ASUS M4A88TD-M Motherboard
  • AM3, 880G, SB850, HT 5200, 4xDDR3-1066, 1xPCI-Ex16 v2.0, 6xSATA-II, RAID, GigLAN, 8Chl, VGA, DVI, HDMI, mATX

IMG 1 of 5
No Longer Available
Part Number:
142594
(?) Brand:
ASUS Web Site
Manuf No:
M4A88TD-M
M4A88TDM
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
M4A88TDM, M4A88TD-M, MBDASUM4A21D

M4A88TD-M

Unlock AMD CPU's Potential, Turbocharge your Performance!



  • Turbo Unlocker - On Demand Real Time System Tuning
  • Core Unlocker - Unlock the Potential, Turbocharge your Performance!
  • GPU Boost - Instant iGPU Level Up!
  • TurboV EVO - The Ultimate O.C. Processor!
  • True SATA 6Gb/s Support

    • CPU, Chipset, and Graphics Features

    AMD Phenom II/Athlon II/ Sempron 100 series Processors (socket AM3)

    This motherboard supports AMD Socket AM3 multi-core processors with unique L3 cache and delivers better overclocking capabilities with less power consumption. It features dual-channel DDR3 1333 memory support and accelerates data transfer rate up to 5200MT/s via HyperTransport 3.0 based system bus. This motherboard also supports AMD CPUs in the new 45nm manufacturing process.

    Dual-Channel DDR3 2000(O.C.)

    The motherboard supports DDR3 memory that features data transfer rates of 2000(O.C.)/1600(O.C.)/1333/1066 MHz to meet the higher bandwidth requirements of the latest operation system, 3D graphics, multimedia, and Internet applications.

    Hybrid CrossFireX Support

    Boosted Performance with onboard GPU and discrete graphics card
    ATI Hybrid CrossFireX technology is a unique hybrid multi-GPU technology. It takes your gaming experience to the next level boosting PC performance by enabling the chipsets integrated graphics processor and a discrete GPU to operate simultaneously with combined output for blisteringly-fast frame rates unleashing the graphics performance
    * Visit www.amd.com for the Hybrid CrossFireX selected GPUs.

    HDMI/DVI/RGB Support

    Flexible Graphics Alternatives
    This motherboard supports multiple digital and analog display output interfaces - HDMI, DVI, and D-Sub. With such diversity of display outputs, you are able to choose and upgrade display devices freely.

    AMD 880G/SB850 Chipset

    AMD 880G Chipset is designed to support up to 5200MT/s HyperTransport 3.0 (HT3.0) interface speed and PCI Express 2.0 x 16 graphics. It is optimized with AMD's latest AM3 and multi-core CPUs to provide excellent system performance and overclocking capabilities.The AMD SB850 Southbridge natively supports the next generation SATA 6.0 Gb/s data transfer rate and PCI Express 2.0 interface.



    PCIe 2.0 support

    This motherboard supports the latest PCIe 2.0 devices for double speed and bandwidth which enhances system performance.



    HDMI Support

    Enjoy Full HD 1080p Multimedia Home-Theater Entertainment
    High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals through a single cable. Supporting HDCP copy protection such as HD DVD and Blu-ray Discs, HDMI provides you with the highest-quality home theater experience.

    Next-gen Technology

    Serial ATA 6.0 Gb/s support

    The AMD SB850 Southbridge natively supports next-generation Serial ATA (SATA) storage interface, this motherboard delivers up to 6.0 Gb/s data transfer rates. Additionally, get enhanced scalability, faster data retrieval, double the bandwidth of current bus systems.

    ASUS Overclocking Tools

    TurboV EVO

    The Ultimate O.C. Processor
    The ultimate O.C. processor satisfies every level of overclockersfrom die-hard enthusiasts to beginners. Auto tuning intelligently pushes the system to the fastest clock speeds while maintaining stability. Turbo Key boosts performance with just one touch; while TurboV offers more options to advanced overclockers to achieve world O.C. record. Moreover, upgrade your CPU at no additional cost with CPU Level UP!

    Turbo Key

    Touch-n-Boost!
    ASUS Turbo Key allows you to turn the PC power button into a physical overclocking button. After the easy setup, Turbo Key can boost performances without interrupting ongoing work or games, simply through pressing the button.

