GENERAL
|
| General type |
b/w multifunctional for A4 format |
| Technology |
KYOCERA ECOSYS Laser |
| Engine speed |
Up to 40 pages A4 per minute |
| Resolution |
1,200 dpi quality (1,800 x 600, print), 600 x 600 dpi, 256 greyscales (scan/copy) |
| Warm-up time |
Approx. 21 seconds or less from power on |
| Time to first print |
Approx. 9 seconds or less |
| Time to first copy |
Approx. 9 seconds or less |
| Dimensions (W x D x H) |
475 x 455 x 575 mm |
| Weight |
Approx. 21.5 kg |
| Power consumption |
Copying / Printing: 680 W, Ready mode: 54.7 W, Low-power mode: 29.7 W, Sleep-mode: 2.6W Typical Electricity Consumption (TEC): 2.2 KWh / week |
| Power source |
AC 220 ~ 240 V, 50 Hz |
| Noise (ISO 7779) |
Noise (Sound pressure level: ISO 7779 / ISO 9296) Copying / Printing: 51,1 dB(A), Ready mode: 26,5 dB(A), Quiet mode: 48,9 dB(A) |
| Safety standards |
TV/GS, CE - This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| General memory |
Standard 512 MB, max. 1536 MB |
|
 |
PAPER HANDLING
|
| Input capacity |
100-sheet multi-purpose tray; 60 220 g/m; A4, A5, A6, B5, Letter, Legal, Custom (70 x 148 216 x 356 mm) 500-sheet universal paper cassette, 60 120 g/m; A4, A5, B5, Letter, Legal, Custom (140 x 210 216 x 356 mm) |
| Max. input capacity with options |
2,600 sheets |
| Duplex unit |
Duplex as standard supports A4, A5, B5, Letter, Legal, Custom (140 x 210 mm to 216 x 356 mm), 60120 g/m |
| Max. output capacity |
250-sheet-face-down with paper full sensor |
| Document processor |
Reversing document processor: 75-sheet, 50120 g/m, A4, A5, A6, B5, Letter, Legal, Custom (105 x 148 to 216 x 356 mm) |
| General paper handling |
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions. |
|
|
PRINT
|
| Processor |
PowerPC 465S / 667 MHz |
| Controller language |
PRESCRIBE IIe |
| Emulations |
PCL 6 (5c / XL), KPDL 3 (PostScript 3-compatible), Line Printer, IBM Proprinter X24E, Epson LQ-850, PDF Direct Print 1.7, XPS Direct Print |
| Fonts |
93 outline fonts (PCL 6, KPDL 3) + 8 (Windows Vista), 1 bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417) |
| Integrated Accounting |
100 department codes |
| Features |
AirPrint, Encrypted PDF Direct Print, IPP printing, Email printing, WSD print, Secure printing via SSL, IPsec, HTTPS, SNMPv3, IPPS, POP over SSL, SMTP over SSL, Private Print, Toner save mode |
| Resolution |
1,200 dpi quality (1,800 x 600, print) |
| Applicable OS |
All current Windows operating systems, MAC OS X version 10.5 or higher, Unix, Linux as well as other operating systems on request |
|
|
COPY
|
| Copy resolution |
600 x 600 dpi |
| Max. original size |
A4/Legal |
| Digital copy features |
Scan-once-copy-many, electronic sort, 2in1, 4in1, ID-card copy, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change, copy density control |
| Exposure modes |
Auto, manual: 9 steps |
| Preset magnification ratios |
7 Reductions / 5 Enlargements |
| Zoom range |
25 - 400 % in 1% steps |
| Continuous copy |
1 - 999 |
| Image adjustments |
Text + photo, text, photo, graphic/map |
|
|
SCAN
|
| File type |
PDF (high compression, encrypted, PDF/A), JPEG, TIFF, XPS |
| Scan features |
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi-send (e-mail, fax, SMB/FTP folder, print) at once |
| Original recognition |
Text, photo, text + photo, for OCR |
| Max. scan size |
A4 / Legal |
| Scan functionalities |
Scan-to-Email, Scan-to-FTP , Scan-to-SMB, Scan to USB Host, Network Twain, WSD (WIA) scan (USB, network) |
| Scan resolution |
600, 400, 300, 200 dpi (256 greyscales) |
| Scan speed |
40 ipm (300 dpi, A4, b/w), 30 ipm (600 dpi, A4, b/w, 300 dpi, A4, colour) |
|
|
FAX
|
| Compatibility |
ITU-T Super G3 |
| Modem speed |
Max. 33.6 kbps |
| Scanning speed |
2.5 seconds |
| Transmission speed |
Less than 3 seconds |
| Scanning density |
Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, Halftone: 256 greyscales |
| Max. original size |
A4 / Legal |
| Compression method |
JBIG, MMR, MR, MH |
| Fax features |
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast |
|
|
INTERFACES
|
| Standard interface |
USB 2.0 (Hi-Speed), 2 x USB Host 2.0, GigaBit Ethernet (10BaseT / 100Base-TX / 1000BaseT), slot for optional internal interface or SSD hard disc, slot for optional SD / SDHC card |
|
|
WARRANTY
|
| Warranty |
1-year warranty (depending on the country) as standard. Kyocera guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. |
|
