ATEN CE770 KVM Extender Kit VGA/Audio Cat 5 Extender With Deskew
1920x1200@60Hz 150m, 1280x1024@60Hz 300m

Our Price:

$605.10

RRP:

~~$699.00~~

You Save:

$93.90

Qty:

Add To Cart

or quickly purchase this product

Buy Now

Backorder

Part Number:

140827

(?) Brand:

ATEN

Manuf No:

CE770-AT-U
CE770ATU

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Date Added:

19/4/2010

Add to wishlist

Write a Review

Details Files Finance Images & Video

Enter email address to be notified when this item is available again

Join waiting list

All stock codes associated to this product

CE770ATU, CE770-AT-U, KVACE770, KVA-CE-770, ATCE770, 4710423776432

CE770

USB KVM Extender

The CE770 is a USB based KVM Extender with Deskew function. The automatic signal compensation and RS-232 serial functionality allow access to a computer system from a remote USB console.

The CE770 supports RGB delay tuner to manually synchronize the RGB signals. This allows users to deploy system equipment over large distances. The CE770's line synchronizing function corrects color phase and timing errors that occur over long distance transmissions. It also enables you to manually tune the R/G/B signal settings.

Features

	Local and Remote Units connect at distances up to 300 m using Cat 5e cable
	Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
	Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance
	Built-in ASIC for greater reliability and compatibility
	Auto Signal Compensation (ASC)
	RS-232 serial ports - allow you to connect to a serial terminal, or serial devices such as touchscreens and barcode scanners
	Sun/Mac keyboard support and emulation*
	Audio Enabled - supports stereo speakers and microphone
	USB overcurrent detection and prevention
	Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes, with the press of a single button
	Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
	High resolution video - up to 1920 x 1200@60Hz (150 m); 1280 x 1024@60Hz (300 m)
	Superior Audio - no loss in audio quality at 300 m
	Spports Wide Screen formats
	Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), WUXGA (1920 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B
	Hot pluggable
	Rack mountable
	Easy to install - no software required - connecting cables to the devices is all it takes 1. PC keyboard combinations emulate Sun/Mac keyboards 2. Sun/Mac keyboards only work with their own computers

Package Content

	1x CE770L USB KVM Extender (Local Unit)
	1x CE770RQ USB KVM Extender (Remote Unit)
	1x USB KVM Cable (1.8m)
	2x Power Adapter
	1x Rack Mount Kits
	2x Grounding Wires
	1x User Manual
	1x Quick Start Guide

Diagram

+ View enlargement

Specification

Function			CE770L	CE770RQ
Connectors	Console Ports	Keyboard	1 x USB Type A Female (White)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (White)
		Speakers	1 x Mini Stereo Jack Female (Green)
		Mic.	1 x Mini Stereo Jack Female (Pink)
		RS-232	1 x DB-9 Female (Black)	1 x DB-9 Male (Black)
	KVM Ports	Keyboard/ Video / Mouse	1 x SPHD-17 Female (Yellow)	N/A
		Speakers	1 x Mini Stereo Jack (Green)
		Mic.	1 x Mini Stereo Jack (Pink)
	Power		1 x DC Jack (Black)
	Unit to Unit		1 x RJ-45 Female (Black)
LEDs	Local		1 (Green)	N/A
	Remote		1 (Green)	N/A
	B		N/A	1 (Blue)
	G	Link	N/A	1 (Orange/Green)
	R	Remote	N/A	1 (Red)
Pushbuttons	Operating Mode Selection		1 x Pushbutton	N/A
	Color / Up		N/A	1 x Pushbutton
	Select / Down		N/A	1 x Pushbutton
Emulation	Keyboard / Mouse		USB
Video			1920 x 1200 @ 60Hz (150 m); 1280 x 1024 @ 60Hz(300m); DDC, DDC2, DDC2B
Power Consumption			DC5.3V/3.5W	DC5.3V/5.1W
Environment	Operating Temp.		0 - 50XC
	Storage Temp.		-20 - 60XC
	Humidity		0-80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		0.49 kg	0.48 kg
	Dimensions (L x W x H)		20.00 x 8.00 x 2.50 cm