    Auto Tuning

    Auto System Level Up
    Auto Tuning is an intelligent tool that automates overclocking to achieve a total system level up. This tool also provides stability testing. Even O.C. beginners can achieve extreme yet stable overclocking results with Auto Tuning!

    Precision Tweaker 2

    Allows you to fine-tune the CPU/NB voltage in 0.003125V steps and DRAM voltage in 0.015V steps to achieve the most precise setting for the ultimate overclocking configuration.

    Turbo Unlocker

    Turbo Unlocker is the next evolution of an exclusive ASUS performance boost feature. All it takes is one click in the TurboV EVO interface and Turbo Unlocker automatically and dynamically adjusts each core frequency to speed up performance based on actual system load. Turbo Unlocker gets you in touch with more performance exactly when you need it.


    Core Unlocker

    ASUS Core Unlocker simplifies the activation of a latent AMD CPUwith just a simple switch. Enjoy an instant performance boost by simply unlocking the extra cores, without performing complicated BIOS changes.
    * The actual overclocking result depends on the system configuration.

    GPU Boost

    GPU Boost overclocks the integrated GPU in real time for the best graphics performance. User-friendly UI facilitates flexible frequency and voltage adjustments. Its ability to deliver multiple overclocking profiles also provides rapid and stable system-level upgrades.

    ASUS Power Solutions

    EPU

    System Level Energy Efficiency
    The ASUS EPU (Energy Processing Unit) provides total system power management by detecting current PC loadings and intelligently moderating power usage for critical PC components in real-timehelping save power and money!

    Anti-Surge Protection

    This special design prevents expensive devices and the motherboard from damage caused by power surges from switching power supply(PSU).

    Express Gate

    Express Gate

    0 to Internet in Seconds!
    Express Gate is an ASUS exclusive OS that provides you with quick access to the Internet and key applications before entering Windows.

    Quiet Thermal Solutions

    Q-Fan

    ASUS Q-Fan technology intelligently adjusts both CPU fan speeds according to system loading to ensure quiet, cool and efficient operation.

    Other ASUS Features

    CrashFree BIOS3

    The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a USB flash disk containing the BIOS file. This utility saves users the cost and hassle of buying a replacement BIOS chip.


    Uses 100% All High-quality Conductive Polymer Capacitors!

    This motherboard uses all high-quality conductive polymer capacitors onboard for durability, improved lifespan, and enhanced thermal capacity.

    High Definition Audio

    Enjoy high-end sound system on your PC!
    The onboard 8-channel HD audio (High Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio output, jack-sensing feature, retasking functions and multi-streaming technology that simultaneously sends different audio streams to different destinations. You can now talk to your partners on the headphone while playing a multi-channel network games. All of these are done on one computer.

    EZ Flash 2

    ASUS EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predefined hotkey to launch the utility and update the BIOS without entering the OS. Update your BIOS easily without preparing a bootable diskette or using an OS-based flash utility.

    MyLogo2

    Personalize your system with customizable boot logo
    You can convert your favorite photo into a 256-color boot logo for a more colorful and vivid image on your screen.

    S/PDIF-out on Back I/O Port

    This motherboard provides convenient connectivity to external home theater audio systems via optical S/PDIF-out (SONY-PHILIPS Digital Interface) jacks. It allows to transfer digital audio without converting to analog format and keeps the best signal quality.

    RoHS

    GreenASUS

    The motherboard and its packaging comply with the European Union's Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers' health while minimizing the impact on the environment.



