Printer
|
| PRINTER TYPE |
| EPSON STYLUS PHOTO TX700W |
C11CA30401 |
| PRINTING METHOD |
On-demand Inkjet (piezoelectric) |
| NOZZLE CONFIGURATION |
180 nozzles colour (Black, Yellow, Light Magenta, Light Cyan, Cyan, Magenta) |
| PRINT SPEED |
| BLACK TEXT (MEMO) A4 (Draft)^ |
40ppm*1 |
| COLOUR TEXT (MEMO) A4 (Draft)^ |
40ppm*2 |
| Photo 4"x6" (10 x 15cm) (Draft)^ |
Approx. 10 sec *3+ |
Print Speed Data Printout Patterns The thumbnail images below show the printout patterns used to determine print speed specifications.
*"Second" rating refers to the time taken to print one page. The computer environment we test under is as follows: CPU: Pentium 4, 2.4GHz; RAM: 512MB; OS: Windows XP professional; Interface/Connectivity: USB2.0 HighSpeed; SOFTWARE: Word XP/PhotoShop7.0; PAPER: Epson Premium Glossy Photo Paper or Plain Paper
+ When printed on Epson Premium Glossy Photo Paper |
| RESOLUTION |
| |
5760 Optimised dpi using Resolution Performance Management (RPM) Technology |
| MINIMUM INK DROPLET VOLUME |
1.5 Picolitres |
| PRODUCT DIMENSIONS |
446mm (W) x 385mm (D) x 150mm (H) |
| WEIGHT |
9.3kg |
| PAPER HANDLING |
| PAPER SIZES |
A4, Letter, Legal, 8x10", 5x7", 4x6", 3.5x5", 5x8", A6, A5, B5, Half Letter, Envelopes: No10, DL, C6 |
| PAPER HOLD CAPACITY |
120 sheets, A4 Plain paper |
*True BorderFree printing is available for the following media sizes: 4"x6", 5"x7" and A4.
Media types recommended: Premium Glossy Photo paper A4, 4"x6" and 5"x7".
BorderFree prints are media dependent. |
Scanner
|
| SCANNER TYPE |
A4 Flatbed colour image scanner |
| SENSOR TYPE |
CIS |
| DOCUMENT SIZE |
Up to A4 |
| PIXEL DEPTH |
Input 48bits (16bits/colour) / output 24bits (8bits/colour) |
| SCANNING RESOLUTION |
2400 x 4800 dpi |
| SCAN SPEED |
A4 1200dpi 6m sec/line (mono) |
| |
A4 1200dpi 12m sec/line (colour) |
Copy Function
|
| COPY SPEED+# |
| Copy Speed Black or Colour A4 |
40cpm (mono)
39cpm (colour) |
| COPY FEATURES |
| COPY MODES |
Auto Fit Function
Standard copy mode/ BorderFree
|
General
|
| OPERATING SYSTEMS |
| PRINTER DRIVERS* |
Win 2000/XP/XP x64/Vista, Mac OS 10.3.9 or later with USB* |
| * Drivers if available are downloadable from Tech Epson |
| ELECTRICAL SPECIFICATIONS |
| RATED VOLTAGE |
AC 220 ~ 240V |
| RATED FREQUENCY |
50 ~ 60Hz |
| |
Approx. 25W Standalone copying (ISO10561 Letter Pattern) |
| POWER CONSUMPTION |
Sleep mode : Approx. 5.0W
Power OFF : Approx. 0.5W |
| NOISE LEVEL |
| NOISE LEVEL# |
4.8B(A), 35dB(A)> |
| INTERFACES |
| CONNECTIVITY |
HiSpeed USB Compatible with the USB 2.0 Specification (cable included) |
| NETWORKING |
802.11b/g WiFi
10-Base-T, 100 Base-TX Ethernet (cable included)
|
| LCD SCREEN |
2.5" with tilt-adjustment via control panel |
| CARD SLOTS |
CF Type II, Memory Stick, SD/MMC, XD-Picture card |
| PICTBRIDGE |
Yes
|
| PRINTER SOFTWARE (AVAILABLE ON CD-ROM ONLY) |
| SOFTWARE TOOLS* |
Epson Event Manager (with Scan 2.0 and Email 1.0)
Epson Easy Photo Print
Epson Web-To-Page
Epson Print CD (for CD/DVD printing)
Optical Character Recognition (OCR)
Online Guide
|
| OPTIONS |
| Bluetooth adaptor |
C12C824384
|
| Auto Duplexer |
C12C802521 |
| LIGHTFASTNESS |
| LIGHTFASTNESS# |
Up to 200 years album storage |
| # Data is calculated using accelerated simulation of fading under indoor preservation conditions including fluorescent light indoor display. Temperature, humidity and some atmospheric gases may also affect the rate of fading. The estimated lightfastness period does not indicate the colour changing or the durability of the paper itself. Epson recommends that your prints be stored in a photo album (or plastic photo storage box) in acid free, archival sleeves commonly available from most camera shops. |
| INK CARTRIDGES |
| STANDARD INK CARTRIDGES |
82N Black, 82N Cyan, 82N Magenta, 82N Yellow, 82N Light Cyan, 82N Light Magenta |
| HIGH CAPACITY INK CARTRIDGES |
81N Black, 81N Cyan, 81N, Magenta, 81N Yellow, 81N Light Cyan, 81N Light Magenta |
| STANDARD INK CARTRIDGE YIELDS^^ |
Black 360 pages, Colour Composite 535 pages |
| HIGH CAPACITY INK CARTRIDGE YIELDS^^ |
Black 575 pages, Colour Composite 865 pages |
|
^ Print speed (PPM) when printed on A4 plain paper in the fastest mode. 10x15cm photo print speed when printed on Epson Premium Glossy Photo Paper borderless in draft mode. Print speed may vary depending on system configuration, print mode, document complexity, software, type of paper used and connectivity. Print speed does not include processing time on host computer.
+ Copy speed when printed on plain paper in the fastest mode. Copy speed may vary depending on copy mode, document complexity, type of paper used and number of copies.
|
