All stock codes associated to this product
BDL4256ET, MNPHBDL4256ET, MNPH-BDL4256ET
Signage Solutions Multi-Touch Display
BDL4256ET/00
Product features
Full HD LED for brilliant images with incredible contrast
Picture Quality matters. Regular displays deliver quality, but you expect more. Imagine crisp detail paired with high brightness, incredible contrast and realistic colors for a true to life picture.
Experience amazing interactivity with true Multi-Touch
A brand new level of interactivity is now available thanks to integrated touch technology. More flexibility and optimum simultaneous touch performance coupled with excellent operability opportunities to give you the ultimate in user interaction. The Multi-Touch displays are enabled with automatic touch recognition. The USB connector is HID compliant, providing true plug-and-play operation.
Optical touch technology for advanced user interaction
The sensors on the edge of the screen give you perfect clarity whilst at the same time offering multi-touch interaction, opening up all kinds of possibilities for new interactive applications.
Optional OPS Insert to create an all-in-one solution
Turn your display into an all-in-one digital signage solution and create a display network which is connected, intelligent and secure. Open Pluggable Specification (OPS) is an industry standard slot into which you can add an OPS-standardized media player. This cable free solution gives you the ability to install, use or maintain your hardware whenever you need.
SmartPower for energy saving
The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.
Manage and control your network remotely via SmartControl
SmartControl software suite lets you remotely control and manage your network of displays via RJ45 and RS232C. Easy identify your displays and fine-tune all display settings including resolution, brightness, contrast, video wall configurations and cloning of your settings over your complete network.
Designed for 24/7 operation
Because business never sleeps, our signage displays are designed for 24/7 use. Taking advantage of superior components to ensure a higher level of quality, you can count on this range of models for complete around-the-clock reliability.
True multi touch with 6 simultaneous touch points
Enjoy a more interactive experience with up to 6 touch points at the same time. Ideal for when you have more than one user to interact with your application simultaneously, the 6 touch points offer an extremely cost-effective solution.
Compatible with all leading operating systems
Our touch displays are software independent and supports Windows 8, Windows 7, Vista, XP, Mac OS and Linux.
Technical Specifications
Picture/Display
Diagonal screen size (metric)
106.7 cm
Diagonal screen size (inch)
42 inch
Panel resolution
1920x1080p
- Optimum resolution
- 1920 x 1080 @ 60Hz
-
- Brightness
- 450 cd/m
-
- Contrast ratio (typical)
- 1300:1
-
- Dynamic contrast ratio
- 500,000:1
-
- Response time (typical)
- 12 ms
-
- Aspect ratio
- 16:9
-
- Viewing angle (horizontal)
- 178 degree
-
- Viewing angle (vertical)
- 178 degree
-
- Display colors
- 1.06 Billion
-
- Pixel pitch
- 0.485 x 0.485 mm
-
- Surface treatment
- Anti-Glare coating
-
- Picture enhancement
-
-
-
-
3/2 - 2/2 motion pull down
-
3D Combfilter
-
Motion compens. deinterlacing
-
Progressive scan
-
3D MA deinterlacing
-
Dynamic contrast enhancement
Convenience
Placement
-
Signal Loop Through
-
Network controllable
-
Picture performance
Advanced color control
Picture in picture
PIP
Screen saving functions
Pixel Shift, Low Brightness
Keyboard control
-
Remote control signal
Lockable
Ease of installation
-
Energy saving functions
Smart Power
Packaging
Reusable box
Other convenience
Carrying handles
Sound
Built-in speakers
2 x 10W
Operating conditions
Temperature range (operation)
5 ~ 40 °C
Relative humidity
20 ~ 80 %
MTBF
50,000 hour(s)
Miscellaneous
On-Screen Display Languages
-
-
English
-
French
-
German
-
Italian
-
Polish
-
Turkish
-
Spanish
-
Russian
-
Simplified Chinese
-
Traditional Chinese
-
Arabic
-
Japanese
Regulatory approvals
-
-
CE
-
CCC
-
FCC, Class B
-
UL/cUL
-
RoHS
-
EPA
-
CB
-
C-Tick
-
EAC
-
EMF
-
KUCAS
-
SASO
Warranty
3 year warranty
Interactivity
Multi-touch technology
Optical sensing
Touch points
6 simultaneous touch points
Plug and play
HID compliant
Protection glass
4 mm tempered safety glass
Connectivity
Video input
-
-
DisplayPort (1.1a)
-
HDMI
-
DVI-D
-
VGA (Analog D-Sub)
-
Component (RCA)
-
Composite (RCA)
Video output
-
Audio input
-
-
Audio Left/Right (RCA)
-
3.5 mm jack
Audio output
-
External control
-
-
RJ45
-
RS232C (in/out) D-Sub9
Other connections
-
Supported Display Resolution
Computer formats
-
-
640 x 480, 60, 67, 72, 75Hz
-
800 x 600, 56, 60, 72, 75Hz
-
1024 x 768, 60Hz
-
1280 x 768, 60Hz
-
1280 x 800, 60Hz
-
1280 x 1024, 60Hz
-
1360 x 768, 60Hz
-
1366 x 768, 60Hz
-
1440 x 900, 60Hz
-
1600 x 1200, 60Hz
-
1920 x 1080, 60Hz
-
1920 x 1200, 60Hz
Video formats
-
-
480i, 60Hz
-
480p, 60Hz
-
576p, 50Hz
-
576i, 50Hz
-
720p, 50, 60Hz
-
1080i, 50, 60Hz
-
1080p, 50, 60Hz
Dimensions
Set Width
976.16 mm
Set Height
569.50 mm
Set Depth
79.80 mm
Bezel width
19.5 mm
Product weight
24.75 kg
VESA Mount
400 x 200 mm, 200 x 200 mm
Smart Insert mount
100 x 200 mm, 100 x 100 mm
Power
Mains power
90 ~ 240 VAC, 50/60Hz
Consumption (On mode)
120 W (Typ.)
Standby power consumption
<0.5W
Accessories
Included accessories
Stand
BM05462 (Optional)
