Emerge HGA51G-DIR30 Directional Antenna Kit
Extend wireless audio and video up to 1000 feet (305 m) line-of-sight with this optional directional antenna using the Emerge MPX HD multipoint extender.
The Avocent Emerge HGA51G-DIR30 directional antennas work together with the MPX HD multipoint extender to provide line-of-sight extended distance capability when required by an installation. The Emerge HGA51G-DIR30 directional antenna works by focusing the energy of the antenna signal into an intensified unidirectional beam. In line-of-sight applications the directional antenna allows the MPX HD multipoint extender receiver to be placed up to 1000 feet from the transmitter.
Optional Directional Antenna
The optional HGA51G-DIR30 directional antenna ships with two antennas, one antenna for the device transmitter, and a second antenna for the device receiver. The directional antennas work in the 802.11a band and provide frequency ranges of 5.150 GHz to 5.825 GHz. Applications requiring extended distance benefit from using the directional antenna as it allows the user to install a display system without running wires around a room, or incur the expense of having to open walls to run conduit.
Features and Benefits
- 802.11a Radio Standard - Operates on the least-used standard WLAN frequencies for higher QoS and interference-free connectivity.
- Proprietary Communications Protocol - Proprietary packet protocol offers security and high bandwidth for challenging installations.
- AES Encryption - Built-in Advanced Encryption Standard (AES) for secure wireless connectivity.
Specifications
| General
|
| Size |
1.5" (38 mm) D x 4.5" (114 mm) W x 10.5" (267 mm) H |
| Weight |
1.5 lbs. (.68 Kg) |
| Frequency |
5.150 GHz to 5.825 GHz |
| Gain |
8dB |
| Polarization |
Horizontal |
| Horizontal Beam Width |
40 |
| Vertical Beam Width |
25 |
| Connector |
Reverse polarity SMA |
| Environmental
|
| Operating Temperature |
32F (0C) to 104F (40C) |
| Storage Temperature |
-4F (-20C) to 122F (50C) |
| Performance
|
| Line-of-Sight Distance |
Up to 1000 feet (305 m) with optional HGA51G-DIR30 directional antenna |
| Supported Hardware
|
| Products |
MPX1500T, MPX1500R, MPX1000T, MPX1000R |
| Standards
|
| Approvals |
UL, cUL, FCC, CE |
| Warranty
|
| Warranty |
Two Years |
