| PRINTER |
|
| Type |
Desktop |
| Print engine |
Electrophotographic |
| Print speed |
Up to 22ppm |
| First Print Speed |
Less than 10 sec (from print-data-in to paper-ejection)
Less than 6 sec (from paper-feed-start to paper-ejection) |
| Warm-up Time |
Less than 27 sec *2 |
| Printing resolution |
1200 x 600 dpi / 600 x 600 dpi |
| Duplex |
Manual |
| Dimensions (W x D x H) |
402 x 360 x 293 mm |
| Weight |
Less than 11.1kg |
| Input capacity |
Standard: 150 sheets |
| |
Bypass: 1 sheet |
| |
ADF: Up to 35 sheets |
| Output capacity |
Standard: 50 sheets(face down, 70 g/m2) |
| |
Bypass: 1 sheet (face-up, straight paper path) |
| Paper size |
Standard: A4, Letter, Half letter, B5 (ISO), A5, B6, A6, Executive, 16K, Legal |
| |
Bypass: Width 100mm to 216mm, Length 148mm to 356mm
ADF: Width 139.7mm to 215.9mm, Length 139.7mm to 355.6mm
|
| Media type |
Standard/Bypass: Plain Paper, Recycled Paper |
| |
ADF: Plain Paper, Recycled Paper |
| Paper weight |
Standand: 60 - 105g/m2 |
| |
ADF: 52 - 105g/m2 |
| Power source |
220 - 240V, 50/60Hz |
| Network protocol |
TCP/IP |
| Windows environments |
Windows XP/Vista/7/Server 2003/x64/Server 2003 R2/Server 2008/Server 2008 R2/8/Server 2012 |
| |
|
| |
|
| COPIER |
|
| First copy speed |
Less than 32 sec |
| Maximum original size |
A6 SEF - A4/LT
Custom: Max 216mmW x 297mmL |
| Copy speed |
A4 (210 x 297mm) Up to 22 cpm |
| Multiple copy |
Stack : Yes (up to 99) |
| |
Sort : Yes |
| Resolution |
600 x 600 dpi, 600 x 300 dpi |
| Reduction/ Ealargement |
25% - 400% in 1% increments |
| Duplex |
Manual |
| Combine copy |
Yes (ADF mode only) |
| ID card copy |
Yes |
| |
|
| |
|
| SCANNER |
|
| Color / Mono |
Color |
| Resolution (TWAIN) |
Glass 600 x 600 dpi |
| |
ADF: 600 x 300 dpi |
| Scanning speed |
Colour : 9.90ipm300x300dpi
Monochrome : 29.70ipm600x300dpi |
| Scan size |
A6 SEF - A4/LT
Custom: Max 216mmW x 356mmL |
| TWAIN compliant |
TWAIN, WIA |
| |
|
| |
|
| FAX |
|
| Compatibility |
G3 |
| Coding system compression |
MH / MR / MMR |
| Modem speed |
33.6 kbps - 2400 bps |
| Transmission speed |
Approx. 3 sec |
| Speed dial / group dial |
100 locations |
| Automatic redial |
Yes |
| Dual access |
Yes |
| Time Indicator |
Yes |
| Memory backup |
Yes |
| Smoothing |
Yes |
| PC FAX |
Yes (send/receiver) |
| |
|
| |
|
| ECOLOGY |
|
| Power consumption |
Average: Less than 900W |
| |
Standby: Less than 60W |
| |
Sleep: Less than 3.7W |
| |
|
| |
|
| CONSUMABLES |
| Max Print Volume (Duty) |
Less than 20,000 pages/month |
| Target Print Volume |
Max 1,000 pages/month
Average: 500 pages/month |
| Target Consumable Yield* |
Starter Toner: Approx 1,000 pages |
| |
High Yield Toner: Approx. 2,600 pages |
| |
|
| *1)ISO/IEC19752 is used to measure the above toner yield. |
| *2) The condition is standard temperature and humidity. |
| *3) This yield number may change depending on the circumstances and printing conditions. |
