Features
| Key Features |
 |
USB 2.0 Support
A standard plug and play interface providing easy-to-use connectivity for USB devices.
|
|
PCI Express 2.0 / 1.1 Support
Allows 500MB a lane or up to 8 GB/s at 16x speeds - allows for full support for new PCI-E 2.0 graphics cards.
|
|
Serial ATA - II
Also known as SATA2, features a 3.0 Gbit/s transfer speed, faster than Standard Serial ATA.
|
|
Solid Capacitors
Offers a longer lifespan, better stability when at high frequencies, can operate at higher temperatures, and no longer runs the risk of exploding.
|
|
Active Heatsink
Consists of a fan and metal heatsink.
|
|
8 - Phase Power Design
For excellent power-stability, an 8 Phase Power Design is used.
|
|
On-Boad Clear CMOS Button
An onboard clear CMOS button which allows you to easily clear your BIOS without moving a jumper.
|
|
On-Board Power Button with Integrated Power Light
An onboard power button for easily powering on or off your system. Also shows a power indication light.
|
|
On-Board Reset Button with Integrated HDD Activity Light
An onboard reset button for easily rebooting your system as well as gives current status of your HDD via an activity light.
|
|
On-Board Diagnostics LED Readout
Helpful for when diagnosing a problem is needed.
|
|
2-Way SLI Support
Feel free to turn up the eye candy and experience the performance of 2 Graphics Cards running together.
|
|
3-Way SLI Support
Experience the amazing performance that only 3 Graphics Cards can deliver, a visual experience that will take you to the next level.
|
|
Windows 2000 Support
|
|
Windows XP Support
|
|
Windows Vista Support
|
|
DDR3 Support
Full support for the latest in DDR technologies.
|
|
Triple-Channel Support
Supports Triple-Channel memory configurations for extreme amounts of system memory bandwidth.
|
|
Dual-Channel Support
Supports Dual-Channel memory configurations for increased amounts of system memory bandwidth.
|
|
Intel X58/ICH10R Chispet
This chipset supports Triple-Channel DDR3 system memory configurations as well as Intel Core i7 (Socket 1366) support and NVIDIA 2-Way and 3-Way SLI support.
|
|
Intel Core i7 Support |
Specifications
Performance
Based on Intel X58/ICH10R chipset
Supports Intel Core i7 Processors
133 Mhz QPI
Memory
6 x 240-pin DIMM sockets
Triple Channel DDR3
Maximum of 12GB of DDR3 1066/1333 MHz
Expansion Slot
1 x PCIe x16, 1 x PCIe x8/x16, 1 x PCIe x8, 1 x PCIe x1, 2 x PCI
2 x 32-bit PCI, support for PCI 2.1
Storage I/O
1 x UltraDMA133
9 x Serial ATA 300MB/sec with support for RAID 0, RAID1, RAID 0+1, RAID5, JBOD
x Floppy disk drive connector
Integrated Peripherals
8 Channel High Definition
2 x 10/100/1000
Multi I/O
1 x PS2 Keyboard
1 x Serial Ports
12 x USB2.0 ports (4 external + 8 internal headers)
Audio connector (Line-in, Line-out, MIC)
FireWire 1394A (1 external, 1 header)
Form Factor
ATX Form Factor
Length: 12.0in - 304.8mm
Width: 9.6in - 243.6mm