    Specifications

    CPU AMD Socket AM3 ;PhenomII /AthlonII /Sempron 100 Series Processors
    AMD 140W CPU Support
    AMD Cool 'n' Quiet Technology
    Supports 45nm CPU
    Chipset AMD 880G/SB850
    System Bus Up to 5200 MT/s ; HyperTransport 3.0
    Memory 4 x DIMM, Max. 16 GB, DDR3 2000(O.C.)/1600(O.C.)/1333/1066 ECC,Non-ECC,Un-buffered Memory
    Dual Channel memory architecture
    *Due to CPU spec., AMD 100 and 200 series CPUs support up to DDR3 1066Mhz. With ASUS design, this motherboard can support up to DDR3 1333MHz.
    **Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit WindowsWindows OS when you want to install 4GB or more memory on the motherboard.
    ***Refer to www.asus.com for the memory QVL (Qualified Vendors Lists)
    Expansion Slots 1 x PCIe 2.0 x16
    2 x PCIe 2.0 x1
    1 x PCI
    VGA Integrated ATI Radeon HD 4250 GPU
    - Supports HDMI Technology with max. resolution up to 1920 x 1080
    - Supports Dual-link DVI with max. resolution up to 2560x1600 @60Hz
    - Supports D-Sub with max. resolution 2048x1536 @85Hz
    - Hybrid CrossFireX Support
    - Dual independent displays support with HDMI / DVI and D-Sub
    - Supports Microsoft DirectX 10.1, OpenGL 2.0, Shader Model 4.1
    - Hardware Decode Acceleration for H.264,VC-1, and MPEG-2
    - Maximum shared memory of 1GB
    Storage Southbridge
    6 xSATA 6.0 Gb/s ports Support RAID 0,1,5,10
    VIA VT6415 PATA controller
    1 xUltraDMA 133/100 for up to 2 PATA devices
    LAN Realtek RTL8111E Gigabit LAN controller featuring AI NET 2
    Audio ALC892 8-Channel High Definition Audio CODEC
    - Supports 192kHz/ 24bit BD Lossless Sound
    - Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking (HD mode only)
    - Optical S/PDIF Out ports at back I/O
    USB 14 USB 2.0/1.1 ports (8 ports at mid-board, 6 ports at back panel)
    ASUS Unique Features ASUS Xtreme Design
    ASUS Hybrid Processor -- TurboV EVO
    - Turbo Unlocker, Auto Tuning, TurboV, CPU Level UP and GPU Boost
    ASUS Hybrid Switch
    - Core Unlocker
    ASUS Hybrid OS -- Express Gate
    ASUS Power Solutions
    - 4+1 Phase Power Design
    - ASUS Anti-Surge Protection
    - ASUS EPU
    ASUS Exclusive Features
    - MemOK!
    ASUS Quiet Thermal Solution
    - ASUS Fanless Design: Heat sink solution
    - ASUS Fan-Xpert
    - ASUS Stack Cool 3
    ASUS EZ DIY
    - ASUS O.C. Profile
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 2
    - ASUS MyLogo 2
    Overclocking Features Precision Tweaker 2
    - vCore: Adjustable CPU voltage at 0.003125V increment
    - vChipset (VDDNB): Adjustable chipset voltage at 0.003125V increment
    - vDIMM: Adjustable DRAM voltage at 0.015V increment
    SFS (Stepless Frequency Selection)
    - PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
    - HT frequency tuning from 100MHz up to 550MHz at 1MHz increment
    Overclocking Protection
    - ASUS C.P.R.(CPU Parameter Recall)
    Special Features 100% All High-quality Conductive Polymer Capacitors
    Back Panel I/O Ports 1 x PS/2 Keyboard/Mouse Combo port
    1 x DVI
    1 x D-Sub
    1 x HDMI
    1 x S/PDIF Out (Optical)
    1 x LAN(RJ45) port
    6 x USB 2.0/1.1
    8 -Channel Audio I/O
    Internal I/O Connectors 4 x USB connectors (8 ports)
    1 x COM connector
    1 x IDE connector
    6 x SATA 6Gb/s connectors
    1 x CPU Fan connector
    1 x Chassis Fan connectors
    1 x Front panel audio connector
    1 x S/PDIF Out Header
    1 x Core Unlocker Switch
    1 x MemOK! Button
    1x LPT connector
    24-pin EATX Power connector
    4-pin ATX 12V Power connector
    1 x System panel connector
    BIOS 16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SPI, SM BIOS 2.5, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
    Manageability WOL by PME,WOR by PME,WOR by Ring,PXE
    Accessories 1 x Ultra DMA 133/100/66 cable
    2 x Serial ATA 3 Gb/s cables
    1 x Serial ATA 6 Gb/s cables
    1 x IO shield
    1 x User's manual
    Support Disc Drivers
    Anti-virus software (OEM version)
    ASUS Update
    ASUS Utilities
    Form Factor uATX Form Factor
    9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

    The product (electrical , electronic equipment, Mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
    • All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
    • PCB color and bundled software versions are subject to change without notice.
    • Brand and product names mentioned are trademarks of their respective companies.
