series / Sempron
HyperTransport 3.0 (5200MT/s for AM2+) HyperTransport 1.0 (2000/1600MT/s for AM2)
AMD OverDrive provides tuning options using the new Advanced Clock Calibration overclocking feature.
Socket 940 AM2+ 65nm
|
| |
| Chipset |
| |
AMD chipset - Northbridge: AMD 790FX - Southbridge: AMD SB750
|
| |
| System Memory |
| |
Four 240-pin DDR2 DIMM sockets
Supports DDR2 667/800/1066 MHz DIMMs
Supports dual channel (128-bit wide) memory interface
Supports up to 8GB system memory
Supports unbuffered non-ECC x8 and x16 DIMMs
|
| |
| Expansion Slots |
| |
3 PCI Express (Gen 2) x16 slots - 2-way or 4-way CrossFire at x16/x16/NC bandwidth - 3-way CrossFire at x16/x8/x8 bandwidth - 2-way CrossFire + Physics at x16/x8/x8 bandwidth
3 PCI slots
|
| |
| BIOS |
| |
Award BIOS
CMOS Reloaded
CPU/DRAM overclocking
CPU/DRAM/Chipset overvoltage
8Mbit SPI flash memory
|
| |
| Audio |
| |
Realtek ALC885 8-channel HD Audio Codec
High-performance DACs with 106dB dynamic range (A-Weight), ADCs with 101dB dynamic range (A-Weight)
|
| |
| LAN |
| |
Marvell 88E8053 PCIE Gigabit LAN controller
Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX) and 802.3ab (1000BASE-T) standards
|
| |
| Serial ATA with RAID |
| |
Supports up to 6 SATA devices
SATA speed up to 3Gb/s
RAID 0, RAID 1 and RAID 0+1
|
| |
| IDE |
| |
One IDE connector allows connecting up to two UltraDMA 133Mbps hard drives
|
| |
| Rear Panel I/O |
| |
1 mini-DIN-6 PS/2 mouse port
1 mini-DIN-6 PS/2 keyboard port
1 optical S/PDIF-out port
1 coaxial RCA S/PDIF-out port
6 USB 2.0/1.1 ports
1 RJ45 LAN port
Center/subwoofer, rear R/L and side R/L jacks
Line-in, line-out (front R/L) and mic-in jacks
|
| |
| Internal I/O |
| |
3 connectors for 6 additional external USB 2.0 ports
1 connector for an external COM port
1 front audio connector
1 CD-in connector
1 IrDA connector
1 CIR connector
6 Serial ATA connectors
1 40-pin IDE connector
1 floppy connector
1 24-pin ATX power connector
1 8-pin 12V power connector
2 4-pin 5V/12V power connectors (FDD type)
1 front panel connector
6 fan connectors
EZ touch switches (power switch and reset switch)
|
| |
| Power Management |
| |
ACPI and OS Directed Power Management
ACPI STR (Suspend to RAM) function
Wake-On-PS/2 Keyboard/Mouse
Wake-On-USB Keyboard/Mouse
Wake-On-Ring
Wake-On-LAN
RTC timer to power-on the system
AC power failure recovery
|
| |
| Hardware Monitor |
| |
Monitors CPU/system/chipset temperature
Monitors 12V/5V/3.3V/Vcore/Vbat/5Vsb/Vdimm/Vchip voltages
Monitors the speed of the cooling fans
CPU Overheat Protection function monitors CPU temperature during system boot-up
|
| |
| PCB |
| |
ATX form factor
24.5cm (9.64") x 30.5cm (12") All specifications above are subject to change without prior notice.
|
