All stock codes associated to this product
RPC3216R, RPC-3216R
Features:
* 3U rackmount design
* Sixteen hot-swappable SATA (I or II) / SAS drive bays
* Four internal SFF-8087 Mini SAS connectors support up to sixteen 3.5" or 2.5" SATA (I or II) or SAS hard disk drives;
* Hot-swappable HDD tray with special designed power-off and lock mechanism.
* 1 x slim CD-ROM bay,1 x FDD bay, 16 x 3.5" hot-swappable drive bays, 1 x 3.5" drive bay.
* Six ball-bearing cooling fans for better ventilation
* Support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6") motherboard (If working with standard power supply, four expansion slots are available; if working with redundant power supply and optional back window, seven expansion slots are available)
* Screwless top cover
* Smooth border prevent lacerating your skin
Specifications:
Drive Bay:
16 x hot-swappable SATA/SAS drive bays, 1 x slim CD-ROM bay, 1 x slim FDD bay, 1 x HDD bay
Cooling Fan:
4 x 80mm middle fans, 2 x 60mm rear fans
Switch:
Power ON/OFF x 1, System reset x 1
Indicator:
Power ON/OFF x 1, HDD x 1, NETWORK X 2
Connector:
Front accessible USB port, Four internal SFF-8087 Mini SAS connectors, ten 4-pin molex power connectors.
Motherboard Compatibility:
Support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6") (If working with standard power supply, four expansion slots are available; if working with redundant power supply and optional back window, seven expansion slots are available)
Power Supply Options:
Mini redundant power supply supported ONLY
Dimensions ( W x D x H ):
16.9" x 25.5" x 5.1 " (430mm x 650mm x 130.1mm)
Packing:
Double boxes, 22" x 33" x 9.5"
Weight:
12.3 kg/27 lb (NET) 17.7 kg/39 lb (GROSS)
Environment Temperature:
0/55 °C, 32/131 °F (Operating) -20/60 °C, -4/140 °F (Non-Operating)
Relative Humidity:
5% to 95%,non-condensing
Vibration ( 5-500 Hz ):
1 Grms (Operating), 2 G (Non-Operating)
Shock:
10 G(with 11ms duration, half sine wave) (Operating), 30 G (Non-Operating)
