| Operating indicators |
|
| Visual |
1 LED (red/green/orange) |
| Non-visual |
Buzzer |
| Communication |
|
| RS232 |
DB9 PTF connector with external power supply |
| USB |
Ver. 1.1, VCP, USB-A connector |
| Power |
|
| Voltage requirement |
5V 10% |
| Current consumption |
Max. 500mA |
| Barcode scanner Optics |
|
| Light source |
650 nm visible laser diode |
| Scan method |
Polygon mirror |
| Scan rate |
1000 scans/sec |
| Trigger mode |
Manual, multiple read, serial software trigger |
| Reading pitch angle |
-30 to 0, 0 to +30 |
| Reading skew angle |
-60 to -7, +9 to +60 |
| Reading tilt angle |
-25 to 0, 0 to +25 |
| Curvature |
R>15 mm (EAN8), R>20 mm (EAN13) |
| Min. resolution at PCS 0.9 |
0.15 mm / 6 mil |
| Depth of field |
70 - 330 mm / 2.76 - 12.99 in (1.0 mm / 39 mil), 60 - 270 mm / 2.36 - 10.36 in (0.5 mm / 20 mil), 60 - 200 mm / 2.36 - 7.87 in (0.25 mm / 10 mil), 70 - 140 mm / 2.76 - 5.51 in (0.15 mm / 6 mil), at PCS 0.9, Code 39 |
| Supported Symbologies |
|
| Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, GS1-128 (EAN-128), IATA, Industrial 2of5, Interleaved 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
| Postal code |
Chinese Post |
| 2D code |
MicroPDF417, PDF417 |
| Durability |
|
| Temperature in operation |
0 to 45 C / 32 to 113 F |
| Temperature in storage |
-20 to 65 C / -4 to 149 F |
| Humidity in operation |
5 - 90% (non-condensing) |
| Humidity in storage |
5 - 90% (non-condensing) |
| Ambient light immunity |
Fluorescent 4,000 lx max, Direct sun 80,000 lx max, Incandescent 4,000 lx max |
| Antistatic electricity |
15kV (non-destructive) |
| Drop test |
0.75 m / 2.5 ft drop onto concrete surface |
| Protection rate |
IP 54 |
| Physical |
|
| Dimensions (w x h x d) |
29 x 17 x 34 mm / 1.14 x 0.67 x 1.34 in |
| Weight body |
Ca. 30 g / 1.06 oz (excl. cable) |
| Case |
Metal diecast, Black |
| Regulatory & Safety |
|
| Product compliance |
CE, FCC, VCCI, RoHS, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II |
