GENERAL
|
| General type |
Monochrome multifunctional for A4/ A3 format |
| Technology |
KYOCERA ECOSYS, Mono Laser, HyPAS |
| Engine speed |
Up to 25/12 pages A4/A3 per minute (print/copy) |
| Resolution |
600 x 600 dpi (print), 600 x 600 dpi (scan/copy) |
| Warm-up time |
20 seconds or less |
| Time to first print |
Approx. 8 seconds or less |
| Time to first copy |
Approx. 9.2 seconds or less (DP), 7.8 seconds or less (Platen Cover) |
| Dimensions (W x D x H) |
590x590x694 mm (Dimensions with document processor) |
| Weight |
Approx. 52.2 kg (Weight with document processor, including toner container) |
| Power consumption |
Sleep-mode: 0.9W, Ready mode: 114 W, Copying/Printing: 530 W |
| Power source |
AC 220 ~ 240 V, 50/60 Hz |
| Noise (ISO 7779) |
Copying/Printing: 46.8 dB(A), Stand-by: 27.1 dB(A) |
| Safety standards |
TV/GS, CE - This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| General memory |
1024 MB, max. 2,048 MB |
|
 |
PAPER HANDLING
|
| Input capacity |
100-sheet multi-purpose tray, 45256 g/m (52163 g/m for larger than A4/Letter size): A3, A4, A5, A6, B5, Letter, Legal, Folio, envelopes, Custom (98 x 148 to 297 x 432 mm) 500-sheet universal paper cassette, 60163 g/m, A3, A4, A5,B5, Letter, Legal, Folio |
| Max. input capacity with options |
1,600 sheets |
| Duplex unit |
Duplex as standard supports 60163 g/m |
| Max. output capacity |
Max. 300 sheets: 250 sheets face-down (main tray), plus 50 sheets (job separator tray) |
| Document processor |
Reversing document processor: 50-sheet, Simplex scan 45160 g/m, Duplex scan 50120 g/m, A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm) |
| General paper handling |
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions. |
|
|
PRINT
|
| Processor |
PowerPC 464 - 800 MHz |
| Controller language |
PRESCRIBE IIe |
| Emulations |
PCL 6 (5e/XL), KPDL3 (Postscript 3 compatible), PDF Direct print, XPS Direct print |
| Fonts |
93 outline fonts (PCL 6, KPDL 3) + 8 (Windows Vista), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417) |
| Integrated Accounting |
100 department codes |
| Features |
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Private Print |
| Standard Interfaces |
USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10/100/1000Base-TX, slot for optional print server, slot for optional CompactFlash-Card |
| Resolution |
600 x 600 dpi |
| Applicable OS |
All current Windows operating systems, MAC OS X Version 10.4 or higher, Unix, Linux as well as other operating systems on request |
|
|
COPY
|
| Copy resolution |
600 x 600 dpi |
| Max. original size |
A3/Ledger |
| Digital copy features |
Scan-once-copy-many, electronic sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through |
| Exposure modes |
Auto, manual: 7 steps |
| Preset magnification ratios |
5 Reductions/5 Enlargements |
| Zoom range |
25 - 400 % in 1% steps |
| Continuous copy |
1 - 999 |
| Image adjustments |
Text, Photo, Text + Photo, Graphic/Map, Copy/Printout |
|
|
SCAN
|
| Compression format |
MMR /JPEG |
| File type |
PDF, PDF/A, JPG, TIFF, XPS |
| Scan features |
Colour Scan integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once |
| Original recognition |
Text, photo, text + photo, optimized for OCR |
| Max. scan size |
A3/Ledger |
| Scan functionalities |
Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan |
| Scan resolution |
200 dpi, 300 dpi, 400 dpi, 600 dpi (256 greyscales per colour) |
| Scan speed |
40 ipm (300 dpi, A4, b/w), 20 ipm (300 dpi, A4, colour) |
|
|
FAX
|
| Compatibility |
ITU-T Super G3 |
| Modem speed |
Max. 33.6 kbps |
| Scanning speed |
2.0 seconds (Quick Scanning, Bitmap) |
| Transmission speed |
Less than 3 sec |
| Scanning density |
Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 256 gray scales |
| Max. original size |
A3/Ledger |
| Compression method |
JBIG, MMR, MR, MH |
| Fax features |
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast |
|
|
INTERFACES
|
| Standard interface |
USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10/100/1000Base-TX, slot for optional print server, slot for optional CompactFlash-Card |
|
|
WARRANTY
|
| Warranty |
1-year warranty as standard. KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. |
|
